Comprehensive Product Summary: 4G/LTE-EA Package

---

### 1. Product Overview

Product Name: 4G/LTE-EA Package
Model: 4G/LTE-EA
Series: Artila Industrial Connectivity Accessories
Article Number: 4G/LTE-EA Package
Manufacturer: Artila Electronics Co., Ltd.

The Artila 4G/LTE-EA Package is a dedicated external antenna and wiring kit designed to enhance wireless communication performance for Artila’s range of industrial embedded systems, IoT gateways, and communication modules. This package provides a robust, high-gain antenna solution optimized for 4G/LTE networks, ensuring stable connectivity, extended coverage, and improved signal quality in industrial and remote environments. The product integrates seamlessly with Artila’s embedded computing platforms, such as the Matrix and Moxa-compatible series, offering a reliable and easy-to-install connectivity enhancement for data communication, telemetry, and remote monitoring applications.

---

### 2. Key Features

- Optimized for 4G/LTE Networks: Designed to operate across standard LTE frequency bands, ensuring compatibility with global cellular networks.
- High-Gain External Antenna: Provides improved signal strength and stability, particularly in areas with weak cellular coverage.
- Industrial-Grade Construction: Built with durable materials suitable for harsh environments, including outdoor and industrial installations.
- Flexible Mounting Options: Supports magnetic, adhesive, or screw-mount configurations for versatile deployment.
- Extended Cable Assembly: Includes a pre-terminated coaxial cable for easy connection to Artila devices or other compatible modems.
- Plug-and-Play Integration: Fully compatible with Artila’s embedded systems and communication modules, requiring minimal configuration.
- Low VSWR (Voltage Standing Wave Ratio): Ensures efficient power transfer and minimal signal loss.
- Weather-Resistant Design: Suitable for both indoor and outdoor use, with protection against moisture, dust, and UV exposure.
- Compact Form Factor: Streamlined design allows installation in constrained spaces without compromising performance.
- Enhanced Data Throughput: Supports high-speed LTE data transmission for bandwidth-intensive applications such as video streaming, telemetry, and remote diagnostics.

---

### 3. Technical Specifications

| Parameter | Specification |
|----------------|-------------------|
| Product Type | External 4G/LTE Antenna with Cable Assembly |
| Frequency Range | 698–960 MHz / 1710–2690 MHz (LTE Bands 1–20) |
| Gain | 3–5 dBi (typical, depending on frequency band) |
| VSWR | ≤ 2.0:1 |
| Impedance | 50 Ω |
| Polarization | Vertical |
| Connector Type | SMA Male (standard) |
| Cable Type | RG174 or equivalent low-loss coaxial cable |
| Cable Length | 1.5 m (standard), customizable upon request |
| Material (Antenna Housing) | ABS or UV-resistant plastic |
| Mounting Method | Magnetic base / adhesive pad / screw mount (depending on variant) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +90°C |
| Humidity Resistance | Up to 95% RH, non-condensing |
| Ingress Protection | IP65 (weatherproof variant) |
| Dimensions (Antenna) | Approx. 110 mm (height) × 30 mm (diameter) |
| Weight | Approx. 80 g (including cable) |
| Color | Black |
| Compliance | RoHS, CE, FCC |

---

### 4. Functionality

The 4G/LTE-EA Package functions as an external antenna system designed to improve the wireless performance of devices operating on LTE networks. It connects directly to the cellular modem or embedded communication module via an SMA connector, providing enhanced signal reception and transmission capabilities.

How It Works:
The antenna captures radio frequency (RF) signals from nearby cellular towers and transmits them to the connected device through the coaxial cable. Conversely, it radiates outgoing signals from the device to the network, ensuring optimal communication efficiency. The low-loss cable and impedance-matched design minimize signal degradation, while the high-gain antenna element amplifies weak signals for stable connectivity.

Use Cases & Applications:
- Industrial IoT gateways and remote monitoring systems
- Embedded computing platforms requiring cellular connectivity
- Smart grid and energy management systems
- Transportation and fleet management solutions
- Environmental monitoring and telemetry stations
- Remote data acquisition and control systems
- Backup communication links for critical infrastructure

Compatibility:
The 4G/LTE-EA Package is compatible with all Artila devices equipped with SMA antenna connectors, including the Matrix-700, Matrix-710, Matrix-750, and Matrix-760 series, as well as other LTE-enabled embedded systems. It can also be used with third-party LTE routers, modems, and M2M communication devices that support standard 50 Ω SMA interfaces.

