Comprehensive Product Summary: ADLINK PXIe-3935/M8G PXI Express Embedded Controller

---

### 1. Product Overview

Product Name: PXIe-3935/M8G
Model: PXIe-3935/M8G
Series: PXIe-3935 PXI Express Embedded Controller Series
Article Number: PXIe-3935/M8G
Manufacturer: ADLINK Technology, Inc.
Part Number: 50-17052-1000
Manual Revision: 2.00 (March 24, 2017)

The ADLINK PXIe-3935/M8G is a 3U PXI Express embedded controller designed for hybrid PXI Express-based test and measurement systems. It integrates an Intel® Celeron® 2000E 2.20GHz processor and Mobile Intel® HM86 chipset, providing a cost-effective yet high-performance platform for modular instrumentation, data acquisition, and automated test applications. The controller is engineered for reliability, flexibility, and ease of integration within PXI Express chassis environments.

---

### 2. Key Features

- Processor and Architecture:
Equipped with an Intel® Celeron® 2000E dual-core processor running at 2.20GHz, offering a balance between performance and energy efficiency. The Direct Media Interface (DMI) provides 5 GT/s bandwidth per direction for high-speed data transfer between CPU and chipset.

- PXI Express Compliance:
Fully compliant with PXI-5 PXI Express Hardware Specification Revision 1.0, ensuring interoperability with PXI Express and hybrid PXI systems.

- Display and Graphics:
Supports dual independent displays via two DisplayPort outputs, each capable of 3840×2160 resolution at 60Hz. DisplayPort-to-DVI-D adapters (up to 1920×1200 @60Hz) are supported for legacy monitors.

- Memory:
Dual-channel DDR3L SODIMM slots supporting up to 16GB of 1333/1600MHz non-ECC unbuffered memory. The PXIe-3935/M8G configuration includes 8GB preinstalled.

- Storage:
Integrated 2.5" 500GB SATA hard drive (SATA 3Gb/s, AHCI support). Optional configurations include 240GB SSD for enhanced performance and extended temperature range.

- I/O Interfaces:
- 2 × USB 3.0 ports
- 4 × USB 2.0 ports
- 2 × Gigabit Ethernet ports (Intel® I210 and I217 controllers)
- 1 × RS-232/422/485 D-SUB9 serial port
- 1 × IEEE488 GPIB controller with Micro-D 25-pin connector
- 1 × SMB trigger I/O connector for PXI trigger bus routing

- System Throughput:
Up to 8 GB/s maximum system bandwidth.

- Reliability Enhancements:
Dual BIOS support for backup and recovery, easily replaceable CMOS battery, and user-upgradable storage and memory modules.

- Environmental Robustness:
Designed for industrial environments with operating temperature up to 55°C (SSD configuration) and vibration/shock resistance per EN 61326-1 standards.

---

### 3. Technical Specifications

| Parameter | Specification |
|----------------|-------------------|
| Processor | Intel® Celeron® 2000E, 2.20GHz |
| Chipset | Mobile Intel® HM86 |
| Memory | 8GB DDR3L 1333/1600MHz (expandable to 16GB) |
| Storage | 500GB SATA HDD (optional 240GB SSD) |
| Display Outputs | 2 × DisplayPort (3840×2160 @60Hz) |
| DVI Support | Up to 2 × DP-to-DVI-D adapters (1920×1200 @60Hz) |
| Ethernet | 2 × RJ-45 (Intel® I210 + I217), LEDs for link/activity |
| USB Ports | 2 × USB 3.0, 4 × USB 2.0 |
| Serial Port | 1 × RS-232/422/485 (D-SUB9 male) |
| GPIB | Built-in IEEE488 controller, Micro-D 25-pin connector |
| Trigger I/O | 1 × SMB connector for PXI trigger bus routing |
| PXI Slot Requirement | 1 system slot + 3 controller expansion slots |
| Form Factor | 3U/4-slot PXI Express module |
| Dimensions | 80.94 mm (W) × 128.7 mm (H) × 212.9 mm (D) |
| Weight | Approx. 1.0 kg (2.2 lbs) |
| Operating Temperature | 0–50°C (HDD), 0–55°C (SSD) |
| Storage Temperature | -20–70°C |
| Humidity | 5–95% non-condensing |
| Shock | 30 G, half-sine, 11 ms |
| Vibration | Operating: 0.21 Grms (5–500Hz); Non-operating: 2.46 Grms |
| Power Requirements | +3.3V @3.3A, +5V @38A, +12V @1.2A (42.5W total) |
| Compliance | FCC Class A, CE EN 61326-1 |
| Software Support | Windows 7 (32/64-bit) |

---

### 4. Functionality

The PXIe-3935/M8G serves as the central processing and control unit within a PXI Express chassis. It manages communication between PXI modules, external instruments, and host systems through its integrated interfaces.

Operational Overview:
- The controller boots from its onboard HDD/SSD and runs a Windows-based OS.
- Dual DisplayPort outputs enable simultaneous multi-monitor operation for test visualization and control.
- The built-in GPIB controller allows direct connection to IEEE488 instruments without requiring an external GPIB interface.
- The SMB trigger I/O connector enables routing of external or software-generated triggers to/from the PXI trigger bus, supporting synchronization across multiple PXI modules.
- Dual Gigabit Ethernet ports facilitate LAN connectivity and LXI instrument control.

