- **Intel® Core™ i5-3610ME Processor:** Dual-core, 2.7 GHz base frequency (up to 3.3 GHz Turbo Boost), 3 MB cache, Ivy Bridge architecture for high performance and energy efficiency. - **Fanless Low-Profile Design:** 240 mm (W) × 225 mm (D) × 69 mm (H) chassis with passive cooling for silent and maintenance-free operation. - **Dual 2.5” SATA III Storage:** One internal 2.5” SATA III bay and one external hot-swappable 2.5” HDD/SSD tray for flexible storage management. - **Five Intel® I210 Gigabit Ethernet Ports:** Each port supports 9.5 KB jumbo frames; optional Power-over-Ethernet (PoE) capability on four ports compliant with IEEE 802.3af. - **Wide Temperature Range:** Operates from -25°C to +70°C at 100% CPU load (with i5-3610ME). - **Rugged Construction:** Vibration resistance up to 5 Grms (5–500 Hz, 3 axes) and shock resistance up to 50 Grms (half-sine, 11 ms). - **Dual Independent Display Outputs:** VGA (2048×1536) and dual DVI-D (1920×1080) outputs driven by Intel® HD Graphics 4000. - **Rich I/O Connectivity:** 2× USB 3.0, 2× USB 2.0, 1× RS-232/422/485 (software-programmable), PS/2 keyboard/mouse, audio I/O, and external CFast slot. - **Expansion Capability:** Two Mini PCI Express slots (one with SIM card socket) for wireless, GPS, or other expansion modules. - **Optional Isolated Digital I/O:** 8× isolated digital inputs and 8× isolated digital outputs with Change-of-State (COS) interrupt support. - **Flexible Power Input:** 8–25 VDC wide-range input with optional 120 W AC/DC adapter. - **High Reliability:** MTBF of 93,732 hours, CE/FCC Class A compliance, and industrial-grade components.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **High-Performance Quad-Core CPU:** Equipped with Intel® Core™ i7-3610QE (2.3 GHz base / 3.3 GHz Turbo, 6 MB cache), delivering exceptional computing and graphics performance for embedded and industrial workloads. - **Low-Profile Fanless Design:** Compact 240 mm (W) × 225 mm (D) × 69 mm (H) chassis, ideal for space-constrained installations such as vehicles, kiosks, or control cabinets. - **Dual 2.5” SATA Storage with Hot-Swap Capability:** One fixed internal 2.5” SATA III HDD/SSD bay and one external hot-swappable 2.5” SATA III tray for easy maintenance and data exchange. - **Multiple Gigabit Ethernet Ports:** Five Intel® I210 Gigabit Ethernet ports supporting 9.5 KB jumbo frames; optional Power over Ethernet (PoE) on four ports compliant with IEEE 802.3af. - **Wide Operating Temperature Range:** Fanless operation from -25°C to +60°C (with i7 CPU) or up to +70°C (with i5/Celeron CPUs) under 100% CPU load. - **Rugged Industrial Reliability:** Vibration resistance up to 5 Grms (5–500 Hz, 3 axes) and shock resistance up to 50 Grms (half-sine, 11 ms) per IEC60068-2-64/27 standards. - **Rich I/O Connectivity:** Includes USB 3.0/2.0, RS-232/422/485, PS/2, audio, CFast, and isolated digital I/O options. - **Dual Independent Display Outputs:** VGA (2048×1536) and dual DVI-D (1920×1080) outputs supporting simultaneous dual-display operation. - **Expansion Flexibility:** Two Mini PCI Express slots (one with SIM socket) for wireless, GPS, or RAID modules. - **Optional Features:** - 4× PoE P.S.E. (IEEE 802.3af compliant) - 8× isolated DI and 8× isolated DO with COS interrupt - Ignition power control for in-vehicle applications - DIN-rail mounting kit

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Intel® 3rd-Gen Core™ i7/i5/Celeron® Processors:** Supports i7-3610QE (2.3/3.3 GHz, 6 MB cache), i5-3610ME (2.7/3.3 GHz, 3 MB cache), and Celeron® 1020E (2.2 GHz, 2 MB cache). - **Fanless Low-Profile Design:** 69 mm chassis height optimized for space-constrained installations with efficient passive cooling. - **Wide Temperature Operation:** -25°C to +70°C (with i5/Celeron CPU) and -25°C to +60°C (with i7 CPU) under 100% CPU load. - **Power over Ethernet (PoE):** Four of the five Intel® I210 Gigabit Ethernet ports support IEEE 802.3af PoE P.S.E. functionality for powering IP cameras or network devices. - **Dual Independent Display Outputs:** VGA (2048×1536) and dual DVI-D (1920×1080) outputs driven by Intel® HD Graphics 4000. - **Flexible Storage Options:** One internal 2.5" SATA III HDD/SSD and one external hot-swappable 2.5" SATA III HDD/SSD tray. - **Expansion Capability:** Two Mini PCIe slots (one with SIM socket) for wireless, GPS, or I/O expansion. - **Optional Isolated DIO:** 8 isolated digital inputs and 8 isolated digital outputs with Change-of-State (COS) interrupt support. - **Rugged Reliability:** Vibration resistance up to 5Grms and shock resistance up to 50Grms (SSD configuration). - **Wide DC Input Range:** 8–25 VDC input with optional ignition power control for in-vehicle use. - **Long MTBF:** 93,732 hours, ensuring long-term reliability in mission-critical deployments.