Comprehensive Product Summary: ADLINK PXIe‑3935/M8G/SSD
### 1. Product Overview
Product Name: PXIe‑3935/M8G/SSD
Model: PXIe‑3935
Series: PXI Express Embedded Controller Series
Article Number: PXIe‑3935/M8G/SSD
Manufacturer: ADLINK Technology, Inc.
Form Factor: 3U PXI Express (PXIe) System Controller
Processor Platform: Intel® Celeron® 2000E 2.20 GHz
Chipset: Mobile Intel® HM86
The ADLINK PXIe‑3935/M8G/SSD is a 3U PXI Express embedded controller designed for hybrid PXI Express‑based test and measurement systems. It integrates an Intel® Celeron® 2000E dual‑core processor, 8 GB DDR3L memory, and a 240 GB SATA solid‑state drive (SSD). The controller provides a rugged, stable, and cost‑effective computing platform for automated test, data acquisition, and instrumentation control applications.
### 2. Key Features
- Processor and Architecture:
Intel® Celeron® 2000E dual‑core CPU at 2.20 GHz with 5 GT/s DMI bandwidth, providing a balanced combination of performance and energy efficiency.
- PXI Express Compliance:
Fully compliant with PXI‑5 PXI Express Hardware Specification Rev. 1.0, ensuring interoperability with PXI and PXIe chassis and modules.
- High System Throughput:
Supports up to 8 GB/s maximum system bandwidth for high‑speed data transfer between controller and PXIe backplane.
- Dual Independent Display Support:
Two DisplayPort outputs supporting resolutions up to 3840 × 2160 @ 60 Hz; compatible with DisplayPort‑to‑DVI‑D adapters (up to 1920 × 1200 @ 60 Hz).
- Comprehensive I/O Connectivity:
- 2 × USB 3.0 ports
- 4 × USB 2.0 ports
- 2 × Gigabit Ethernet ports (Intel® I210 and I217 controllers)
- 1 × RS‑232/422/485 serial port (D‑SUB 9)
- 1 × Micro‑D 25‑pin GPIB (IEEE 488) connector
- 1 × SMB trigger I/O connector for PXI trigger bus routing
- Integrated GPIB Controller:
Built‑in IEEE 488 controller with up to 1.5 MB/s transfer rate, 2 KB FIFO buffer, and NI‑488.2‑compatible driver API.
- Dual BIOS Support:
Redundant BIOS architecture for system recovery in case of primary BIOS corruption.
- Upgradeable and Serviceable Design:
Easily replaceable CMOS battery, accessible SODIMM slots (up to 16 GB), and removable 2.5″ SATA storage device.
- Environmental Robustness:
Operating temperature up to 55 °C (SSD configuration), shock resistance up to 30 G, and vibration tolerance up to 0.21 Grms (operating).
- Software Compatibility:
Supports Windows 7 x86/x64; additional OS support available upon request.
### 3. Technical Specifications
| Category | Specification |
|---------------|------------------|
| Processor | Intel® Celeron® 2000E, dual‑core, 2.20 GHz |
| Chipset | Mobile Intel® HM86 |
| Memory | 8 GB DDR3L 1333/1600 MHz SODIMM (expandable to 16 GB, dual‑channel) |
| Storage | 240 GB SATA SSD (2.5″, SATA 3 Gb/s, AHCI support) |
| Display Outputs | 2 × DisplayPort (3840 × 2160 @ 60 Hz); supports DP‑to‑DVI‑D adapters (1920 × 1200 @ 60 Hz) |
| Ethernet | 2 × Gigabit Ethernet (Intel® I210 + I217), RJ‑45 with link/activity LEDs |
| USB Ports | 2 × USB 3.0 (Type A), 4 × USB 2.0 (Type A) |
| Serial Port | 1 × RS‑232/422/485 D‑SUB 9 male |
| GPIB | IEEE 488 controller, Micro‑D 25‑pin connector (ACL‑IEEE488‑MD1‑A cable required) |
| Trigger I/O | 1 × SMB connector for external trigger routing to/from PXI trigger bus |
| PXI Slot Requirement | 1 system slot + 3 controller expansion slots |
| Form Factor | 3U / 4‑slot PXI standard |
| Dimensions | 80.94 (W) × 128.7 (H) × 212.9 (D) mm (3.15 × 5.07 × 8.38 in.) |
| Weight | Approx. 1 kg (2.2 lb) |
| Operating Temperature | 0 – 55 °C (SSD) / 0 – 50 °C (HDD) |
| Storage Temperature | −20 – 70 °C |
| Relative Humidity | 5 – 95 % (non‑condensing) |
| Shock | 30 G, half‑sine, 11 ms pulse |
| Vibration | Operating: 5–500 Hz, 0.21 Grms (3 axes); Non‑operating: 2.46 Grms |
| Power Requirements | +3.3 V @ 3.3 A, +5 V @ 38 A, +12 V @ 1.2 A (≈ 42.5 W total) |
| Compliance | FCC Class A, EN 61326‑1 (CE EMC and Immunity) |
### 4. Functionality
The PXIe‑3935/M8G/SSD functions as the embedded system controller within a PXI Express chassis. It manages communication between the host system and PXI/PXIe modules through the PXIe backplane, providing deterministic control, data acquisition, and synchronization.
