1. Product Overview
Product Name: PoE Power Injector
Model: PET-102GT++
Series: Industrial Gigabit PoE Injector Series
Article Number: PET-102GT++
Manufacturer: (Not specified; typically produced by an industrial networking equipment manufacturer specializing in PoE and Ethernet connectivity solutions)

The PET-102GT++ is a compact, industrial-grade Power over Ethernet (PoE) injector designed to deliver high-power PoE capabilities in rugged environments. It supports multiple Gigabit Ethernet interfaces and provides both Powered Device (PD) and Power Sourcing Equipment (PSE) functionality, enabling flexible deployment in complex network topologies. The unit is engineered for demanding industrial applications requiring reliable power and data transmission over Ethernet, with compliance to IEEE 802.3af and IEEE 802.3at standards.

---

2. Key Features
- Dual Functionality (PD + PSE): The PET-102GT++ operates simultaneously as a Powered Device (PD) and as Power Sourcing Equipment (PSE). It can receive power from an upstream PoE source and redistribute power to downstream devices.
- High-Power PoE Output: Supports up to 90 watts per port on two PSE ports, enabling connection of high-power devices such as PTZ cameras, wireless access points, IP telephony systems, and industrial sensors.
- Triple Gigabit Ethernet Ports: Equipped with 3 × 10/100/1000Base-T(X) RJ45 ports for high-speed data transmission and flexible network integration.
- IEEE 802.3af/at Compliance: Fully compliant with PoE (15.4W) and PoE+ (30W) standards, ensuring interoperability with a wide range of PoE-enabled devices.
- Wide Input Voltage Range: Accepts dual 50–57 VDC power inputs, providing redundancy and stable operation in industrial power systems.
- Compact Mini-Type Design: Small form factor (41 × 75 × 115 mm) allows installation in space-constrained environments such as control cabinets or network enclosures.
- Rugged Industrial Construction: Built with a metal IP30-rated enclosure, offering protection against dust and mechanical impact, suitable for harsh industrial conditions.
- Oring Power Redundancy: Dual power input design with Oring diodes ensures uninterrupted operation in case of power source failure.
- High Reliability: Designed for continuous operation in mission-critical applications, with robust electrical and thermal performance.
- Plug-and-Play Operation: No software configuration required; automatically detects and powers compatible PoE devices.

---

3. Technical Specifications
- Ethernet Ports:
- 3 × 10/100/1000Base-T(X) RJ45 ports (auto-negotiation, auto MDI/MDI-X)
- 2 × PSE ports (Power Sourcing Equipment)
- 1 × PD port (Powered Device input)

- PoE Power Output:
- 2 × PSE ports @ 90 W each (maximum)
- Total PoE budget dependent on input power source capacity

- PoE Power Input (PD Port):
- 1 × PD port @ 90 W maximum input power

- Power Input:
- Dual DC input: 50–57 VDC
- Oring redundancy for uninterrupted operation

- Power Consumption:
- Dependent on connected load and PoE output utilization

- Enclosure:
- Material: Rugged metal housing
- Protection Rating: IP30 (protection against solid objects >2.5 mm, no water protection)

- Dimensions:
- Width: 41 mm
- Height: 75 mm
- Depth: 115 mm

- Weight:
- Approx. 0.5–0.7 kg (typical for metal-cased industrial injectors of this size; exact weight not specified)

- Mounting Options:
- DIN-rail or wall-mount installation (depending on accessory availability)

- Operating Temperature:
- Typically -10°C to +60°C (not specified, but standard for IP30 industrial devices)

- Storage Temperature:
- Typically -40°C to +85°C

- Humidity:
- 5%–95% non-condensing (typical industrial specification)

---

4. Functionality
The PET-102GT++ functions as a PoE power injector that bridges standard Ethernet data with power delivery over the same cable. It can receive power through its PD port from an upstream PoE switch or injector and then distribute power to downstream devices through its two PSE ports.

Operational Modes:
- PD Mode: Receives power from an upstream PoE source (e.g., PoE switch or midspan injector) via the PD port.
- PSE Mode: Supplies power to connected PoE devices (e.g., IP cameras, access points) through the two PSE ports.

Use Cases and Applications:
- Industrial automation systems requiring distributed PoE power delivery.
- Surveillance networks powering multiple IP cameras from a single PoE uplink.
- Wireless infrastructure deployments (Wi-Fi access points, point-to-point radios).
- Smart building systems integrating sensors, controllers, and IP-based devices.
- Transportation and utility monitoring systems where compact, rugged PoE injectors are needed.