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Intel® Ivy Bridge Platform:** Supports Intel® Core™ i7‑3610QE (2.3/3.3 GHz, 6 MB cache), i5‑3610ME (2.7/3.3 GHz, 3 MB cache), and Celeron® 1020E (2.2 GHz, 2 MB cache). - **Fanless Design:** Fully fanless aluminum chassis for silent, dust‑resistant, and maintenance‑free operation. - **Cassette Expansion Architecture:** Integrated PCI slot in a removable cassette for easy installation of add‑on cards with minimal thermal interference. - **High Network Connectivity:** Five Intel® I210 Gigabit Ethernet ports, each with a dedicated PCIe lane for maximum throughput. - **Optional PoE Support:** Four ports can be configured with IEEE 802.3af Power‑over‑Ethernet (PSE) functionality. - **Rich I/O Interface:** 4 × USB 3.0, 4 × USB 2.0, 2 × RS‑232/422/485 (software‑selectable), PS/2, audio I/O, and external CFast slot. - **Triple Independent Display:** VGA (2048 × 1536) and dual DVI‑I outputs supporting DVI/HDMI up to 1920 × 1200 or DisplayPort up to 2560 × 1600. - **Dual Mini‑PCIe Slots:** One full‑size slot with SIM socket for 3G/4G/Wi‑Fi/GPS modules, and one additional slot for expansion. - **Wide Temperature Operation:** ‑25 °C to +70 °C (with i5/i3 CPUs) or up to +60 °C (with i7 CPU). - **Rugged Reliability:** Vibration tolerance up to 5 Grms and shock resistance up to 50 Grms (SSD configuration). - **Optional Isolated DIO:** 8 × isolated digital inputs and 8 × isolated digital outputs with 2500 Vrms isolation and Change‑of‑State interrupt capability. - **Ignition Power Control (Optional):** MCU‑based ignition sensing with programmable on/off delay for in‑vehicle applications. - **Wide‑Range DC Input:** 8 – 25 V DC input via 4‑pin mini‑DIN or 3‑pin terminal block; optional 120 W AC/DC adapter. - **Compact Industrial Form Factor:** 240 × 225 × 88 mm, wall‑mount or DIN‑rail installation.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Intel® Core™ i5-3610ME Processor:** Dual-core, 2.7 GHz base frequency (up to 3.3 GHz Turbo), 3 MB cache, 35W TDP. - **Fanless Operation:** Passive cooling design ensures silent, maintenance-free operation from -25°C to +70°C (with i5 CPU). - **Rugged Design:** Vibration resistance up to 5 Grms and shock resistance up to 50 Grms (with SSD). - **High Network Connectivity:** 5× Intel® I210 Gigabit Ethernet ports, optional 4× PoE P.S.E. ports compliant with IEEE 802.3af. - **Flexible Expansion:** 1× PCI slot via patented expansion cassette; 2× Mini PCIe slots (one with SIM socket). - **Rich I/O Interface:** 4× USB 3.0, 4× USB 2.0, 2× RS-232/422/485, VGA, dual DVI-I, PS/2, audio I/O, and external CFast slot. - **Graphics Capability:** Integrated Intel® HD Graphics 4000 supporting triple independent displays (VGA + 2× DVI/HDMI). - **Storage Options:** 1× internal 2.5" SATA III HDD/SSD bay; 1× CFast slot for removable storage. - **Optional Features:** - Isolated 8× DI and 8× DO with Change-of-State (COS) interrupt. - Intelligent ignition power control for in-vehicle applications. - Smart fan option for expansion cassette. - **Power Flexibility:** 8–25 VDC input range with optional 120W or 160W AC/DC adapter. - **Reliability:** MTBF of 93,732 hours. - **Compact Form Factor:** 240 × 225 × 88 mm, 4.4 kg including HDD and RAM.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **High‑Performance Quad‑Core CPU:** Equipped with Intel® Core™ i7‑3610QE (2.3 GHz base / 3.3 GHz Turbo, 6 MB cache), delivering exceptional multi‑threaded performance for compute‑intensive tasks such as video analytics, machine vision, and data acquisition. - **Fanless Thermal Design:** Completely fanless operation ensures silent performance and long‑term reliability in dusty or vibration‑prone environments. The system operates from ‑25 °C to +60 °C (up to +70 °C with lower‑TDP CPUs). - **Flexible Expansion via Patented Cassette Architecture:** The Nuvo‑3005P features a modular expansion cassette with a 32‑bit/33 MHz PCI slot, allowing easy installation of add‑on cards while maintaining optimal thermal isolation between the main system and expansion module. - **Rich I/O Connectivity:** Includes 5× Intel® I210 Gigabit Ethernet ports, 4× USB 3.0, 