**General Capabilities** - Ethernet‑based remote analog I/O control module with web‑based configuration. - Supports both unipolar and bipolar analog input ranges. - Available in multiple variants for different resolution and input configurations: - **EMA‑8308:** 24‑bit unipolar, 8 differential / 16 single‑ended inputs, 2×12‑bit outputs. - **EMA‑8308A:** 24‑bit unipolar, 8 differential / 16 single‑ended inputs, 2×16‑bit outputs. - **EMA‑8308D:** 24‑bit bipolar, 8 differential inputs, 2×12‑bit outputs. - **EMA‑8308DA:** 24‑bit bipolar, 8 differential inputs, 2×16‑bit outputs. **Analog Input Section** - 24‑bit resolution with selectable input ranges: - Unipolar: 0–5 V, 0–10 V, 0–20 mA, 4–20 mA. - Bipolar: ±5 V, ±10 V, 0–20 mA, 4–20 mA. - Programmable single‑ended or differential input configuration. - High common‑mode voltage tolerance up to 10 V (for EMA‑8308D/DA). - Over‑voltage protection up to 20 V DC. - Input filter bandwidths: 7.03 kHz, 3.52 kHz, 1.76 kHz, 879 Hz. - Sampling rate: 10 samples/s. - Offset error: 2.5 µV typical, 5 µV max; drift 20 nV/°C. - Common‑mode rejection ratio (CMRR): 120 dB. **Analog Output Section** - Two analog output channels. - Output range: ±10 V DC. - Resolution: 12‑bit (EMA‑8308/D) or 16‑bit (EMA‑8308A/DA). - Overload protection: 50 mA (peak). - Over‑voltage protection: 20 V DC max. **Ethernet Section** - Dual 10/100 Mbps auto‑negotiating Ethernet ports (RJ‑45). - Direct web‑page control and configuration. - IP reassignment and software‑based configuration. - Software key and password protection for security. - Supports UDP communication protocol for remote I/O control. **Mechanical and Electrical** - Compact metal housing for industrial durability. - DIN‑rail mountable. - Power supply: 12–24 V DC input. - Operating temperature: 0 – 70 °C; storage: −20 – 80 °C. - Humidity: 5 – 95 % RH (non‑condensing).

Hersteller: JS Automation

Kategorie: Analog Modules

**General Highlights** - Ethernet‑based remote analog I/O control module with web interface - Dual 10/100 Mbps auto‑detecting LAN ports for flexible network integration - High‑resolution 24‑bit analog input and 16‑bit analog output - Supports both unipolar and bipolar input ranges - Differential or single‑ended input configuration (software selectable) - Over‑voltage and overload protection on all analog channels - Compact metal enclosure suitable for DIN‑rail mounting - Compatible with Windows and Linux via provided DLL libraries - Remote addressable and configurable through IP and port settings - Software security key and password protection for configuration access **Analog Input Section** - 24‑bit resolution with selectable input ranges - Configurable as 16 single‑ended or 8 differential channels - Sampling rate: 10 samples/s per channel - Input ranges: 0–5 V, 0–10 V, 0–20 mA, 4–20 mA - High common‑mode voltage tolerance up to 10 V - Input filter bandwidths: 7.03 kHz, 3.52 kHz, 1.76 kHz, 879 Hz - Over‑voltage protection up to 20 V DC **Analog Output Section** - Two 16‑bit D/A output channels - Output range: ±10 V DC - Overload protection: 50 mA (peak) - Over‑voltage protection: 20 V DC (max) **Ethernet Section** - Two RJ‑45 ports (10/100 M auto‑switching) - Web‑based configuration and control interface - IP reassignment and port configuration via software - Supports UDP communication protocol - Default IP: 192.168.0.100 Default Port: 6936

