Comprehensive Product Summary – RAYON FPI401 PoE Power Injector
### 1. Product Overview
Product Name: PoE Power Injector
Model: FPI401
Series: FPI400 Series (Four-Port PoE Power Injectors)
Article Number: FPI401
Manufacturer: RAYON TECHNOLOGY CO., LTD.
Manufacturer Address: 2F, No. 177, Chung Shan 2 Rd., Lu Chou City, Taipei Hsien, Taiwan
Contact:
- Tel: +886-2-82858362
- Fax: +886-2-82857065
- Email: rayon@ms1.hinet.net
- Websites: [www.computex.com.tw/rayon](http://www.computex.com.tw/rayon), [www.rayontech.com](http://www.rayontech.com)
Product Description:
The RAYON FPI401 is a four-port Power over Ethernet (PoE) power injector designed for 10/100 Mbps Ethernet networks. It provides centralized power distribution to network devices that require PoE functionality, such as IP cameras, VoIP phones, and wireless access points, while maintaining data connectivity through standard RJ45 interfaces. The FPI401 operates with an external 48VDC power input and delivers up to 15.4W per port in compliance with IEEE 802.3af standards. It also supports Cisco legacy detection, ensuring compatibility with a wide range of powered devices (PDs).
### 2. Key Features
- IEEE 802.3af Compatibility: Fully compliant with the IEEE 802.3af PoE standard, ensuring interoperability with standard PoE-enabled devices.
- Cisco Legacy Detection: Supports Cisco’s proprietary PoE detection mechanism for backward compatibility with older Cisco devices.
- Four Independent PoE Ports: Provides four 10/100 Mbps Ethernet ports capable of delivering power and data simultaneously.
- External 48VDC Power Input: Designed for use with an external DC power supply, allowing flexible integration into existing power systems.
- 15.4W Output per Port: Each port can supply up to 15.4 watts of power, suitable for Class 0–3 PoE devices.
- Dynamic Power Management: Intelligent power allocation ensures stable operation and prevents overload conditions.
- LED Indicators: Front-panel LEDs provide real-time status for power, overload, short-circuit, and insufficient power conditions.
- Compact and Durable Design: Space-efficient enclosure (195 × 131 × 45 mm) suitable for wiring closets or desktop installations.
- Scalable and Cost-Effective: Enables easy PoE integration into existing non-PoE networks without replacing switches.
- Power Over Spare Lines: Utilizes spare wire pairs in 10/100 Mbps Ethernet cabling for power transmission.
- Optional Configurations:
- FPI401A: IEEE 802.3af detection only.
- FPI401C: Cisco legacy detection only.
- Custom configurations available upon request.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Number of Ports | 4 PoE ports |
| Data Rate | 10/100 Mbps |
| Input Power | 48VDC external power supply |
| PoE Output Power | 15.4W per port (IEEE 802.3af Class 0) |
| Total Power Budget | 65W maximum (aggregate for all ports) |
| Power Transmission Mode | Power over spare lines (10/100 Mbps) |
| Connectors | Data In: RJ45; Data Out: RJ45 |
| LED Indicators | PWR (Power On), POE1–POE4 (Status per port: Normal, Overload, Short-circuit, Insufficient Power) |
| Dimensions | 195 mm (L) × 131 mm (W) × 45 mm (H) |
| Weight | Approx. 0.8–1.0 kg (typical, depending on configuration) |
| Operating Temperature | -15°C to +50°C |
| Storage Temperature | -15°C to +80°C |
| Operating Humidity | 10%–90% RH (non-condensing) |
| Storage Humidity | 5%–95% RH (non-condensing) |
| Material | Metal enclosure for durability and heat dissipation |
| Mounting Options | Desktop or wall-mountable |
| Compliance | IEEE 802.3af, Cisco legacy detection |
| Special Order Models | FPI401A (IEEE 802.3af only), FPI401C (Cisco legacy only) |
### 4. Functionality
Operational Concept:
The FPI401 acts as a midspan power injector between a non-PoE Ethernet switch and PoE-enabled devices. It receives data signals from the switch through the “Data In” RJ45 ports and combines them with DC power supplied from an external 48VDC source. The combined power and data signals are then transmitted through the “Data Out” RJ45 ports to the connected PoE devices.
Use Cases and Applications:
- IP Surveillance Systems: Powers IP cameras in remote or outdoor locations without separate power cabling.
