Comprehensive Product Summary: ADLINK PCI-9820D/128 High-Speed PCI Digitizer

---

### 1. Product Overview

Product Name: PCI-9820D/128
Model: PCI-9820D
Series: NuDAQ PCI Digitizer Series
Article Number: PCI-9820D/128
Manufacturer: ADLINK Technology Inc.
Manufacturer Website: [www.adlinktech.com](http://www.adlinktech.com)
Product Type: 2-Channel, 14-bit, High-Speed PCI Analog-to-Digital (A/D) Digitizer Card with Onboard SDRAM

The ADLINK PCI-9820D/128 is a high-performance PCI-based digitizer designed for high-speed waveform acquisition and signal digitization. It provides simultaneous sampling on two analog input channels at up to 65 MS/s per channel, or up to 130 MS/s in single-channel “ping-pong” mode. The board integrates deep onboard SDRAM memory (128 MB standard, expandable to 512 MB) for extended data capture and supports scatter-gather DMA for efficient data transfer to host memory.

---

### 2. Key Features

- High-Speed Sampling:
- 65 MS/s per channel (dual-channel mode)
- 130 MS/s in single-channel ping-pong mode

- High Resolution:
- 14-bit analog-to-digital conversion for precise waveform capture

- Deep Onboard Memory:
- 128 MB SDRAM standard, expandable to 512 MB via 144-pin SODIMM
- 3k-sample FIFO buffer for real-time streaming

- Flexible Input Configuration:
- Two simultaneous-sampled, single-ended analog input channels
- Programmable input ranges: ±1 V or ±5 V
- Selectable input impedance: 50 Ω or 1.5 MΩ

- Wide Bandwidth:
- ≥30 MHz (-3 dB) analog input bandwidth

- Advanced Triggering:
- Supports software, analog, digital, and SSI (System Synchronization Interface) triggers
- Trigger modes: pre-trigger, post-trigger, middle-trigger, delay-trigger
- Programmable trigger thresholds and slopes (rising/falling)
- Repeated trigger acquisition with 2-cycle rearming interval

- Multiple Device Synchronization:
- SSI bus for clock and trigger synchronization across multiple PCI-9820 boards

- Auto-Calibration:
- Fully automatic offset and gain calibration using onboard reference
- Calibration constants stored in EEPROM

- Software Support:
- Drivers for Windows (WD-DASK), Linux (WD-DASK/X), and LabVIEW® (WD-LVIEW)
- ActiveX controls (WD-OCX) and DAQBench visualization tools

- Compact PCI Form Factor:
- Half-size PCI card (175 mm × 107 mm)
- Universal PCI interface (3.3 V / 5 V signaling)

---

### 3. Technical Specifications

Analog Input
- Channels: 2 simultaneous-sampled, single-ended
- Resolution: 14 bits
- Sampling Rate:
- 65 MS/s per channel (dual-channel)
- 130 MS/s (single-channel ping-pong mode)
- Bandwidth: ≥30 MHz (-3 dB)
- Input Ranges: ±1 V, ±5 V (software programmable)
- Input Coupling: DC
- Input Impedance: 50 Ω or 1.5 MΩ (solder-selectable)
- Overvoltage Protection:
- ±5 V range: ±14 V
- ±1 V range: ±5 V
- Crosstalk: -80 dB (DC to 1 MHz)
- THD: -75 dB
- SNR: 66 dB (±5 V), 62 dB (±1 V)
- SFDR: 75 dB
- FIFO Buffer: 3 kSamples
- Onboard Memory: 128 MB SDRAM (standard), up to 512 MB (optional)

Timebase System
- Internal Clock: 60 MHz
- External Clock Input: SMB connector, 50 Ω, AC-coupled
- Input amplitude: 1–2 Vpp
- Frequency range: 500 kHz–65 MHz
- Overvoltage protection: 2.5 Vpp
- External Sine Wave Clock: Supported
- SSI Timebase: Synchronization across multiple boards

Triggering
- Sources: Software, analog, digital, SSI
- Modes: Pre-trigger, post-trigger, middle-trigger, delay-trigger
- Analog Trigger:
- Source: CH0 or CH1
- Slope: Rising/falling
- Sensitivity: 256 steps across full-scale range
- Coupling: DC
- Digital Trigger:
- Source: External SMB connector
- Compatibility: 5 V TTL
- Minimum pulse width: 10 ns
- Repeated Trigger Interval: 2 timebase cycles
- Pre/Post Trigger Depth: Up to full memory capacity (128 MB or 512 MB)

Calibration
- Reference Voltage: +5.000 V
- Temperature Drift: ±2 ppm/°C
- Stability: 6 ppm/1000 hours
- Warm-up Time: 15 minutes

General Specifications
- Dimensions: 175 mm × 107 mm (excluding connectors)
- Connectors:
- 2 × BNC (analog inputs)
- 2 × SMB (external trigger and timebase)
- Operating Temperature: 0–50 °C
- Storage Temperature: -20–80 °C
- Humidity: 5–95% RH, non-condensing
- Power Requirements:
- +5 V @ 895 mA
- +12 V @ 295 mA
- +3.3 V @ 310 mA (128 MB) / 430 mA (512 MB)

---

### 4. Functionality

The PCI-9820D/128 digitizer converts analog signals into high-resolution digital data for analysis and processing. It employs two 14-bit pipeline ADCs operating at up to 65 MS/s per channel. In single-channel “ping-pong” mode, both ADCs interleave to achieve up to 130 MS/s sampling.