---

### 5. Components & Accessories

Included Items:
- 1 × 4G/LTE External Antenna (Model: 4G/LTE-EA)
- 1 × Coaxial Cable (1.5 m, RG174 type, SMA Male connector)
- 1 × Mounting Base (magnetic or adhesive, depending on variant)
- 1 × Quick Installation Guide

Optional Accessories:
- Extension cable assemblies (3 m, 5 m, or 10 m lengths)
- SMA-to-RP-SMA or SMA-to-TS9 adapters for device compatibility
- Wall or pole mounting brackets for outdoor installations
- Weatherproof sealing kit for outdoor use
- LTE signal booster or amplifier (optional accessory for extended range)

Connectors & Interfaces:
- Primary Connector: SMA Male (standard)
- Optional Connectors: RP-SMA, FME, or N-type (custom order)
- Cable Interface: 50 Ω coaxial

---

### 6. Installation & Setup

Requirements:
- Device with SMA female antenna port
- LTE-enabled communication module or modem
- Suitable mounting surface (metallic for magnetic base, flat for adhesive mount)

Mounting Options:
1. Magnetic Mount: Ideal for metallic surfaces such as enclosures or vehicle roofs.
2. Adhesive Mount: Suitable for non-metallic surfaces; uses industrial-grade adhesive pad.
3. Screw Mount: Provides permanent installation for outdoor or vibration-prone environments.

Installation Steps:
1. Identify the optimal antenna placement for maximum signal strength (typically near a window or elevated position).
2. Mount the antenna using the chosen method.
3. Connect the SMA connector to the device’s LTE antenna port.
4. Power on the device and verify signal strength through the system interface.
5. Adjust antenna orientation if necessary to optimize performance.

Configuration:
No software configuration is required. The antenna operates as a passive component and automatically enhances the device’s LTE signal reception and transmission.

---

### 7. Performance & Capabilities

Signal Enhancement:
The 4G/LTE-EA antenna provides a gain of up to 5 dBi, significantly improving signal reception in low-coverage areas. This results in reduced latency, higher data throughput, and more stable connections.

Speed & Data Throughput:
When paired with LTE Cat 4 or higher modems, the antenna supports data rates up to 150 Mbps (downlink) and 50 Mbps (uplink), depending on network conditions and device capabilities.

Efficiency:
The antenna’s low VSWR ensures efficient power transfer, minimizing reflection losses and maximizing effective radiated power.

Coverage:
Supports global LTE frequency bands, making it suitable for deployment in multiple regions without requiring hardware modification.

Limitations:
- Performance may vary depending on environmental factors such as building materials, interference, and distance from the cellular tower.
- Requires proper grounding and weatherproofing for outdoor installations.
- Not designed for 5G NR frequencies (sub-6 GHz or mmWave).

---

### 8. Standards & Compliance

The 4G/LTE-EA Package adheres to international standards for RF performance, safety, and environmental compliance.

Certifications:
- CE (Conformité Européenne): Ensures compliance with EU safety, health, and environmental protection standards.
- FCC Part 15: Meets U.S. Federal Communications Commission requirements for unintentional radiators.
- RoHS (Restriction of Hazardous Substances): Free from lead, mercury, cadmium, and other restricted materials.
- REACH Compliance: Conforms to EU regulations on chemical substances.

Industry Standards:
- 3GPP LTE Standards: Compatible with LTE Release 8 and above.
- IEC 60068: Environmental testing standards for temperature and humidity resistance.
- ISO 9001 Manufacturing: Produced under certified quality management systems.

Safety & Environmental Compliance:
- Flame-retardant housing materials (UL94-V0 rated).
- Designed for electromagnetic compatibility (EMC) with industrial equipment.
- Meets environmental durability standards for outdoor use.

---

### 9. Additional Information

Warranty:
The Artila 4G/LTE-EA Package is covered by a one-year limited warranty against manufacturing defects. Extended warranty options are available upon request.

Technical Support:
Artila provides comprehensive technical support, including installation guidance, compatibility verification, and troubleshooting assistance. Support is available via email, online documentation, and authorized distributors.

Maintenance:
The antenna requires minimal maintenance. For outdoor installations, periodic inspection is recommended to ensure the integrity of the mounting and cable connections. Clean the antenna surface with a soft, dry cloth to remove dust or debris.

Firmware & Updates:
As a passive component, the antenna does not require firmware updates. However, Artila periodically releases compatibility notes and integration guides for new device models.

Service & Replacement:
Replacement antennas and cables are available through Artila’s authorized service centers. Custom cable lengths and connector types can be ordered for specific project requirements.

Environmental Considerations:
The product is designed for long-term reliability and recyclability. All materials comply with environmental directives, and packaging is made from recyclable materials.

Typical Deployment Scenarios:
- Industrial automation systems requiring reliable LTE connectivity
- Smart city infrastructure (traffic monitoring, environmental sensors)
- Remote data loggers and telemetry units
- Mobile and vehicular communication systems
- Backup communication links for SCADA and control networks

---

### Summary

The Artila 4G/LTE-EA Package is a high-performance, industrial-grade antenna and cable assembly engineered to deliver reliable 4G/LTE connectivity for embedded and IoT applications. With its robust construction, wide frequency coverage, and flexible installation options, it provides a cost-effective solution for enhancing wireless communication in demanding environments. The package’s compatibility with Artila’s embedded systems and other LTE-enabled devices makes it an essential accessory for industrial networking, remote monitoring, and M2M communication projects.

---