- VoIP Telephony: Supplies power to IP phones in office environments.
- Wireless Access Points: Enables remote installation of Wi-Fi access points without local power outlets.
- Industrial and Commercial Networks: Provides centralized power management for distributed network devices.
- Building Automation: Supports PoE-enabled sensors, controllers, and access control systems.
Compatibility:
- Compatible with IEEE 802.3af-compliant powered devices.
- Supports Cisco legacy PoE devices.
- Works with standard Cat5/Cat5e Ethernet cabling.
- Integrates seamlessly with non-PoE switches and routers.
### 5. Components & Accessories
Included Items:
- FPI401 PoE Power Injector main unit
- User manual or quick installation guide
- Mounting accessories (optional, depending on package)
Optional Accessories:
- External 48VDC Power Supply Unit: Required for operation (not included by default).
- PoE Splitters (SP1301, SP2401): Used to convert PoE power back to DC output (12.5VDC) for non-PoE devices.
- SP1301: 13W capacity, IEEE 802.3af Class 0
- SP2401: 24W capacity, IEEE 802.3at Class 4
- PoE Power Modules (PD1301, PD2401): Compact PCB modules for integrating PoE functionality into custom devices.
- PD1301: 13W, IEEE 802.3af Class 0
- PD2401: 24W, IEEE 802.3at Class 4
Connectors:
- Data In Ports (RJ45): Connect to non-PoE switch or router.
- Data Out Ports (RJ45): Connect to PoE-enabled devices.
- DC Power Input: 48VDC terminal or connector (depending on model configuration).
### 6. Installation & Setup
Requirements:
- External 48VDC power supply with sufficient current capacity (minimum 65W total output recommended).
- Standard Cat5 or Cat5e Ethernet cables.
- Non-PoE Ethernet switch or router for data input.
Installation Steps:
1. Power Connection: Connect the external 48VDC power source to the FPI401’s DC input terminal.
2. Data Input: Connect the “Data In” RJ45 ports to the corresponding ports on the network switch.
3. Data + Power Output: Connect the “Data Out” RJ45 ports to the PoE-enabled devices (PDs).
4. LED Verification: Check the front-panel LEDs to confirm power and port status.
5. Testing: Verify that connected devices are receiving both data and power.
Mounting Options:
- Desktop Placement: Suitable for small installations or test environments.
- Wall Mounting: Optional brackets can be used for vertical or horizontal mounting in wiring closets or equipment racks.
Configuration:
- Plug-and-play operation; no software configuration required.
- Power management and detection are handled automatically by the internal PoE controller.
### 7. Performance & Capabilities
Power Delivery:
- Each port delivers up to 15.4W, compliant with IEEE 802.3af Class 0–3 devices.
- Total power budget of 65W ensures stable operation across all four ports.
- Dynamic power management prevents overload by distributing available power intelligently.
Data Transmission:
- Supports 10/100 Mbps Ethernet data rates.
- Transparent data pass-through with no latency or packet loss.
- Power is transmitted over spare wire pairs (pins 4,5 and 7,8) in 10/100 Mbps cabling.
Efficiency:
- High conversion efficiency minimizes power loss and heat generation.
- Low standby power consumption when no devices are connected.
Limitations:
- Not suitable for Gigabit (1000 Mbps) networks; use GPI4000 or GPI4001 for 10/100/1000 Mbps environments.
- Requires external 48VDC power supply (not included).
- Maximum total power limited to 65W; exceeding this may trigger overload protection.
### 8. Standards & Compliance
Industry Standards:
- IEEE 802.3 10BASE-T / 100BASE-TX Ethernet
- IEEE 802.3af Power over Ethernet (PoE)
- Cisco Legacy PoE Detection (for older Cisco PDs)
Electrical Safety & Protection:
- Overload protection per port
- Short-circuit protection
- Over-temperature protection (internal thermal safeguards)
- Automatic power classification and detection
Environmental Compliance:
- Operating temperature range: -15°C to +50°C
- Humidity tolerance: up to 90% RH non-condensing
- RoHS-compliant materials (lead-free construction)
Regulatory Compliance:
- Designed to meet international safety and EMC standards applicable to networking equipment.
- Conforms to CE and FCC Class A/B requirements (depending on region).
### 9. Additional Information
Warranty:
- Standard manufacturer warranty (typically 1–2 years, depending on region and distributor).