Operational Overview:
- The controller boots from its onboard SSD and runs a standard operating system (e.g., Windows 7 64‑bit).
- It interfaces with PXI modules via the PXIe backplane using PCI Express signaling.
- External instruments can be connected through GPIB, USB, Ethernet, or serial interfaces.
- The SMB trigger I/O allows routing of external or software‑generated triggers to synchronize PXI modules.
Typical Applications:
- Automated Test Equipment (ATE) systems
- Data acquisition and signal analysis
- Instrument control for GPIB/LXI devices
- Industrial measurement and monitoring
- Research and laboratory automation setups
Compatibility:
- Compatible with PXI Express and hybrid PXI chassis from ADLINK and other PXI‑5‑compliant vendors.
- Supports DisplayPort, DVI‑D (via adapter), USB peripherals, and standard Ethernet networks.
### 5. Components & Accessories
Included Items:
- PXIe‑3935/M8G/SSD controller (pre‑installed 8 GB RAM + 240 GB SSD)
- 1 × DisplayPort‑to‑DVI‑D cable (bundled)
- Quick Start Guide
Optional Accessories:
- ACL‑IEEE488‑MD1‑A: 1 m Micro‑D 25‑pin to GPIB cable for instrument connection
- Replacement CMOS battery (CR2032 3 V lithium)
- Additional DDR3L SODIMM modules (up to 16 GB total)
- Alternative SATA HDD (500 GB or greater)
Connectors on Front Panel:
- 2 × DisplayPort
- 2 × USB 3.0 (Type A)
- 4 × USB 2.0 (Type A)
- 2 × RJ‑45 Gigabit Ethernet
- 1 × RS‑232/422/485 D‑SUB 9
- 1 × Micro‑D 25 GPIB
- 1 × SMB Trigger I/O
- Reset button and LED status indicators (Power, HDD, User)
### 6. Installation & Setup
Requirements:
- PXI Express chassis with one system slot and three adjacent expansion slots.
- Anti‑static handling equipment (wrist strap, mat).
- Phillips screwdriver for securing front‑panel screws.
Installation Steps:
1. Power off the PXIe chassis and disconnect power.
2. Locate the system controller slot (Slot 1).
3. Align the controller with the chassis card guides and slide it in carefully.
4. Engage the red locking lever and secure the four front‑panel screws.
5. Connect peripherals (display, Ethernet, USB, GPIB, etc.).
6. Power on the chassis and install the operating system if required.
Operating System Installation:
- Supported OS: Windows 7 32/64‑bit (others on request).
- Bootable devices: USB CD‑ROM, USB flash drive, USB HDD.
- BIOS boot order configurable via Boot Setup Menu.
Driver Installation Sequence:
1. Chipset driver
2. Graphics driver
3. Ethernet driver
4. GPIB driver
5. Management engine driver
6. PXIe Trigger driver
7. USB 3.0 driver
Maintenance Tasks:
- Storage Replacement: Remove five screws securing the 2.5″ drive bracket, replace SSD/HDD, and reinstall.
- Battery Replacement: Replace CR2032 cell following anti‑static precautions.
- CMOS Reset: Toggle onboard switch SW1 to “Clear” for 5 seconds, then return to “Normal.”
