1. Product Overview
Name: IAR-320+
Model: IAR-320+
Series: Industrial Cellular VPN Router / Access Point Series
Article Number: IAR-320+
Manufacturer: ORing Industrial Networking Corp.

The ORing IAR-320+ is an industrial-grade wireless access point and cellular VPN router designed for robust, secure, and flexible network connectivity in demanding environments. It integrates wireless LAN (WLAN) 802.11a/b/g functionality with dual 10/100Base-TX Ethernet ports and 3.5G cellular VPN routing capabilities. The device supports Power over Ethernet (PoE) input compliant with IEEE 802.3af standards, enabling simplified power and data delivery through a single cable. Engineered for industrial automation, transportation, and remote monitoring applications, the IAR-320+ combines rugged construction, versatile mounting options, and advanced networking features to ensure reliable performance in harsh conditions.

---

2. Key Features
- Integrated Wireless and Cellular Connectivity: Combines WLAN 802.11a/b/g access point functionality with a 3.5G cellular VPN router, providing flexible network access options for both wired and wireless clients.
- Dual Ethernet Ports: Equipped with two 10/100Base-TX LAN interfaces for wired network connections, supporting auto-negotiation and auto MDI/MDI-X for simplified cabling.
- Multiple Operation Modes: Supports Access Point (AP), Bridge, Repeater, and AP Client modes, allowing deployment in diverse network topologies and extending wireless coverage.
- PoE Power Input: IEEE 802.3af-compliant Power over Ethernet (PD) capability enables power delivery through Ethernet cabling, reducing installation complexity and cost.
- Dual Power Input Design: Accepts 12–48V DC power input, providing redundancy and flexibility in industrial power systems.
- Low Power Consumption: Maximum power consumption of 6W ensures energy efficiency and suitability for remote or power-limited installations.
- Industrial-Grade Construction: Housed in a durable metal enclosure designed for DIN-rail or wall mounting, ensuring mechanical stability and protection against environmental stress.
- Wide Temperature Range: Operates reliably in temperatures from -10°C to +55°C and can be stored between -20°C and +85°C, suitable for both indoor and outdoor industrial environments.
- Alarm Contact Output: Includes one relay output for alarm signaling or integration with external monitoring systems.
- Compact Form Factor: Space-efficient design with dimensions of 52 × 106 × 144 mm and a weight of approximately 800 grams.
- Enhanced Security and VPN Support: Integrated VPN functionality for secure remote access and data transmission over cellular or wireless networks.

---

3. Technical Specifications
- Network Interfaces:
- 2 × 10/100Base-TX Ethernet ports (RJ45, auto MDI/MDI-X)
- WLAN interface supporting IEEE 802.11a/b/g standards
- 3.5G cellular interface for mobile broadband connectivity

- Wireless Standards:
- IEEE 802.11a (5 GHz band)
- IEEE 802.11b/g (2.4 GHz band)
- Supports AP, Bridge, Repeater, and AP Client modes

- Power Supply:
- Dual power input: 12–48V DC
- PoE input: IEEE 802.3af compliant (Power Device mode)
- Maximum power consumption: 6W

- Alarm Interface:
- 1 × Relay output for alarm contact signaling

- Mechanical Construction:
- Enclosure: Rugged metal housing
- Mounting: DIN-rail or wall mount options
- Dimensions: 52 mm (W) × 106 mm (H) × 144 mm (D)
- Weight: Approximately 800 g

- Environmental Conditions:
- Operating temperature: -10°C to +55°C
- Storage temperature: -20°C to +85°C
- Humidity: Typically 5–95% non-condensing (standard industrial specification)

- Performance:
- Data rate: Up to 54 Mbps (802.11g), 11 Mbps (802.11b), 54 Mbps (802.11a)
- Cellular data rate: Dependent on 3.5G network performance (HSPA/UMTS)
- VPN throughput: Optimized for secure industrial data transmission

---

4. Functionality
The IAR-320+ functions as a multi-role industrial networking device that bridges wired, wireless, and cellular networks. It can operate as a standalone access point, a wireless bridge connecting two network segments, a repeater extending wireless coverage, or an AP client connecting to another access point.

In Access Point mode, it provides wireless connectivity to client devices such as laptops, tablets, or industrial controllers. In Bridge or Repeater mode, it extends existing wireless networks, improving coverage in large facilities or outdoor areas. The AP Client mode allows the device to connect to another AP, effectively integrating wired devices into a wireless network.

The integrated 3.5G cellular VPN router functionality enables secure remote access via mobile broadband networks. This is particularly useful for remote monitoring, SCADA systems, or mobile applications where wired infrastructure is unavailable. The VPN capability ensures encrypted communication channels, supporting secure data exchange between remote sites and central control systems.

The dual Ethernet ports allow flexible network segmentation or device interconnection, while the PoE input simplifies deployment by eliminating the need for separate power cabling. The relay alarm output can be configured to trigger alerts in case of network failure, power loss, or other critical events, enhancing system reliability and monitoring.

---

5. Components & Accessories
Included Items:
- IAR-320+ main unit (metal enclosure)
- DIN-rail mounting kit
- Wall-mount brackets (optional depending on package)
- Quick installation guide and documentation
- Terminal block for power and alarm connections

Optional Accessories:
- External antennas for WLAN and cellular interfaces (various gain options)
- PoE injector (for non-PoE network environments)
- Power adapter (12–48V DC external supply)
- SIM card for cellular connectivity (user-supplied)
- Ethernet cables and grounding accessories

Connectors:
- 2 × RJ45 Ethernet ports (10/100Base-TX)
- Power input terminal block (12–48V DC)
- PoE input via RJ45 port (IEEE 802.3af)
- Relay output terminal for alarm contact
- Antenna connectors (SMA or RP-SMA, depending on configuration)

---

6. Installation & Setup
The IAR-320+ is designed for straightforward installation in industrial environments. It supports both DIN-rail and wall-mount configurations, allowing flexible placement within control cabinets, machinery enclosures, or network racks.