- Covers defects in materials and workmanship under normal operating conditions.
Technical Support:
- Provided by RAYON TECHNOLOGY CO., LTD. via email or phone.
- Online resources available through the company’s website, including datasheets and product manuals.
Maintenance:
- Minimal maintenance required.
- Periodic inspection recommended to ensure clean RJ45 connectors and stable power input.
- Avoid exposure to excessive dust, moisture, or vibration.
Firmware & Updates:
- The FPI401 operates as a hardware-based injector; no firmware updates are typically required.
- Any configuration or feature updates are available through hardware revisions (e.g., FPI401A, FPI401C).
Related Products in the RAYON PoE Ecosystem:
- FPI400: 10/100 Mbps PoE injector with built-in AC power supply (90–264VAC input).
- GPI4000 / GPI4001: Gigabit PoE injectors for 10/100/1000 Mbps networks.
- SP1301 / SP2401: PoE splitters for converting PoE to DC power for non-PoE devices.
- PD1301 / PD2401: Embedded PoE modules for device integration.
- GPS8075 / GPS8180: PoE switches with 8 RJ45 ports and 1 SFP uplink, supporting 75W and 180W PoE budgets respectively.
### Summary
The RAYON FPI401 PoE Power Injector is a robust, four-port midspan injector designed to add PoE functionality to existing 10/100 Mbps Ethernet networks. It provides a reliable and cost-effective solution for powering network devices remotely, eliminating the need for separate power cabling. With IEEE 802.3af compliance, Cisco legacy support, and intelligent power management, the FPI401 ensures safe and efficient power delivery to a wide range of PoE-enabled devices. Its compact design, LED monitoring, and flexible installation options make it ideal for small to medium-sized network deployments in commercial, industrial, and institutional environments.
Manufacturer Contact Information:
RAYON TECHNOLOGY CO., LTD.
2F, No. 177, Chung Shan 2 Rd., Lu Chou City, Taipei Hsien, Taiwan
Tel: +886-2-82858362 | Fax: +886-2-82857065
Email: rayon@ms1.hinet.net
Web: [www.rayontech.com](http://www.rayontech.com)
### 1. Product Overview
Product Name: PoE Power Injector
Model: FPI401
Series: FPI400 Series (Four-Port PoE Power Injectors)
Article Number: FPI401
Manufacturer: RAYON TECHNOLOGY CO., LTD.
Manufacturer Address: 2F, No. 177, Chung Shan 2 Rd., Lu Chou City, Taipei Hsien, Taiwan
Contact:
- Tel: +886-2-82858362
- Fax: +886-2-82857065
- Email: rayon@ms1.hinet.net
- Websites: [www.computex.com.tw/rayon](http://www.computex.com.tw/rayon), [www.rayontech.com](http://www.rayontech.com)
Product Description:
The RAYON FPI401 is a four-port Power over Ethernet (PoE) power injector designed for 10/100 Mbps Ethernet networks. It provides centralized power distribution to network devices that require PoE functionality, such as IP cameras, VoIP phones, and wireless access points, while maintaining data connectivity through standard RJ45 interfaces. The FPI401 operates with an external 48VDC power input and delivers up to 15.4W per port in compliance with IEEE 802.3af standards. It also supports Cisco legacy detection, ensuring compatibility with a wide range of powered devices (PDs).
### 2. Key Features
- IEEE 802.3af Compatibility: Fully compliant with the IEEE 802.3af PoE standard, ensuring interoperability with standard PoE-enabled devices.
- Cisco Legacy Detection: Supports Cisco’s proprietary PoE detection mechanism for backward compatibility with older Cisco devices.
- Four Independent PoE Ports: Provides four 10/100 Mbps Ethernet ports capable of delivering power and data simultaneously.
- External 48VDC Power Input: Designed for use with an external DC power supply, allowing flexible integration into existing power systems.
- 15.4W Output per Port: Each port can supply up to 15.4 watts of power, suitable for Class 0–3 PoE devices.
- Dynamic Power Management: Intelligent power allocation ensures stable operation and prevents overload conditions.
- LED Indicators: Front-panel LEDs provide real-time status for power, overload, short-circuit, and insufficient power conditions.
- Compact and Durable Design: Space-efficient enclosure (195 × 131 × 45 mm) suitable for wiring closets or desktop installations.