- Backup BIOS: Automatic failover to secondary BIOS in case of corruption.
### 7. Performance & Capabilities
- System Throughput: Up to 8 GB/s PXIe backplane bandwidth.
- Data Interfaces: High‑speed USB 3.0 (5 Gb/s) and Gigabit Ethernet (1 Gb/s each).
- Display Performance: Dual 4K (3840 × 2160 @ 60 Hz) independent outputs.
- Trigger I/O: Programmable routing between external SMB connector and PXIe trigger bus; supports software‑generated TTL triggers.
- GPIB Performance: Up to 1.5 MB/s transfer rate, connects up to 14 instruments.
- Reliability: Dual BIOS redundancy and industrial‑grade components ensure high uptime.
- Environmental Limits: Operates reliably in 0–55 °C ambient (SSD version) and high humidity environments (≤ 95 % RH non‑condensing).
Limitations:
- Memory addressing above 4 GB requires a 64‑bit OS.
- OS installation via USB CD‑ROM only (some limitations on USB 3.0 boot media).
- PXIe trigger functions require ADLINK driver library installation.
### 8. Standards & Compliance
- PXI/PXIe Standard: PXI‑5 PXI Express Hardware Specification Rev. 1.0
- Electrical Safety & EMC:
- FCC Class A (EN 61326‑1 Emission Compliance)
- CE Mark (EN 61326‑1 Immunity Compliance)
- Environmental Directives:
- RoHS (Restriction of Hazardous Substances)
- WEEE (Waste Electrical and Electronic Equipment)
- Quality & Reliability:
- Designed and manufactured under ADLINK’s ISO 9001 quality management system.
- Complies with industrial shock and vibration standards for PXI controllers.
### 9. Additional Information
Warranty & Support:
- Standard ADLINK limited hardware warranty (terms vary by region).
- Technical support available via ADLINK Ask‑an‑Expert portal (http://askanexpert.adlinktech.com).
- Global service centers in Taiwan, USA, China, Europe, Japan, Korea, Singapore, and India.
Maintenance & Serviceability:
- User‑replaceable storage and battery components.
- BIOS and firmware updates available from ADLINK website.
- Recommended preventive maintenance: periodic dust removal and connector inspection.
Environmental Responsibility:
- Fully RoHS and WEEE compliant.
- Designed for minimal environmental impact through energy‑efficient components and recyclable materials.
Safety Precautions:
- Operate only within specified temperature and humidity ranges.
- Avoid exposure to liquids and high heat sources.
- Disconnect power before installation or maintenance.
- Replace battery only with approved CR2032 type to avoid explosion risk.
BIOS & Configuration:
- BIOS Setup Utility accessible via <Delete> key at boot.
- Configurable parameters include boot order, USB settings, power management, and security passwords.
- Dual BIOS architecture provides automatic failover and manual recovery options.
Software Development & Trigger API:
- ADLINK provides a PXIe Trigger I/O Function Library for C/C++, Visual Basic, and Delphi.
- Functions include TRIG_Init, TRIG_SetSoftTrg, TRIG_Trigger_Route, and TRIG_GetDriverRevision.
- Enables software‑controlled trigger generation and routing between SMB connector and PXIe trigger bus lines (TRIG0–TRIG7).
Documentation:
- User’s Manual Rev. 2.00 (March 24, 2017, Part No. 50‑17052‑1000).
- Updated specifications available on ADLINK website (www.adlinktech.com).
### Summary
The ADLINK PXIe‑3935/M8G/SSD is a compact, high‑reliability PXI Express embedded controller optimized for cost‑sensitive test and measurement environments. It combines Intel® Celeron® processing power, robust I/O connectivity, and PXIe 8 GB/s bandwidth in a 3U form factor. With dual DisplayPort outputs, integrated GPIB and trigger I/O, and dual Gigabit Ethernet interfaces, it serves as a versatile controller for automated test systems, instrument control, and data acquisition applications.
Its rugged design, dual BIOS redundancy, and broad environmental tolerance make it suitable for industrial and laboratory deployments requiring long‑term stability and serviceability. The PXIe‑3935/M8G/SSD embodies ADLINK’s commitment to “Building Forward Together” by delivering a reliable, standards‑compliant platform for next‑generation PXI Express test solutions.