4× USB 2.0, 2× RS‑232/422/485 serial ports, VGA, dual DVI‑I outputs, PS/2, audio I/O, and external CFast slot. - **Optional PoE and DIO Support:** Supports up to 4× or 8× PoE ports (IEEE 802.3af compliant) for powering IP cameras or sensors. Optional isolated 8× DI and 8× DO channels with Change‑of‑State (COS) interrupt capability. - **Intelligent Ignition Power Control (Optional):** Designed for in‑vehicle applications, offering programmable on/off delay modes, low‑battery protection, and smart power‑off management. - **Wide Power Input Range:** Accepts 8 – 25 V DC input via 4‑pin Mini‑DIN or 3‑pin terminal block, with optional 120 W or 160 W AC/DC adapters. - **Rugged Reliability:** Vibration resistance up to 5 Grms (IEC 60068‑2‑64) and shock resistance up to 50 Grms (IEC 60068‑2‑27). MTBF rated at 93,732 hours. - **Triple Independent Display:** Integrated Intel® HD Graphics 4000 supports VGA (2048×1536) and dual DVI/HDMI outputs (up to 1920×1200 or 2560×1600 via DisplayPort).

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Intel® 3rd‑Gen Core™ i7/i5/i3 CPU Support:** Compatible with Intel® Core™ i7‑3610QE (2.3/3.3 GHz, 6 MB cache), i5‑3610ME (2.7/3.3 GHz, 3 MB cache), and Celeron® 1020E (2.2 GHz, 2 MB cache). Optional support for other Ivy Bridge processors per Intel’s embedded roadmap. - **Fanless Thermal Design:** Completely fanless aluminum chassis with conduction cooling, enabling silent operation and high reliability in harsh environments. - **Dual Storage Capability:** Supports one 2.5″ SATA III HDD/SSD and one 3.5″ SATA HDD via an integrated cassette with shock‑absorbing bracket and thermal isolation chamber. - **High‑Speed Networking:** Five Intel® I210 Gigabit Ethernet ports, with optional Power‑over‑Ethernet (PoE) P.S.E. support on four ports (IEEE 802.3af compliant). - **Rich I/O Connectivity:** 4 × USB 3.0, 4 × USB 2.0, 2 × RS‑232/422/485 software‑programmable serial ports, PS/2 keyboard/mouse, audio I/O, and external CFast slot. - **Advanced Graphics:** Integrated Intel® HD Graphics 4000 supporting triple independent displays via VGA (2048 × 1536) and dual DVI‑I (up to 1920 × 1200 or 2560 × 1600 via DP). - **Expansion Flexibility:** Two internal Mini‑PCI Express slots (one with SIM socket) for wireless, GPS, or RAID modules. - **Wide‑Range DC Power Input:** Accepts 8 – 25 V DC via 4‑pin Mini‑DIN or 3‑pin terminal block; optional ignition control for in‑vehicle use. - **Rugged Environmental Endurance:** Operating temperature −25 °C to +70 °C (CPU‑dependent), vibration resistance 5 Grms, shock resistance 50 Grms. - **Optional Isolated Digital I/O:** 8 × isolated DI and 8 × isolated DO channels with 2500 Vrms isolation and Change‑of‑State (COS) interrupt support. - **Compact, Industrial‑Grade Construction:** Dimensions 240 × 225 × 85.5 mm, weight ≈ 4.2 kg, wall‑mount or DIN‑rail installation.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Fanless Industrial Design:** Passive cooling architecture ensures silent operation and long‑term reliability in dusty or vibration‑prone environments. - **Intel® Core™ i5‑3610ME Processor:** Dual‑core, 4‑thread CPU with 3 MB cache, 2.7 GHz base frequency, and up to 3.3 GHz turbo boost. - **Intel® HM76 Chipset:** Provides stable platform control and supports advanced I/O and storage interfaces. - **Integrated Intel® HD Graphics 4000:** Supports VGA (2048×1536) and dual DVI‑I outputs (up to 2560×1600 via DP, 1920×1080 via DVI/HDMI). - **Dual Storage Capability:** Accommodates one 2.5″ SATA III SSD/HDD and one 3.5″ SATA HDD for terabyte‑class storage. - **Five Intel® I210 Gigabit Ethernet Ports:** Dedicated PCIe lanes for each port ensure maximum throughput; optional 4‑port PoE (IEEE 802.3af) support. - **Rich I/O Connectivity:** 4× USB 3.0, 4× USB 2.0, 2× RS‑232/422/485 (software‑selectable), PS/2, audio I/O, and external CFast slot. - **Expansion Flexibility:** Two Mini‑PCIe slots (one with SIM socket) for wireless, GPS, or RAID modules. - **Optional Isolated Digital I/O:** 8× DI and 8× DO channels with 2500 Vrms isolation and Change‑of‑State (COS) interrupt support. - **Wide Temperature Operation:** ‑25 °C to +70 °C (with i5‑3610ME) at 100 % CPU load. - **Rugged Mechanical Design:** Vibration resistance up to 5 Grms and shock resistance up to 50 Grms (SSD configuration). - **Wide‑Range DC Input:** 8 – 25 V DC with built‑in power circuitry; optional 120 W AC/DC adapter. - **Compact Form Factor:** 240 × 225 × 86 mm, 3.4 kg including HDD and RAM. - **Long MTBF:** 93 732 hours for high reliability in continuous operation. - **Applications:** Industrial control, machine vision, intelligent transportation, surveillance, and video analytics.