- Scalable and Cost-Effective: Enables easy PoE integration into existing non-PoE networks without replacing switches.
- Power Over Spare Lines: Utilizes spare wire pairs in 10/100 Mbps Ethernet cabling for power transmission.
- Optional Configurations:
- FPI401A: IEEE 802.3af detection only.
- FPI401C: Cisco legacy detection only.
- Custom configurations available upon request.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Number of Ports | 4 PoE ports |
| Data Rate | 10/100 Mbps |
| Input Power | 48VDC external power supply |
| PoE Output Power | 15.4W per port (IEEE 802.3af Class 0) |
| Total Power Budget | 65W maximum (aggregate for all ports) |
| Power Transmission Mode | Power over spare lines (10/100 Mbps) |
| Connectors | Data In: RJ45; Data Out: RJ45 |
| LED Indicators | PWR (Power On), POE1–POE4 (Status per port: Normal, Overload, Short-circuit, Insufficient Power) |
| Dimensions | 195 mm (L) × 131 mm (W) × 45 mm (H) |
| Weight | Approx. 0.8–1.0 kg (typical, depending on configuration) |
| Operating Temperature | -15°C to +50°C |
| Storage Temperature | -15°C to +80°C |
| Operating Humidity | 10%–90% RH (non-condensing) |
| Storage Humidity | 5%–95% RH (non-condensing) |
| Material | Metal enclosure for durability and heat dissipation |
| Mounting Options | Desktop or wall-mountable |
| Compliance | IEEE 802.3af, Cisco legacy detection |
| Special Order Models | FPI401A (IEEE 802.3af only), FPI401C (Cisco legacy only) |
### 4. Functionality
Operational Concept:
The FPI401 acts as a midspan power injector between a non-PoE Ethernet switch and PoE-enabled devices. It receives data signals from the switch through the “Data In” RJ45 ports and combines them with DC power supplied from an external 48VDC source. The combined power and data signals are then transmitted through the “Data Out” RJ45 ports to the connected PoE devices.
Use Cases and Applications:
- IP Surveillance Systems: Powers IP cameras in remote or outdoor locations without separate power cabling.
- VoIP Telephony: Supplies power to IP phones in office environments.
- Wireless Access Points: Enables remote installation of Wi-Fi access points without local power outlets.
- Industrial and Commercial Networks: Provides centralized power management for distributed network devices.
- Building Automation: Supports PoE-enabled sensors, controllers, and access control systems.
Compatibility:
- Compatible with IEEE 802.3af-compliant powered devices.
- Supports Cisco legacy PoE devices.
- Works with standard Cat5/Cat5e Ethernet cabling.
- Integrates seamlessly with non-PoE switches and routers.
### 5. Components & Accessories
Included Items:
- FPI401 PoE Power Injector main unit
- User manual or quick installation guide
- Mounting accessories (optional, depending on package)
Optional Accessories:
- External 48VDC Power Supply Unit: Required for operation (not included by default).
- PoE Splitters (SP1301, SP2401): Used to convert PoE power back to DC output (12.5VDC) for non-PoE devices.
- SP1301: 13W capacity, IEEE 802.3af Class 0
- SP2401: 24W capacity, IEEE 802.3at Class 4
- PoE Power Modules (PD1301, PD2401): Compact PCB modules for integrating PoE functionality into custom devices.
- PD1301: 13W, IEEE 802.3af Class 0
- PD2401: 24W, IEEE 802.3at Class 4
Connectors:
- Data In Ports (RJ45): Connect to non-PoE switch or router.
- Data Out Ports (RJ45): Connect to PoE-enabled devices.
- DC Power Input: 48VDC terminal or connector (depending on model configuration).
### 6. Installation & Setup
Requirements:
- External 48VDC power supply with sufficient current capacity (minimum 65W total output recommended).
- Standard Cat5 or Cat5e Ethernet cables.
- Non-PoE Ethernet switch or router for data input.
Installation Steps:
1. Power Connection: Connect the external 48VDC power source to the FPI401’s DC input terminal.
2. Data Input: Connect the “Data In” RJ45 ports to the corresponding ports on the network switch.
3. Data + Power Output: Connect the “Data Out” RJ45 ports to the PoE-enabled devices (PDs).
4. LED Verification: Check the front-panel LEDs to confirm power and port status.
5. Testing: Verify that connected devices are receiving both data and power.
Mounting Options:
- Desktop Placement: Suitable for small installations or test environments.