Hersteller: JS Automation

Kategorie: Analog Modules

**Analog Input Section** - 8 differential analog input channels (bi‑polar configuration). - 24‑bit resolution with high accuracy and low noise. - Input ranges: ±5 V, ±10 V, 0–20 mA, 4–20 mA. - Common‑mode voltage tolerance up to 10 V. - Over‑voltage protection up to 20 V DC (max). - Input filter options: 7.03 kHz, 3.52 kHz, 1.76 kHz, 879 Hz. - Sampling rate: 10 samples per second. - Typical offset error: 2.5 µV; maximum 5 µV. - Offset drift: 20 nV/°C. - Common‑mode rejection ratio (CMRR): 120 dB. **Analog Output Section** - 2 analog output channels. - 12‑bit resolution (EMA‑8308D variant). - Output range: −10 V to +10 V DC. - Overload protection: 50 mA (peak). - Short‑circuit and over‑voltage protection up to 20 V DC. **Ethernet Communication** - Dual 10/100 Mbps auto‑switching Ethernet ports (2 × RJ‑45). - Web‑based configuration and control interface. - IP address reassignment and software key protection. - Supports UDP communication protocol for remote I/O control. - Default IP: 192.168.0.100; default port: 6936. **General Features** - Compact, rugged metal housing for industrial use. - DIN‑rail mountable design. - Power supply: 12–24 V DC input. - Operating temperature: 0 °C to +70 °C. - Storage temperature: −20 °C to +80 °C. - Humidity: 5–95 % RH (non‑condensing). - Dimensions: 107.6 (D) × 135.8 (W) × 34 (H) mm (4.3 × 5.4 × 1.4 in).

Hersteller: JS Automation

Kategorie: Analog Modules

**Analog Input Section** - 8 differential analog input channels (bi‑polar configuration) - 24‑bit resolution for high‑accuracy signal acquisition - Input ranges: ±5 V, ±10 V, 0–20 mA, 4–20 mA - Sampling rate: 10 samples per second - Common‑mode voltage tolerance up to 10 V - Over‑voltage protection up to 20 V DC (max) - Programmable input filters (7.03 kHz, 3.52 kHz, 1.76 kHz, 879 Hz) - Offset error: 2.5 µV (typical), 5 µV (max) - Offset drift: 20 nV/°C - Common‑mode rejection ratio (CMRR): 120 dB **Analog Output Section** - 2 analog output channels - 16‑bit resolution (high‑precision D/A conversion) - Output range: −10 V DC to +10 V DC - Overload protection: 50 mA (peak) - Short‑circuit and over‑voltage protection (up to 20 V DC) **Ethernet Communication** - Dual 10/100 Mbps auto‑switching Ethernet ports (2 × RJ‑45) - Web‑based configuration and control interface - IP address reassignment and software‑based configuration - Supports UDP protocol for remote I/O communication - Software key and password protection for security - Compatible with Windows and Linux environments via DLL libraries **General Features** - Compact DIN‑rail mountable metal enclosure - Power supply: 12–24 V DC input - Operating temperature: 0 °C to +70 °C - Storage temperature: −20 °C to +80 °C - Humidity: 5–95 % RH (non‑condensing) - High reliability and remote addressability - Factory default IP: 192.168.0.100, port 6936

Hersteller: JS Automation

Kategorie: Analog Modules

- **Multi-Channel RTD Input:** Supports 4 independent input channels for Pt100 and Pt1000 sensors, enabling simultaneous multi-point temperature measurement. - **High-Resolution Measurement:** 24-bit ADC resolution ensures precise and stable readings, suitable for high-accuracy industrial temperature monitoring. - **Flexible Sensor Wiring:** Compatible with 2-wire, 3-wire, and 4-wire RTD connection configurations, allowing adaptation to various installation and accuracy requirements. - **Dual Ethernet Ports:** Equipped with 2×10/100Base-TX LAN interfaces for network redundancy, daisy-chaining, or segmented network configurations. - **Integrated Relay Outputs:** Includes 4 relay channels for control, alarm signaling, or process actuation, enabling direct interaction with external devices. - **Wide Operating Temperature Range:** Designed for operation from 0°C to +70°C, ensuring reliable performance in industrial and process environments. - **Industrial-Grade Construction:** Metal housing provides electromagnetic shielding and mechanical durability, suitable for harsh industrial conditions. - **DIN Rail Mounting:** Standard DIN rail mounting design simplifies installation in control cabinets and industrial panels. - **Flexible Power Supply:** Operates from a 12–24 VDC input, compatible with common industrial power systems. - **Compact Form Factor:** Space-efficient design with dimensions of 107.6 × 135.8 × 34 mm, allowing dense installation in control enclosures. - **Network-Based Data Acquisition:** Ethernet connectivity enables remote monitoring, configuration, and integration with SCADA, PLC, or IoT systems.