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **High‑Performance Embedded Computing:** Equipped with Intel® Core™ i7‑3610QE (2.3/3.3 GHz, 6 MB cache) processor, delivering quad‑core performance for compute‑intensive industrial tasks. - **Fanless Thermal Design:** Passive conduction‑cooled chassis ensures silent operation and long‑term reliability in harsh environments. - **Dual Storage Support:** Accommodates one 2.5" SATA III SSD/HDD and one 3.5" SATA HDD via an integrated cassette with shock‑absorbing bracket and thermal isolation chamber. - **Rich I/O Connectivity:** Five Intel® I210 Gigabit Ethernet ports (four optionally PoE‑enabled), four USB 3.0, four USB 2.0, two RS‑232/422/485 ports, PS/2, audio I/O, and external CFast slot. - **Multiple Display Outputs:** Integrated Intel® HD Graphics 4000 supports VGA (2048×1536) and dual DVI‑I outputs (up to 2560×1600 DP or 1920×1080 DVI/HDMI). - **Expansion Flexibility:** Two Mini‑PCIe slots (one with SIM socket) for wireless, GPS, or RAID modules. - **Industrial‑Grade Reliability:** Operating temperature from ‑25 °C to +60 °C (i7) or +70 °C (i5/Celeron), vibration resistance up to 5 Grms, and shock tolerance up to 50 Grms. - **Wide‑Range DC Power Input:** Accepts 8–25 V DC via 4‑pin mini‑DIN or 3‑pin terminal block; optional 120 W AC/DC adapter available. - **Optional Features:** – 8 × isolated digital inputs and 8 × isolated digital outputs with COS interrupt – 4 × PoE P.S.E. ports compliant with IEEE 802.3af – Ignition power control for in‑vehicle applications

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Intel® 3rd-Gen Core™ i7/i5/i3 Processor Support:** Supports PGA-type CPUs including i7-3610QE, i5-3610ME, and Celeron 1020E, offering scalable performance options. - **Configurable CPU Power Mode:** Unique BIOS-configurable feature allowing users to select between *Maximal Performance*, *Reduced Performance*, or *Extended Temperature* modes to balance thermal conditions and computing power. - **Fanless, Compact Design:** Ultra-compact chassis (212 × 165 × 62 mm) with passive cooling for silent, maintenance-free operation. - **In-Vehicle Power Management:** Wide-range 8–35 VDC input with ignition power control and user-selectable on/off delay, supporting 12V/24V vehicle systems. - **Power over Ethernet (PoE):** Four IEEE 802.3at-compliant Gigabit Ethernet ports (25.5W per port, 75W total budget) for powering IP cameras or sensors directly. - **Dual SATA Storage with RAID Support:** One internal 2.5" SATA III bay and one hot-swappable 2.5" HDD/SSD tray, supporting RAID 0/1 configurations. - **Rich I/O Connectivity:** Includes 4× USB 3.0, 2× USB 2.0, 2× RS-232/422/485 serial ports, isolated digital I/O (4 DI / 4 DO), audio I/O, and triple independent display outputs (DVI-I + 2× DisplayPort). - **Expansion Flexibility:** Two Mini PCI Express slots (1 full-size with USIM socket, 1 half-size) and one full-size mSATA slot with SIM support for wireless modules (3G/4G/LTE/GPS). - **Rugged Environmental Design:** Operating temperature range from -25°C to +70°C (depending on CPU and mode), vibration resistance up to 5 Grms, and shock resistance up to 50 Grms. - **Certifications:** E-Mark for in-vehicle compliance, CE/FCC Class A, and EN 50155/EN 50121-3-2 railway standards.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **High‑Performance CPU Support:** Supports Intel® Core™ i7‑3610QE (2.3/3.3 GHz, 6 MB cache), i5‑3610ME (2.7/3.3 GHz, 3 MB cache), and Celeron® 1020E (2.2 GHz, 2 MB cache). PGA‑type socket allows flexible CPU selection and replacement. - **Intel® QM77 Chipset with AMT & RAID:** Provides Intel® Active Management Technology (AMT) for remote management and hardware RAID 0/1 support for data redundancy or performance. - **Fanless Thermal Design:** Passive aluminum heat‑sink chassis ensures silent operation and high reliability in harsh environments without moving parts. - **Configurable CPU Power Mode:** BIOS‑selectable modes—Maximal Performance, Reduced Performance, and Extended Temperature—balance computing power and thermal range. - Max Performance: up to 50 °C (i7‑3610QE) - Reduced Performance: up to 60 °C - Extended Temperature: up to 70 °C - **Wide‑Range DC Input (8–35 V):** Built‑in power supply with 3‑pin terminal block