### 1. Product Overview
Product Name: PXIe‑3935/M8G/SSD
Model: PXIe‑3935
Series: PXI Express Embedded Controller Series
Article Number: PXIe‑3935/M8G/SSD
Manufacturer: ADLINK Technology, Inc.
Form Factor: 3U PXI Express (PXIe) System Controller
Processor Platform: Intel® Celeron® 2000E 2.20 GHz
Chipset: Mobile Intel® HM86
The ADLINK PXIe‑3935/M8G/SSD is a 3U PXI Express embedded controller designed for hybrid PXI Express‑based test and measurement systems. It integrates an Intel® Celeron® 2000E dual‑core processor, 8 GB DDR3L memory, and a 240 GB SATA solid‑state drive (SSD). The controller provides a rugged, stable, and cost‑effective computing platform for automated test, data acquisition, and instrumentation control applications.
### 2. Key Features
- Processor and Architecture:
Intel® Celeron® 2000E dual‑core CPU at 2.20 GHz with 5 GT/s DMI bandwidth, providing a balanced combination of performance and energy efficiency.
- PXI Express Compliance:
Fully compliant with PXI‑5 PXI Express Hardware Specification Rev. 1.0, ensuring interoperability with PXI and PXIe chassis and modules.
- High System Throughput:
Supports up to 8 GB/s maximum system bandwidth for high‑speed data transfer between controller and PXIe backplane.
- Dual Independent Display Support:
Two DisplayPort outputs supporting resolutions up to 3840 × 2160 @ 60 Hz; compatible with DisplayPort‑to‑DVI‑D adapters (up to 1920 × 1200 @ 60 Hz).
- Comprehensive I/O Connectivity:
- 2 × USB 3.0 ports
- 4 × USB 2.0 ports
- 2 × Gigabit Ethernet ports (Intel® I210 and I217 controllers)
- 1 × RS‑232/422/485 serial port (D‑SUB 9)
- 1 × Micro‑D 25‑pin GPIB (IEEE 488) connector
- 1 × SMB trigger I/O connector for PXI trigger bus routing
- Integrated GPIB Controller:
Built‑in IEEE 488 controller with up to 1.5 MB/s transfer rate, 2 KB FIFO buffer, and NI‑488.2‑compatible driver API.
- Dual BIOS Support:
Redundant BIOS architecture for system recovery in case of primary BIOS corruption.
- Upgradeable and Serviceable Design:
Easily replaceable CMOS battery, accessible SODIMM slots (up to 16 GB), and removable 2.5″ SATA storage device.
- Environmental Robustness:
Operating temperature up to 55 °C (SSD configuration), shock resistance up to 30 G, and vibration tolerance up to 0.21 Grms (operating).
- Software Compatibility:
Supports Windows 7 x86/x64; additional OS support available upon request.
### 3. Technical Specifications
| Category | Specification |
|---------------|------------------|
| Processor | Intel® Celeron® 2000E, dual‑core, 2.20 GHz |
| Chipset | Mobile Intel® HM86 |
| Memory | 8 GB DDR3L 1333/1600 MHz SODIMM (expandable to 16 GB, dual‑channel) |
| Storage | 240 GB SATA SSD (2.5″, SATA 3 Gb/s, AHCI support) |
| Display Outputs | 2 × DisplayPort (3840 × 2160 @ 60 Hz); supports DP‑to‑DVI‑D adapters (1920 × 1200 @ 60 Hz) |
| Ethernet | 2 × Gigabit Ethernet (Intel® I210 + I217), RJ‑45 with link/activity LEDs |
| USB Ports | 2 × USB 3.0 (Type A), 4 × USB 2.0 (Type A) |
| Serial Port | 1 × RS‑232/422/485 D‑SUB 9 male |
| GPIB | IEEE 488 controller, Micro‑D 25‑pin connector (ACL‑IEEE488‑MD1‑A cable required) |
| Trigger I/O | 1 × SMB connector for external trigger routing to/from PXI trigger bus |
| PXI Slot Requirement | 1 system slot + 3 controller expansion slots |
| Form Factor | 3U / 4‑slot PXI standard |
| Dimensions | 80.94 (W) × 128.7 (H) × 212.9 (D) mm (3.15 × 5.07 × 8.38 in.) |
| Weight | Approx. 1 kg (2.2 lb) |
| Operating Temperature | 0 – 55 °C (SSD) / 0 – 50 °C (HDD) |
| Storage Temperature | −20 – 70 °C |
| Relative Humidity | 5 – 95 % (non‑condensing) |
| Shock | 30 G, half‑sine, 11 ms pulse |
| Vibration | Operating: 5–500 Hz, 0.21 Grms (3 axes); Non‑operating: 2.46 Grms |
| Power Requirements | +3.3 V @ 3.3 A, +5 V @ 38 A, +12 V @ 1.2 A (≈ 42.5 W total) |
| Compliance | FCC Class A, EN 61326‑1 (CE EMC and Immunity) |
### 4. Functionality
The PXIe‑3935/M8G/SSD functions as the embedded system controller within a PXI Express chassis. It manages communication between the host system and PXI/PXIe modules through the PXIe backplane, providing deterministic control, data acquisition, and synchronization.