- Wall Mounting: Optional brackets can be used for vertical or horizontal mounting in wiring closets or equipment racks.
Configuration:
- Plug-and-play operation; no software configuration required.
- Power management and detection are handled automatically by the internal PoE controller.
### 7. Performance & Capabilities
Power Delivery:
- Each port delivers up to 15.4W, compliant with IEEE 802.3af Class 0–3 devices.
- Total power budget of 65W ensures stable operation across all four ports.
- Dynamic power management prevents overload by distributing available power intelligently.
Data Transmission:
- Supports 10/100 Mbps Ethernet data rates.
- Transparent data pass-through with no latency or packet loss.
- Power is transmitted over spare wire pairs (pins 4,5 and 7,8) in 10/100 Mbps cabling.
Efficiency:
- High conversion efficiency minimizes power loss and heat generation.
- Low standby power consumption when no devices are connected.
Limitations:
- Not suitable for Gigabit (1000 Mbps) networks; use GPI4000 or GPI4001 for 10/100/1000 Mbps environments.
- Requires external 48VDC power supply (not included).
- Maximum total power limited to 65W; exceeding this may trigger overload protection.
### 8. Standards & Compliance
Industry Standards:
- IEEE 802.3 10BASE-T / 100BASE-TX Ethernet
- IEEE 802.3af Power over Ethernet (PoE)
- Cisco Legacy PoE Detection (for older Cisco PDs)
Electrical Safety & Protection:
- Overload protection per port
- Short-circuit protection
- Over-temperature protection (internal thermal safeguards)
- Automatic power classification and detection
Environmental Compliance:
- Operating temperature range: -15°C to +50°C
- Humidity tolerance: up to 90% RH non-condensing
- RoHS-compliant materials (lead-free construction)
Regulatory Compliance:
- Designed to meet international safety and EMC standards applicable to networking equipment.
- Conforms to CE and FCC Class A/B requirements (depending on region).
### 9. Additional Information
Warranty:
- Standard manufacturer warranty (typically 1–2 years, depending on region and distributor).
- Covers defects in materials and workmanship under normal operating conditions.
Technical Support:
- Provided by RAYON TECHNOLOGY CO., LTD. via email or phone.
- Online resources available through the company’s website, including datasheets and product manuals.
Maintenance:
- Minimal maintenance required.
- Periodic inspection recommended to ensure clean RJ45 connectors and stable power input.
- Avoid exposure to excessive dust, moisture, or vibration.
Firmware & Updates:
- The FPI401 operates as a hardware-based injector; no firmware updates are typically required.
- Any configuration or feature updates are available through hardware revisions (e.g., FPI401A, FPI401C).
Related Products in the RAYON PoE Ecosystem:
- FPI400: 10/100 Mbps PoE injector with built-in AC power supply (90–264VAC input).
- GPI4000 / GPI4001: Gigabit PoE injectors for 10/100/1000 Mbps networks.
- SP1301 / SP2401: PoE splitters for converting PoE to DC power for non-PoE devices.
- PD1301 / PD2401: Embedded PoE modules for device integration.
- GPS8075 / GPS8180: PoE switches with 8 RJ45 ports and 1 SFP uplink, supporting 75W and 180W PoE budgets respectively.
### Summary
The RAYON FPI401 PoE Power Injector is a robust, four-port midspan injector designed to add PoE functionality to existing 10/100 Mbps Ethernet networks. It provides a reliable and cost-effective solution for powering network devices remotely, eliminating the need for separate power cabling. With IEEE 802.3af compliance, Cisco legacy support, and intelligent power management, the FPI401 ensures safe and efficient power delivery to a wide range of PoE-enabled devices. Its compact design, LED monitoring, and flexible installation options make it ideal for small to medium-sized network deployments in commercial, industrial, and institutional environments.
Manufacturer Contact Information:
RAYON TECHNOLOGY CO., LTD.
2F, No. 177, Chung Shan 2 Rd., Lu Chou City, Taipei Hsien, Taiwan
Tel: +886-2-82858362 | Fax: +886-2-82857065
Email: rayon@ms1.hinet.net
Web: [www.rayontech.com](http://www.rayontech.com)
-
FPI401_Catalog.pdf
PDF Catalog
-
PoE_product_line.pdf
PDF Catalog
Kein Zubehör vorhanden.