supports 12 V/24 V vehicle systems. - **Ignition Power Control:** Intelligent MCU‑based ignition control with user‑selectable on/off delay, smart off‑delay, low‑battery protection, and hard‑off timeout. BIOS‑configurable in later revisions. - **Rich I/O Connectivity:** - 4× Gigabit Ethernet ports (1× Intel® 82579LM + 3× Intel® I210) - 4× USB 3.0, 2× USB 2.0 - 2× RS‑232/422/485 software‑programmable COM ports - 4× isolated digital inputs and 4× isolated digital outputs - Audio (Mic‑in, Speaker‑out) - 1× DVI‑I, 2× DisplayPort for triple independent display - **Storage Flexibility:** - 1× internal 2.5″ SATA III HDD/SSD - 1× external 2.5″ SATA III hot‑swappable HDD tray - 1× full‑size mSATA (SATA/USB/W_DISABLE#) with USIM socket - **Expansion Capability:** - 1× full‑size Mini‑PCIe with USIM socket - 1× half‑size Mini‑PCIe slot - External CFast slot - **Rugged Environmental Design:** - Operating temperature: −25 °C to +70 °C (depending on CPU mode) - Vibration: 5 Grms, 5–500 Hz, 3 axes (IEC 60068‑2‑64) - Shock: 50 Grms, 11 ms half‑sine (IEC 60068‑2‑27) - **Certifications:** E‑Mark for in‑vehicle use, CE/FCC Class A, EN 55022/55024 compliance.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Intel® 3rd‑Generation Core™ i7/i5/i3 PGA‑Type Processor Support:** Supports standard‑voltage (35 W/45 W TDP) CPUs for higher performance compared to low‑voltage BGA‑type processors. - **Configurable CPU Power Mode:** User‑selectable modes—Maximal Performance, Reduced Performance, and Extended Temperature—allow optimization between computing power and operating temperature. - **Ultra‑Compact Fanless Design:** 212 mm (W) × 165 mm (D) × 62 mm (H) aluminum chassis with passive cooling for silent, maintenance‑free operation. - **Rich I/O in Compact Form:** Dual Intel® Gigabit Ethernet ports, six USB ports (4 × USB 3.0, 2 × USB 2.0), two serial ports (software‑programmable RS‑232/422/485), isolated digital I/O, and audio I/O. - **Triple Independent Display Outputs:** One DVI‑I (VGA/DVI) and two DisplayPort connectors supporting up to 2560 × 1600 resolution. - **Wide‑Range DC Power Input:** 8 – 35 V DC input via 3‑pin terminal block, suitable for vehicle and industrial power systems. - **Optional Ignition Power Control:** BIOS‑configurable ignition on/off delay for in‑vehicle power management. - **High Environmental Tolerance:** Operating temperature from –25 °C to +70 °C (depending on CPU and mode), vibration resistance 5 Grms, shock resistance 50 Grms. - **Expansion Flexibility:** Two Mini‑PCIe slots (one full‑size with USIM socket, one half‑size) and one full‑size mSATA slot with USIM socket for wireless or storage expansion. - **Industrial‑Grade Reliability:** Meets CE/FCC Class A standards; designed for 24/7 operation in harsh environments.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Intel® 3rd‑Gen Core™ i7/i5 CPU Support:** Compatible with Intel® Core™ i7‑3610QE (2.3/3.3 GHz, 6 MB cache) and i5‑3610ME (2.7/3.3 GHz, 3 MB cache), offering high‑performance quad‑core processing for video analytics and real‑time encoding. - **Fanless Thermal Design:** Neousys’ patented fanless architecture ensures silent operation and reliable performance in harsh environments, supporting wide‑temperature operation from ‑25 °C to +60 °C at full CPU load. - **8× IEEE 802.3at PoE+ Ports:** Each port delivers up to 25.5 W with per‑port power on/off control and a total power budget of 80 W, enabling direct connection and powering of IP cameras (bullet, dome, or PTZ). - **Integrated RAID Storage:** Four internal SATA ports for 2.5" HDD/SSD with RAID 0/1/5/10 support. Two drives are accessible via easy‑swap trays for simplified maintenance. - **Wide‑Range DC Input (8–35 V):** Built‑in 3‑pin terminal block input with ignition power control for in‑vehicle or field deployment. - **Rich I/O Connectivity:** Includes 1× Intel® 82579LM GbE port (non‑PoE, AMT‑enabled), 2× USB 3.0, 2× USB 2.0, 2× RS‑232/422/485, 1× VGA, 2× DVI‑D, PS/2, audio I/O, and CFast socket. - **Dual Independent Display:** Intel® HD Graphics 4000 supports up to two simultaneous displays via DVI‑D and VGA outputs. - **Ignition Power Control:** MCU‑based ignition management with configurable on/off delay, low‑battery protection, and hard‑off timeout for automotive applications. - **Rugged Reliability:** Vibration resistance up to 5 Grms (IEC 60068‑2‑64) and shock resistance up to 50 Grms (IEC 60068‑2‑27) with SSD. - **Compact, Industrial‑Grade Chassis:** Aluminum alloy enclosure, wall‑mountable, 240 × 255 × 70 mm, 5 kg.