Operational Overview:
- The controller boots from its onboard SSD and runs a standard operating system (e.g., Windows 7 64‑bit).
- It interfaces with PXI modules via the PXIe backplane using PCI Express signaling.
- External instruments can be connected through GPIB, USB, Ethernet, or serial interfaces.
- The SMB trigger I/O allows routing of external or software‑generated triggers to synchronize PXI modules.
Typical Applications:
- Automated Test Equipment (ATE) systems
- Data acquisition and signal analysis
- Instrument control for GPIB/LXI devices
- Industrial measurement and monitoring
- Research and laboratory automation setups
Compatibility:
- Compatible with PXI Express and hybrid PXI chassis from ADLINK and other PXI‑5‑compliant vendors.
- Supports DisplayPort, DVI‑D (via adapter), USB peripherals, and standard Ethernet networks.
### 5. Components & Accessories
Included Items:
- PXIe‑3935/M8G/SSD controller (pre‑installed 8 GB RAM + 240 GB SSD)
- 1 × DisplayPort‑to‑DVI‑D cable (bundled)
- Quick Start Guide
Optional Accessories:
- ACL‑IEEE488‑MD1‑A: 1 m Micro‑D 25‑pin to GPIB cable for instrument connection
- Replacement CMOS battery (CR2032 3 V lithium)
- Additional DDR3L SODIMM modules (up to 16 GB total)
- Alternative SATA HDD (500 GB or greater)
Connectors on Front Panel:
- 2 × DisplayPort
- 2 × USB 3.0 (Type A)
- 4 × USB 2.0 (Type A)
- 2 × RJ‑45 Gigabit Ethernet
- 1 × RS‑232/422/485 D‑SUB 9
- 1 × Micro‑D 25 GPIB
- 1 × SMB Trigger I/O
- Reset button and LED status indicators (Power, HDD, User)
### 6. Installation & Setup
Requirements:
- PXI Express chassis with one system slot and three adjacent expansion slots.
- Anti‑static handling equipment (wrist strap, mat).
- Phillips screwdriver for securing front‑panel screws.
Installation Steps:
1. Power off the PXIe chassis and disconnect power.
2. Locate the system controller slot (Slot 1).
3. Align the controller with the chassis card guides and slide it in carefully.
4. Engage the red locking lever and secure the four front‑panel screws.
5. Connect peripherals (display, Ethernet, USB, GPIB, etc.).
6. Power on the chassis and install the operating system if required.
Operating System Installation:
- Supported OS: Windows 7 32/64‑bit (others on request).
- Bootable devices: USB CD‑ROM, USB flash drive, USB HDD.
- BIOS boot order configurable via Boot Setup Menu.
Driver Installation Sequence:
1. Chipset driver
2. Graphics driver
3. Ethernet driver
4. GPIB driver
5. Management engine driver
6. PXIe Trigger driver
7. USB 3.0 driver
Maintenance Tasks:
- Storage Replacement: Remove five screws securing the 2.5″ drive bracket, replace SSD/HDD, and reinstall.
- Battery Replacement: Replace CR2032 cell following anti‑static precautions.
- CMOS Reset: Toggle onboard switch SW1 to “Clear” for 5 seconds, then return to “Normal.”
- Backup BIOS: Automatic failover to secondary BIOS in case of corruption.