Captured data is stored in onboard SDRAM, allowing long-duration waveform recording without PCI bus limitations. The scatter-gather DMA engine transfers data efficiently to host memory, while the 3k-sample FIFO enables real-time streaming for lower data rates.

Use Cases and Applications:
- Radar and sonar waveform capture
- Ultrasound and medical imaging
- Software-defined radio (SDR)
- RF and communication signal analysis
- Transient event recording
- Automated test equipment (ATE)
- Automotive and industrial signal monitoring
- Scientific and laboratory research

Compatibility:
- PCI 32-bit, 3.3 V/5 V universal slot
- Supported OS: Windows 98/NT/2000, Linux
- Supported software: LabVIEW®, ActiveX, DAQBench

---

### 5. Components & Accessories

Included Items:
- PCI-9820D/128 Digitizer Card
- ADLINK All-in-One Software CD
- Software Installation Guide
- User’s Manual

Optional Accessories:
- SMB-SMB-1M: 1-meter SMB-to-SMB cable
- SMB-BNC-1M: 1-meter SMB-to-BNC cable
- ACL-SSI-2: SSI synchronization cable for 2 devices
- ACL-SSI-3: SSI synchronization cable for 3 devices
- ACL-SSI-4: SSI synchronization cable for 4 devices

Connectors:
- CH0, CH1: BNC connectors for analog input
- CLK IN: SMB connector for external clock input
- TRG IO: SMB connector for external digital trigger
- SSI: 20-pin header for synchronization bus

---

### 6. Installation & Setup

System Requirements:
- Available PCI slot (32-bit, 3.3 V or 5 V)
- Compatible host PC with Windows or Linux OS
- Administrative privileges for driver installation

Installation Steps:
1. Power off the host system and discharge static electricity.
2. Insert the PCI-9820D/128 into an available PCI slot.
3. Secure the card and reconnect system power.
4. Install drivers from the ADLINK CD (WD-DASK, WD-DASK/X, or WD-LVIEW).
5. Verify installation using the `PCI_SCAN` utility.

Configuration:
- Plug-and-play PCI configuration (no jumpers required).
- Input impedance selectable via solder jumpers J6 (CH0) and J7 (CH1):
- Closed = 50 Ω (default)
- Open = 1.5 MΩ

Mounting:
- Half-size PCI card suitable for standard desktop or industrial PCs.
- Ensure adequate airflow for thermal stability.

---

### 7. Performance & Capabilities

Sampling Performance:
- Dual-channel: 65 MS/s per channel
- Single-channel (ping-pong): 130 MS/s
- Internal clock: 60 MHz; external clock up to 65 MHz

Data Throughput:
- Maximum raw data rate: 240 MB/s (2 channels × 65 MS/s × 2 bytes)
- PCI bus transfer via scatter-gather DMA

Memory Performance:
- 128 MB SDRAM standard (expandable to 512 MB)
- 3k-sample FIFO for continuous streaming

Signal Fidelity:
- THD: -75 dB
- SNR: up to 66 dB
- SFDR: 75 dB
- Crosstalk: -80 dB

Limitations:
- PCI bandwidth (132 MB/s) limits continuous streaming at full rate; onboard memory compensates.
- Ping-pong mode available only on CH0.

---

### 8. Standards & Compliance

- Bus Interface: PCI 2.2 compliant (32-bit, 33 MHz)
- Electrical Compliance: Universal PCI signaling (3.3 V / 5 V)
- Environmental:
- Operating: 0–50 °C, 10–90% RH non-condensing
- Storage: -20–80 °C
- Safety & EMC: Designed for industrial and laboratory environments
- Calibration Reference: ±2 ppm/°C drift, 6 ppm/1000 hr stability

---

### 9. Additional Information

Ordering Information:
- PCI-9820D/128-0: 2-CH 65 MS/s 14-bit Digitizer with 128 MB SDRAM
- PCI-9820D/512-0: 2-CH 65 MS/s 14-bit Digitizer with 512 MB SDRAM

Warranty:
- 2-year limited warranty from ADLINK Technology Inc.
- Covers manufacturing defects and hardware failures under normal use.
- Excludes damage from misuse, improper installation, or environmental factors.

Support & Maintenance:
- Technical support via email: service@adlinktech.com
- RMA service available through ADLINK’s website
- Software updates and documentation downloadable from [www.adlinktech.com](http://www.adlinktech.com)

Maintenance Recommendations:
- Perform auto-calibration after 15-minute warm-up or when environmental conditions change.
- Keep connectors clean and avoid electrostatic discharge during handling.

Software Updates:
- WD-DASK and WD-DASK/X driver updates available online.
- LabVIEW® and ActiveX driver libraries included on CD.

---

### Summary

The ADLINK PCI-9820D/128 is a robust, high-speed PCI digitizer optimized for precision waveform acquisition and analysis. With dual 14-bit ADCs, flexible triggering, deep onboard memory, and advanced synchronization capabilities, it is ideal for demanding applications in radar, communications, and scientific measurement. Its universal PCI interface, comprehensive software support, and auto-calibration features make it a versatile and reliable solution for engineers and researchers requiring high-resolution, high-speed data acquisition.