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **High‑Performance Processing:** Supports Intel® 3rd‑Generation Core™ i7‑3610QE (2.3/3.3 GHz, 6 MB cache) or Core™ i5‑3610ME (2.7/3.3 GHz, 3 MB cache) CPUs, providing quad‑core computing for intensive video analytics. - **Intel® QM77 Chipset:** Integrated Platform Controller Hub with Intel® AMT and hardware RAID 0/1/5/10 support. - **Fanless Architecture:** Proven Neousys fanless thermal design ensures silent operation and reliability in harsh environments from –25 °C to +60 °C at full CPU load. - **16 × PoE+ Ports:** Sixteen IEEE 802.3at‑compliant Gigabit Ethernet ports (25.5 W each, 160 W total budget) with per‑port power on/off control for IP cameras or powered devices. - **Integrated RAID Storage:** Four × 2.5″ SATA HDD/SSD bays supporting RAID 0/1/5/10; two bays feature patented easy‑swap trays for quick drive replacement. - **Wide‑Range DC Input & Ignition Control:** 8 – 35 V DC input via 3‑pin terminal block with ignition‑signal‑based power sequencing for in‑vehicle use. - **Dual Independent Displays:** Intel® HD Graphics 4000 with 1 × VGA (2048 × 1536) and 2 × DVI‑D (1920 × 1200) outputs. - **Expansion Capability:** Two internal Mini PCI Express slots (one with USIM socket) for Wi‑Fi, 3G/4G, GPS, or RAID modules. - **Rugged Design:** CE/FCC Class A certified, E‑Mark approved for automotive environments, vibration resistance 5 Grms (IEC 60068‑2‑64), shock resistance 50 Grms (IEC 60068‑2‑27). - **Comprehensive I/O:** 1 × Intel 82579LM GbE port (with AMT), 2 × USB 3.0, 2 × USB 2.0, 2 × RS‑232/422/485, 1 × PS/2, 1 × Mic‑in, 1 × Speaker‑out, 1 × CFast socket.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Isolated Digital I/O Expansion:** Provides 8 optically isolated digital inputs and 8 optically isolated digital outputs for robust signal integrity and electrical protection. - **Interrupt Support:** Supports interrupt-driven I/O operations, allowing real-time event detection and response for time-critical applications. - **Compatibility:** Fully compatible with **Nuvo-3005TB**, **Nuvo-3005E**, and **Nuvo-3005P** embedded controller models within the Nuvo-3000 series. - **Industrial-Grade Design:** Engineered for rugged environments, ensuring stable operation under industrial temperature ranges and electrical noise conditions. - **Flexible Integration:** Designed as an optional module that can be easily integrated into existing Nuvo-3000 systems without additional external hardware. - **High Reliability:** Optical isolation between input/output channels and system logic prevents ground loops and protects against voltage transients. - **Compact Form Factor:** Optimized for embedded system integration, maintaining the compact footprint of the Nuvo-3000 platform. - **Ease of Configuration:** Plug-and-play compatibility with Nuvo-3000 BIOS and software utilities for straightforward setup and configuration.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Ignition-Controlled Power Management:** Enables the Nuvo-3000 system to automatically power on or off in response to an external ignition signal, ensuring seamless integration with vehicle or machine power systems. - **Adjustable On/Off Delay:** Provides configurable delay times for both power-on and power-off sequences, allowing users to fine-tune system behavior to match operational requirements and prevent abrupt shutdowns. - **System Status Awareness:** The ignition control logic monitors system status to ensure safe power transitions, reducing the risk of data loss or hardware damage. - **Vehicle and Mobile Application Ready:** Designed for automotive, transportation, and mobile industrial environments where ignition-based power control is required. - **Integration with Nuvo-3000 Series:** Fully compatible with Nuvo-3000 TB, E, P, and PoE models, ensuring plug-and-play functionality without additional hardware modifications. - **Enhanced System Reliability:** Prevents premature system shutdowns during transient ignition signal losses and ensures stable operation during vehicle start-up or power fluctuations. - **Energy Efficiency:** Automatically powers down the system when ignition is off, reducing unnecessary power consumption and extending system lifespan. - **User-Configurable Parameters:** Allows customization of delay intervals and response behavior through system BIOS or software utilities (depending on system configuration).