Hersteller: JS Automation

Kategorie: Analog Modules

- **Multi-Channel Thermocouple Input:** Supports **4 independent thermocouple input channels**, compatible with multiple thermocouple types including **S, R, B, K, N, E, J, and T**. - **High-Resolution Measurement:** Each input channel features **24-bit analog-to-digital conversion**, ensuring precise temperature measurement and high signal fidelity. - **Integrated Cold Junction Compensation (CJC):** Built-in thermocouple compensation ensures accurate readings by automatically correcting for ambient temperature variations at the connection terminals. - **Broken Sensor Detection:** The module includes **open thermocouple detection**, allowing immediate identification of disconnected or faulty sensors. - **Dual Ethernet Ports:** Equipped with **2×10/100Base-TX Ethernet interfaces**, enabling flexible network topologies such as daisy-chaining, redundant networking, or separate LAN segmentation. - **Relay Outputs:** Provides **4 relay output channels** for control, alarm signaling, or process actuation, allowing direct interface with external devices such as alarms, indicators, or actuators. - **Industrial-Grade Design:** Housed in a **metal enclosure** for electromagnetic shielding and mechanical durability, suitable for harsh industrial environments. - **Wide Power Supply Range:** Operates from a **12–24 VDC** power input, compatible with standard industrial power systems. - **DIN Rail Mounting:** Designed for **DIN rail installation**, simplifying integration into control cabinets and automation panels. - **Temperature Range:** Operational temperature from **0°C to +70°C**, with storage capability from **–20°C to +80°C**, ensuring reliability across a wide range of environmental conditions.

Hersteller: JS Automation

Kategorie: Analog Modules

**General Highlights:** - Ethernet-based analog I/O module with integrated web control interface. - Supports both single-ended and differential analog input configurations. - High-resolution 24-bit analog-to-digital conversion (ADC). - Dual-channel analog output with 12-bit or 16-bit resolution depending on model. - 10/100 Mbps auto-detect Ethernet interface with IP reassignment capability. - Web-based configuration and control without additional hardware. - DLL libraries provided for Windows and Linux for custom application development. - DIN rail mountable compact industrial design. - High reliability, remote addressability, and stable operation for industrial environments. **Analog Input Features:** - 8 differential or 16 single-ended analog input channels (model dependent). - 24-bit resolution with selectable input ranges. - Input ranges include voltage and current modes: - 0–5 V, 0–10 V, 0–20 mA, 4–20 mA (EMA7308 / EMA7308A) - ±5 V, ±10 V, 0–20 mA, 4–20 mA (EMA7308D / EMA7308DA) - Programmable input configuration (single-ended or differential). - High common-mode voltage tolerance up to 10 V (for differential models). - Over-voltage protection up to 20 VDC. - Input filter options: 7.03 kHz, 3.52 kHz, 1.76 kHz, 879 Hz. - Common-mode rejection ratio (CMRR): 120 dB. - Sampling rate: 10 samples per second. - Offset error: 2.5 µV typical, 5 µV maximum. - Offset drift: 20 nV/°C. **Analog Output Features:** - 2 analog output channels. - Output range: ±10 VDC. - Resolution: - 12-bit for EMA7308 / EMA7308D. - 16-bit for EMA7308A / EMA7308DA. - Overload protection: 50 mA (peak). - Over-voltage protection: 20 VDC maximum. **Ethernet Features:** - 10/100 Mbps auto-switching Ethernet interface. - IP reassignment and port configuration supported. - Direct web-based control and monitoring. - Software API for remote configuration and data access.