### 7. Performance & Capabilities
- System Throughput: Up to 8 GB/s PXIe backplane bandwidth.
- Data Interfaces: High‑speed USB 3.0 (5 Gb/s) and Gigabit Ethernet (1 Gb/s each).
- Display Performance: Dual 4K (3840 × 2160 @ 60 Hz) independent outputs.
- Trigger I/O: Programmable routing between external SMB connector and PXIe trigger bus; supports software‑generated TTL triggers.
- GPIB Performance: Up to 1.5 MB/s transfer rate, connects up to 14 instruments.
- Reliability: Dual BIOS redundancy and industrial‑grade components ensure high uptime.
- Environmental Limits: Operates reliably in 0–55 °C ambient (SSD version) and high humidity environments (≤ 95 % RH non‑condensing).
Limitations:
- Memory addressing above 4 GB requires a 64‑bit OS.
- OS installation via USB CD‑ROM only (some limitations on USB 3.0 boot media).
- PXIe trigger functions require ADLINK driver library installation.
### 8. Standards & Compliance
- PXI/PXIe Standard: PXI‑5 PXI Express Hardware Specification Rev. 1.0
- Electrical Safety & EMC:
- FCC Class A (EN 61326‑1 Emission Compliance)
- CE Mark (EN 61326‑1 Immunity Compliance)
- Environmental Directives:
- RoHS (Restriction of Hazardous Substances)
- WEEE (Waste Electrical and Electronic Equipment)
- Quality & Reliability:
- Designed and manufactured under ADLINK’s ISO 9001 quality management system.
- Complies with industrial shock and vibration standards for PXI controllers.
### 9. Additional Information
Warranty & Support:
- Standard ADLINK limited hardware warranty (terms vary by region).
- Technical support available via ADLINK Ask‑an‑Expert portal (http://askanexpert.adlinktech.com).
- Global service centers in Taiwan, USA, China, Europe, Japan, Korea, Singapore, and India.
Maintenance & Serviceability:
- User‑replaceable storage and battery components.
- BIOS and firmware updates available from ADLINK website.
- Recommended preventive maintenance: periodic dust removal and connector inspection.
Environmental Responsibility:
- Fully RoHS and WEEE compliant.
- Designed for minimal environmental impact through energy‑efficient components and recyclable materials.
Safety Precautions:
- Operate only within specified temperature and humidity ranges.
- Avoid exposure to liquids and high heat sources.
- Disconnect power before installation or maintenance.
- Replace battery only with approved CR2032 type to avoid explosion risk.
BIOS & Configuration:
- BIOS Setup Utility accessible via <Delete> key at boot.
- Configurable parameters include boot order, USB settings, power management, and security passwords.
- Dual BIOS architecture provides automatic failover and manual recovery options.
Software Development & Trigger API:
- ADLINK provides a PXIe Trigger I/O Function Library for C/C++, Visual Basic, and Delphi.
- Functions include TRIG_Init, TRIG_SetSoftTrg, TRIG_Trigger_Route, and TRIG_GetDriverRevision.
- Enables software‑controlled trigger generation and routing between SMB connector and PXIe trigger bus lines (TRIG0–TRIG7).
Documentation:
- User’s Manual Rev. 2.00 (March 24, 2017, Part No. 50‑17052‑1000).
- Updated specifications available on ADLINK website (www.adlinktech.com).
### Summary
The ADLINK PXIe‑3935/M8G/SSD is a compact, high‑reliability PXI Express embedded controller optimized for cost‑sensitive test and measurement environments. It combines Intel® Celeron® processing power, robust I/O connectivity, and PXIe 8 GB/s bandwidth in a 3U form factor. With dual DisplayPort outputs, integrated GPIB and trigger I/O, and dual Gigabit Ethernet interfaces, it serves as a versatile controller for automated test systems, instrument control, and data acquisition applications.
Its rugged design, dual BIOS redundancy, and broad environmental tolerance make it suitable for industrial and laboratory deployments requiring long‑term stability and serviceability. The PXIe‑3935/M8G/SSD embodies ADLINK’s commitment to “Building Forward Together” by delivering a reliable, standards‑compliant platform for next‑generation PXI Express test solutions.
-
PXIe-3935_Datasheet_en_1.pdf
PDF Catalog
Kein Zubehör vorhanden.