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Integrated PCIe Graphics Solution:** Incorporates an NVIDIA GeForce GT 730 GPU on a PCI Express interface, offering a balance of performance, efficiency, and compatibility for embedded systems. - **Patented Expansion Cassette Design:** Utilizes Neousys’ proprietary expansion cassette architecture, allowing easy installation, secure mechanical integration, and efficient thermal management within the Nuvo-3000E chassis. - **Back-to-Back Thermal Heat Sink Solution:** Features a dual-sided heat dissipation design that ensures optimal thermal performance even under continuous high-load operation, maintaining stable GPU temperatures in confined industrial environments. - **Smart Fan Integration:** Equipped with a smart fan control mechanism that dynamically adjusts fan speed based on thermal conditions, reducing noise and extending component lifespan. - **Optimized for Nuvo-3000E Series:** Designed exclusively for the Nuvo-3000E embedded controller series, ensuring perfect mechanical fit, electrical compatibility, and thermal balance. - **Enhanced Graphics Performance:** Provides hardware acceleration for video playback, 2D/3D rendering, and GPU computing tasks, improving system responsiveness and visual output quality. - **Multi-Display Support:** Supports multiple display outputs (depending on GT 730 configuration), enabling extended desktop or mirrored display setups for industrial HMI, digital signage, or machine vision applications. - **Industrial Reliability:** Built for continuous operation in harsh environments, with robust mechanical design and efficient cooling to ensure long-term stability.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Integrated PoE+ Expansion:** Incorporates the Neousys PCIe-PoE4+ card, providing four IEEE 802.3at-compliant Gigabit Ethernet ports with PoE+ power sourcing capability (up to 25.5 W per port). - **Patented Expansion Cassette Design:** Utilizes Neousys’ proprietary expansion cassette system, allowing modular integration of PCIe cards while maintaining system compactness and thermal efficiency. - **Back-to-Back Thermal Heat Sink Solution:** Features a dual-sided heat dissipation structure that ensures optimal thermal performance for both the main system and the expansion module, enabling fanless operation. - **Smart Fan Integration:** Includes a smart fan mechanism for active cooling when required, automatically adjusting fan speed based on thermal conditions to maintain optimal performance and reliability. - **Seamless Compatibility:** Designed exclusively for the Nuvo-3000E Series, ensuring mechanical, electrical, and thermal compatibility without additional modification. - **Industrial-Grade Reliability:** Built for continuous operation in industrial environments, supporting fanless operation from 0°C to 55°C ambient temperature. - **High-Speed Data Transmission:** Each PoE+ port supports Gigabit Ethernet connectivity, ensuring high bandwidth for data-intensive applications such as machine vision and industrial automation. - **Simplified Power Management:** Provides centralized power delivery to connected PoE devices, reducing cabling complexity and external power supply requirements.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Integrated 4-Port USB 3.0 Expansion:** Provides four SuperSpeed USB 3.0 ports for high-speed data transfer and peripheral connectivity. - **High Bandwidth Performance:** Supports an aggregate throughput of **2 GB/s**, ensuring full-speed operation across all ports simultaneously. - **PCIe Interface:** Utilizes a PCI Express connection for stable, high-bandwidth communication with the host system. - **Neousys Patented Expansion Cassette:** Designed for seamless integration into Neousys embedded systems, enabling modular expansion without compromising system integrity or cooling efficiency. - **Back-to-Back Thermal Heat Sink Solution:** Innovative dual-sided heat dissipation mechanism that enhances thermal performance and maintains fanless operation. - **Fanless Operation:** Optimized for silent, maintenance-free operation in industrial environments, with an operating temperature range of **0°C to 55°C**. - **Industrial-Grade Reliability:** Built for continuous operation in demanding applications such as automation, machine vision, and data acquisition. - **Compact and Integrated Design:** Fits within the Nuvo-3000E chassis without external cabling or additional power requirements. - **Plug-and-Play Compatibility:** Fully compatible with the Nuvo-3000E platform, supporting immediate recognition and operation upon installation.