Use Cases:
- Automated test equipment (ATE)
- Data acquisition and signal analysis
- Instrument control and measurement automation
- Industrial monitoring and control systems
- Research and development test benches

Compatibility:
- Compatible with PXI Express and hybrid PXI chassis.
- Supports standard PXI trigger and timing signals.
- Works with ADLINK’s PXI software drivers and trigger I/O libraries.

---

### 5. Components & Accessories

Included Items:
- PXIe-3935/M8G controller (preinstalled 8GB RAM, 500GB HDD)
- 1 × DisplayPort-to-DVI-D cable
- Quick Start Guide

Optional Accessories:
- ACL-IEEE488-MD1-A: 1-meter Micro-D to GPIB cable
- Replacement CMOS battery (CR2032)
- Optional 240GB SSD upgrade
- Additional DDR3L SODIMM modules (up to 16GB total)

Connectors:
- Front panel includes all I/O ports: DisplayPort, USB, Ethernet, GPIB, RS-232/422/485, and trigger I/O.
- Onboard connectors: SATA port, CMOS clear switch, and system battery socket.

---

### 6. Installation & Setup

Requirements:
- PXI Express chassis with available system slot (Slot 1)
- Anti-static handling equipment (mat and wrist strap)
- Phillips screwdriver for securing front panel screws

Installation Steps:
1. Power off the PXI chassis and disconnect power.
2. Insert the PXIe-3935/M8G into the system slot, aligning with guide rails.
3. Secure the module using the front panel screws.
4. Connect peripherals (monitors, USB devices, Ethernet, GPIB instruments).
5. Power on the chassis and configure BIOS/boot settings as needed.

Operating System Installation:
- Supports Windows 7 (32/64-bit).
- Bootable from USB CD-ROM, USB flash drive, or external HDD.
- Drivers available from ADLINK’s website for chipset, graphics, Ethernet, GPIB, USB 3.0, and PXI trigger functions.

Maintenance:
- HDD/SSD and battery are user-replaceable.
- CMOS can be cleared via onboard switch (SW1).
- Dual BIOS ensures recovery in case of firmware corruption.

---

### 7. Performance & Capabilities

- System Throughput: 8 GB/s maximum PXI Express bandwidth.
- Data Transfer: GPIB up to 1.5 MB/s with onboard 2KB FIFO buffer.
- Display Performance: Dual 4K (3840×2160 @60Hz) or dual 1080p displays.
- Network Performance: Dual Gigabit Ethernet with Wake-on-LAN support.
- Trigger Control: Programmable routing between SMB connector, PXI trigger bus, and software triggers.
- Reliability: Dual BIOS, industrial-grade components, and robust mechanical design ensure high uptime.
- Limitations: Limited to Windows 7 OS officially; newer OS support requires ADLINK validation.

---

### 8. Standards & Compliance

- PXI/PXIe Standards: PXI-5 PXI Express Hardware Specification Rev. 1.0 compliant.
- Electrical Safety & EMC:
- FCC Class A (EN 61326-1)
- CE Mark (Immunity and Emissions per EN 61326-1)
- Environmental Compliance:
- RoHS (Restriction of Hazardous Substances)
- WEEE (Waste Electrical and Electronic Equipment)
- Shock & Vibration:
- Meets industrial-grade mechanical durability standards.
- Quality Assurance:
- Manufactured under ADLINK’s ISO-certified quality management system.

---

### 9. Additional Information

Warranty & Support:
- Standard ADLINK limited warranty (contact regional office for terms).
- Technical support via ADLINK’s “Ask an Expert” portal: [http://askanexpert.adlinktech.com](http://askanexpert.adlinktech.com)
- Global service centers in Taiwan, USA, China, Japan, Germany, France, Korea, Singapore, India, Israel, and the UK.

Maintenance & Serviceability:
- User-serviceable HDD/SSD and battery.
- BIOS recovery via backup BIOS flash.
- CMOS reset and BIOS configuration accessible through onboard switches.

Software & Driver Updates:
- Drivers and utilities downloadable from [www.adlinktech.com](http://www.adlinktech.com)
- PXIe Trigger I/O library included for advanced trigger routing and synchronization programming.

Environmental Responsibility:
- ADLINK adheres to RoHS and WEEE directives.
- Customers are encouraged to recycle end-of-life products responsibly.

Safety Notes:
- Operate within specified temperature and humidity ranges.
- Avoid exposure to liquids, excessive dust, or vibration beyond rated limits.
- Follow anti-static precautions during installation or maintenance.

---

### Summary

The ADLINK PXIe-3935/M8G is a compact, high-reliability PXI Express embedded controller optimized for test and measurement automation. Combining an Intel® Celeron® 2000E processor, dual-display capability, extensive I/O interfaces, and integrated GPIB and trigger control, it provides a versatile and cost-effective solution for PXI-based instrumentation systems. Its modular design, robust environmental tolerance, and comprehensive software support make it ideal for laboratory, manufacturing, and field test environments requiring dependable PXI Express control and data management.