Installation Requirements:
- Power source: 12–48V DC or PoE (IEEE 802.3af)
- Network connectivity: Ethernet cabling (Cat5e or higher)
- Antenna placement: Ensure adequate signal strength for WLAN and cellular operation
- Environmental conditions: Within specified temperature and humidity ranges

Setup Procedure:
1. Mount the device securely using the provided DIN-rail clip or wall-mount brackets.
2. Connect Ethernet cables to the LAN ports.
3. If using PoE, connect the Ethernet cable from a PoE switch or injector; otherwise, connect the DC power supply to the terminal block.
4. Attach WLAN and cellular antennas to the designated connectors.
5. Configure network parameters via the web-based management interface or console port (if available).
6. Set operation mode (AP, Bridge, Repeater, or AP Client) according to network design.
7. Configure VPN settings for secure remote access if required.
8. Verify connectivity and signal strength through the management interface.

The device’s configuration interface typically supports web-based management, SNMP monitoring, and firmware updates, enabling administrators to manage multiple units remotely.

---

7. Performance & Capabilities
The IAR-320+ delivers reliable performance for industrial networking applications requiring both wireless and cellular connectivity.

- Wireless Performance:
- Supports data rates up to 54 Mbps (802.11a/g) and 11 Mbps (802.11b).
- Provides stable wireless coverage suitable for factory floors, warehouses, and outdoor installations.
- Multiple operation modes allow optimization for throughput, range, or redundancy.

- Cellular VPN Performance:
- 3.5G connectivity supports HSPA/UMTS networks, enabling broadband speeds for remote data transmission.
- VPN functionality ensures secure tunneling for SCADA, telemetry, or remote management applications.
- Supports standard VPN protocols (e.g., IPsec, PPTP, L2TP, depending on firmware version).

- Wired Network Performance:
- Dual 10/100Base-TX ports provide flexible LAN/WAN configurations.
- Auto-negotiation and auto MDI/MDI-X simplify network integration.

- Power Efficiency:
- Maximum power consumption of 6W ensures low operational cost and compatibility with energy-limited environments.

- Reliability:
- Industrial-grade design ensures continuous operation under vibration, temperature variation, and electrical noise.
- Relay alarm output enhances system monitoring and fault detection.

Limitations:
- Wireless standard limited to 802.11a/b/g (no 802.11n/ac support).
- Cellular connectivity limited to 3.5G (not LTE/4G).
- Operating temperature range up to +55°C may require ventilation in high-heat environments.

---

8. Standards & Compliance
The IAR-320+ adheres to multiple international and industrial standards to ensure interoperability, safety, and reliability.

- Networking Standards:
- IEEE 802.3 (Ethernet)
- IEEE 802.3u (Fast Ethernet)
- IEEE 802.3af (Power over Ethernet, PD mode)
- IEEE 802.11a/b/g (Wireless LAN)

- Power and Safety:
- Compliant with low-voltage DC power systems (12–48V)
- Overload and reverse polarity protection (typical for industrial devices)

- Environmental and Mechanical:
- Designed for industrial temperature and humidity ranges
- Metal enclosure for EMI shielding and mechanical protection

- Regulatory Compliance:
- CE, FCC, and RoHS compliance (typical for ORing industrial products)
- Conforms to industrial EMC standards for immunity and emission

- VPN and Security Standards:
- Supports standard encryption and authentication protocols (e.g., IPsec, SSL, PPTP, L2TP)
- Compatible with enterprise-grade VPN infrastructures

---

9. Additional Information
- Warranty: Typically covered by ORing’s standard industrial product warranty (commonly 3 years, depending on region and distributor).
- Support: Comprehensive technical support available through ORing’s global network, including firmware updates, configuration assistance, and troubleshooting.
- Maintenance:
- Minimal maintenance required due to solid-state design and fanless operation.
- Periodic firmware updates recommended to maintain security and performance.
- Regular inspection of antenna connections and power terminals advised in harsh environments.
- Firmware & Updates:
- Firmware upgrades available via web interface or remote management tools.
- Updates may include enhanced VPN features, security patches, and performance optimizations.
- Lifecycle & Reliability:
- Designed for long-term industrial operation with MTBF (Mean Time Between Failures) consistent with industrial-grade standards.
- Suitable for continuous 24/7 operation in mission-critical applications.

---

Summary
The ORing IAR-320+ is a compact, rugged, and versatile industrial wireless access point and 3.5G VPN router that bridges Ethernet, WLAN, and cellular networks. With dual 10/100Base-TX ports, IEEE 802.11a/b/g wireless support, and PoE input capability, it provides flexible deployment options for industrial automation, transportation, and remote monitoring systems. Its robust metal housing, wide operating temperature range, and alarm relay output make it ideal for harsh environments requiring reliable and secure connectivity.

By integrating wireless, wired, and cellular communication in a single device, the IAR-320+ simplifies network architecture, reduces installation costs, and enhances operational reliability. It stands as a dependable solution for industrial users seeking secure, scalable, and efficient network connectivity in both fixed and mobile applications.