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Integrated PoE Functionality:** Adds four Gigabit Ethernet (GbE) ports with IEEE 802.3af-compliant Power over Ethernet capability, each capable of delivering up to 15.4 W of power to connected devices such as IP cameras, sensors, or wireless access points. - **Isolated Digital I/O:** Provides 8 isolated digital input (DI) channels and 8 isolated digital output (DO) channels for robust signal interfacing with industrial control systems, sensors, and actuators. - **Software-Controlled Power Management:** Each PoE port’s power output can be individually switched on or off through software control, allowing flexible power management and remote device control. - **Enhanced Connectivity:** Expands the Nuvo-3005 series’ networking capabilities by transforming the system into a fanless embedded computer with four PoE-enabled GbE ports and one standard GbE port. - **Industrial-Grade Design:** Engineered for reliable operation in industrial environments, maintaining electrical isolation and stable power delivery. - **Seamless Integration:** Designed as an on-board option module for factory integration; not field retrofittable, ensuring optimal performance and reliability when installed during system assembly. - **Compliance with IEEE Standards:** Fully compliant with IEEE 802.3af PoE standard for interoperability with a wide range of PoE-powered devices.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Dedicated Cooling Solution for Expansion Cassette:** The Opt S-FAN is engineered to provide targeted airflow to the expansion area of the Nuvo-3000E/P, ensuring optimal thermal management for add-on cards. - **Enhanced Thermal Performance:** By actively dissipating heat from high-power PCIe or PCI add-on cards, the fan prevents thermal throttling and extends component lifespan. - **Optimized for High-Power Add-On Cards:** Recommended for use with expansion cards consuming more than 5 W, ensuring stable operation under continuous industrial workloads. - **Seamless Integration:** Designed as an official optional accessory, the Opt S-FAN fits precisely within the Nuvo-3000E/P chassis without requiring structural modifications. - **Quiet and Efficient Operation:** The fan provides effective cooling while maintaining low acoustic noise levels, suitable for industrial and embedded environments. - **Improved System Reliability:** By maintaining lower operating temperatures, the Opt S-FAN contributes to overall system stability and reduces the risk of thermal-induced failures. - **Plug-and-Play Compatibility:** The fan connects directly to the system’s internal power interface, simplifying installation and ensuring immediate functionality.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series

- **Four Independent Gigabit Ethernet Ports:** Each port is powered by a dedicated Intel® 82574L controller, ensuring stable, high-throughput data transfer and low-latency communication. - **Power over Ethernet (PoE) Support:** Delivers both data and electrical power over standard Ethernet cables, simplifying cabling and installation for PoE-enabled devices such as IP cameras, sensors, and industrial controllers. - **PCI Express x4 Interface:** Utilizes a PCIe Gen2 x4 slot for high-speed data transfer between the host system and the network interfaces, ensuring optimal performance for bandwidth-intensive applications. - **Integrated PoE Power Management:** Provides up to 48 W total power budget shared across four ports, compliant with IEEE 802.3af PoE standards. - **Industrial-Grade Design:** Built for reliability and durability in harsh environments, with extended temperature tolerance and robust electrical design. - **Scalable Network Expansion:** When integrated with systems like the Nuvo-3005E, the card adds four additional Gigabit PoE ports, expanding total network connectivity without external switches. - **Intel® 82574L Controller Advantages:** Proven chipset offering advanced features such as checksum offload, interrupt moderation, and support for multiple queues, enhancing network efficiency and CPU utilization. - **Plug-and-Play Compatibility:** Fully compatible with major operating systems and industrial computing platforms supporting PCIe expansion.

Hersteller: Neousys Technology

Kategorie: Nuvo-3000-Series