Hersteller: JS Automation

Kategorie: Analog Modules

**Analog Input Section** - **High-resolution 24-bit A/D conversion** for precise analog signal measurement. - **Configurable input modes:** 16 single-ended or 8 differential channels. - **Multiple input ranges:** 0–5V, 0–10V, 0–20mA, and 4–20mA. - **Sampling rate:** 10 samples per second per channel. - **High common-mode voltage tolerance:** up to 10V. - **Excellent noise performance:** selectable input filters (7.03kHz to 879Hz). - **Over-voltage protection:** up to 20VDC maximum. - **Offset error:** 2.5µV typical, 5µV maximum. - **Offset drift:** 20nV/°C. - **Common-mode rejection ratio (CMRR):** 120dB. **Analog Output Section** - **Two independent D/A output channels.** - **16-bit resolution** for high-accuracy analog output. - **Output range:** ±10VDC. - **Overload protection:** 50mA peak. - **Over-voltage protection:** up to 20VDC maximum. **Ethernet Communication** - **10/100 Mbps auto-detecting Ethernet interface.** - **Supports IP reassignment and direct web-based configuration.** - **Remote control and monitoring via standard TCP/IP protocols.** - **Software libraries (DLLs) for Windows and Linux environments.** **General Features** - **DIN rail mountable** for industrial panel integration. - **Compact form factor:** 89 × 110 × 34 mm. - **Wide power supply range:** 12–24VDC. - **Operating temperature:** 0°C to +70°C. - **Storage temperature:** -20°C to +80°C. - **Humidity tolerance:** 5–95% RH, non-condensing. - **High reliability and remote addressability.**

Hersteller: JS Automation

Kategorie: Analog Modules

**Analog Input Features:** - **8 differential analog input channels** (bipolar configuration) - **24-bit resolution** for high-accuracy signal acquisition - **Input ranges:** ±5V, ±10V, 0–20mA, 4–20mA - **Sampling rate:** 10 samples per second - **High common-mode voltage tolerance:** up to 10V - **Over-voltage protection:** up to 20VDC maximum - **Input filter options:** 7.03 kHz, 3.52 kHz, 1.76 kHz, 879 Hz - **Excellent noise performance:** RMS noise as low as 1.5 µV at lowest filter setting - **Offset error:** 2.5 µV typical, 5 µV maximum - **Offset drift:** 20 nV/°C - **Common-mode rejection ratio (CMRR):** 120 dB **Analog Output Features:** - **2 analog output channels** - **12-bit resolution** - **Output range:** ±10VDC - **Overload protection:** 50 mA (peak) - **Over-voltage protection:** up to 20VDC **Ethernet Communication:** - **10/100 Mbps auto-detection** - **Direct web-based control interface** - **IP address re-assignment capability** - **Supports remote configuration and monitoring** - **Compatible with Windows and Linux via provided DLL libraries** **General Features:** - **DIN rail mountable** for industrial environments - **Power supply:** 12–24VDC input - **Compact design:** 89 × 110 × 34 mm - **Operating temperature:** 0°C to +70°C - **Storage temperature:** -20°C to +80°C - **Humidity tolerance:** 5–95% RH (non-condensing) - **High reliability and remote addressability**

Hersteller: JS Automation

Kategorie: Analog Modules

**Analog Input Features:** - **High-resolution 24-bit A/D conversion** for precise analog signal measurement. - **8 differential input channels** supporting bipolar voltage and current signals. - **Selectable input ranges:** - Voltage: ±5V, ±10V - Current: 0–20mA, 4–20mA - **Sampling rate:** 10 samples per second per channel. - **High common-mode voltage tolerance:** up to 10V. - **Excellent noise rejection:** 120dB common-mode rejection ratio (CMRR). - **Input filter options:** 7.03kHz, 3.52kHz, 1.76kHz, 879Hz. - **Over-voltage protection:** up to 20VDC maximum. - **Offset error:** 2.5µV typical, 5µV maximum. - **Offset drift:** 20nV/°C. **Analog Output Features:** - **2 analog output channels** with 16-bit D/A resolution. - **Output range:** ±10VDC. - **Overload protection:** 50mA peak. - **Over-voltage protection:** up to 20VDC. - **Factory preset voltage trimmers (DA0, DA1)** for calibration. **Ethernet Communication:** - **10/100 Mbps auto-detecting Ethernet interface.** - **Web-based configuration and control interface.** - **IP address reassignment and remote configuration.** - **Supports direct socket communication via DLL libraries.** **General Features:** - **DIN rail mountable** compact industrial design. - **Power supply:** 12–24VDC input. - **Operating temperature:** 0°C to +70°C. - **Storage temperature:** -20°C to +80°C. - **Humidity tolerance:** 5–95% RH, non-condensing. - **Dimensions:** 89(D) × 110(W) × 34(H) mm (3.5 × 4.33 × 1.39 in).

Hersteller: JS Automation

Kategorie: Analog Modules