Compatibility:
- Compatible with IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) devices.
- Works with standard Ethernet switches, routers, and network controllers.
- Supports auto-detection of PoE devices to prevent damage to non-PoE equipment.

---

5. Components & Accessories
Included Components:
- PET-102GT++ PoE Injector main unit
- Quick installation guide or datasheet (depending on packaging)
- Terminal block or DC power connector for dual input connection

Optional Accessories:
- DIN-rail mounting kit
- Wall-mount bracket
- External 50–57 VDC power supply (if not powered via PD port)
- Shielded Ethernet cables for industrial environments

Connectors:
- 3 × RJ45 connectors for Ethernet/PoE data and power transmission
- 2 × DC power input terminals (for dual redundant power)

---

6. Installation & Setup
Requirements:
- DC power source providing 50–57 VDC (if not powered via PD port)
- Standard Cat5e or higher Ethernet cabling for Gigabit data and PoE transmission
- Proper grounding and surge protection recommended for industrial installations

Mounting Options:
- DIN-rail mounting for control cabinets and industrial racks
- Wall-mounting for fixed installations in enclosures or network panels

Configuration:
- Plug-and-play operation; no software or firmware configuration required
- Automatic detection of PoE-compatible devices
- LED indicators (if present) typically show power and link/activity status (not specified but standard for such devices)

Setup Steps:
1. Connect the PD port to an upstream PoE switch or injector.
2. Connect the PSE ports to downstream PoE devices.
3. Connect DC power inputs if redundant power is required.
4. Verify power and data link status via LEDs or network monitoring tools.

---

7. Performance & Capabilities
- Data Rate: Supports full Gigabit Ethernet speeds (10/100/1000 Mbps) on all ports.
- PoE Power Delivery: Up to 90 W per PSE port, sufficient for high-power devices such as PTZ cameras or wireless base stations.
- Power Efficiency: High conversion efficiency due to industrial-grade power circuitry and Oring redundancy design.
- Latency: Negligible; operates as a transparent midspan injector without affecting data throughput.
- Reliability: Designed for continuous 24/7 operation in industrial environments.
- Limitations:
- IP30 rating limits use to indoor or protected environments (not waterproof).
- Requires adequate ventilation for heat dissipation.
- Total PoE output limited by available input power and thermal constraints.

---

8. Standards & Compliance
- IEEE Standards:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3af Power over Ethernet (PoE)
- IEEE 802.3at Power over Ethernet Plus (PoE+)

- Electrical Safety & EMC:
- Designed to meet industrial EMC and safety standards (specific certifications not listed but typically CE, FCC, and RoHS compliant).

- Environmental Protection:
- IP30-rated enclosure for protection against solid objects and mechanical impact.

- Industry Standards Compliance:
- Suitable for industrial automation, transportation, and building management systems adhering to standard Ethernet and PoE protocols.

---

9. Additional Information
- Warranty: Typically 2–5 years manufacturer warranty (not specified; standard for industrial networking equipment).
- Support: Technical documentation, datasheets, and installation guides available from manufacturer or distributor.
- Maintenance:
- Minimal maintenance required; periodic inspection of connectors and power inputs recommended.
- Ensure clean, dust-free environment for optimal heat dissipation.
- Firmware/Software Updates: Not applicable; device operates as a hardware-level injector without firmware dependency.
- Serviceability: Field-replaceable via standard mounting and cabling; no internal service required.
- Lifecycle: Designed for long-term industrial deployment with high MTBF (Mean Time Between Failures).

---

Summary
The PET-102GT++ PoE Power Injector is a high-performance, industrial-grade device that combines the roles of a Powered Device and Power Sourcing Equipment in a compact, rugged form factor. With three Gigabit Ethernet ports, dual 90W PoE outputs, and a 90W PD input, it provides exceptional flexibility for powering and connecting multiple network devices in industrial and commercial environments. Its dual 50–57 VDC input design with Oring redundancy ensures continuous operation, while the IP30-rated metal housing guarantees durability under demanding conditions.

Engineered for reliability, efficiency, and ease of integration, the PET-102GT++ is ideal for applications such as industrial automation, surveillance, and smart infrastructure where robust PoE power delivery and Gigabit connectivity are essential.
