- **Opto-Isolated I/O:** Both input and output channels are optically isolated to protect the host PC from electrical noise, surges, and ground potential differences. - **32 Digital Inputs / 32 Digital Outputs:** Provides 64 total I/O points (32 inputs, 32 outputs) with independent isolation and common lines per 16 channels. - **Negative Logic Configuration:** Supports current sinking (negative logic) operation. The 32 outputs share a positive common line. - **High Noise Immunity:** Opto-coupler isolation ensures stable operation in electrically noisy industrial environments. - **Interrupt Functionality:** All 32 input signals can be configured as interrupt sources. The board consolidates 32 interrupt signals into a single interrupt request (IRQ) line, INTA. - **Digital Filtering:** Built-in digital filter prevents false triggering due to noise or signal chattering, improving input reliability. - **Surge and Overcurrent Protection:** Output transistors include integrated protection circuits (Zener diode and polyswitch) to guard against voltage surges and overcurrent conditions. - **PCI Express Interface:** Fully compliant with PCI Express Base Specification Rev. 1.0a ×1 lane, ensuring high-speed data transfer and compatibility with modern PC architectures. - **Software Support:** Includes license-free drivers and APIs for Windows and Linux, plus LabVIEW VI libraries for easy integration into measurement and control systems. - **RoHS Compliant and Lead-Free:** Environmentally friendly design meeting RoHS directives.

Hersteller: Contec

Kategorie: DIO Isolated PCIe

- **32 Opto-Isolated Digital Inputs and 32 Opto-Isolated Digital Outputs:** Provides 64 total I/O points, each isolated via opto-couplers to ensure electrical separation between the PC and external devices, minimizing noise interference and protecting the host system. - **On-board Power Supply (12VDC 240mA):** Integrated power source for driving input circuit opto-couplers, eliminating the need for an external power supply for input-side isolation circuits. - **Opto-Isolated Open Collector Outputs (Current Sinking Type):** Each output channel supports up to 35VDC and 100mA, with built-in surge and overcurrent protection (Zener diode and polyswitch). - **Interrupt Functionality:** All 32 input channels can be configured as interrupt sources. The 32 interrupt signals are combined into a single interrupt request (IRQ) line as INTA. - **Digital Filtering Function:** Built-in digital filter prevents false triggering due to noise or signal chattering, ensuring stable input signal acquisition. - **Negative Logic (Sink Current Input/Output):** The board operates on negative logic, where logical “ON” corresponds to a low voltage level, suitable for industrial control systems using sink-type logic. - **High Noise Immunity and Electrical Isolation:** Opto-coupler isolation between I/O and internal logic circuits prevents ground loops and electrical interference. - **PCI Express Interface:** Fully compliant with PCI Express Base Specification Rev. 1.0a ×1, ensuring compatibility with modern industrial PCs and embedded systems. - **Software Support:** Includes license-free driver libraries for Windows and Linux (API-TOOL / API-PAC(W32)), and VI-DAQ library for National Instruments LabVIEW integration. - **Surge and Overcurrent Protection:** Each output transistor includes a Zener diode and polyswitch for protection against voltage surges and excessive current. - **RoHS and Lead-Free Compliance:** Environmentally friendly design meeting RoHS directives and CONTEC’s Pb-free manufacturing standards.

Hersteller: Contec

Kategorie: DIO Isolated PCIe

- **64 Opto-Isolated Digital Inputs:** Provides 64 independent input channels, each isolated via opto-couplers to protect the host PC from electrical noise and voltage surges. - **Input Voltage Range:** Accepts 12–24 VDC (±10%) negative logic signals, suitable for industrial sensors and switches. - **Common Configuration:** 16 input channels share one positive common line, simplifying wiring for grouped signal inputs. - **Interrupt Functionality:** 32 input signals can be configured as interrupt sources; all are combined into a single interrupt request (IRQ) line, designated as INTA. - **Digital Filtering:** Built-in digital filter suppresses noise and chattering, ensuring stable signal acquisition in electrically noisy environments. - **High Noise Immunity:** Opto-isolation prevents ground loops and electrical interference between field devices and the PC. - **Fast Response:** Maximum response time of 200 µs, suitable for high-speed digital monitoring. - **PCI Express Interface:** Compliant with PCI Express Base Specification Rev. 1.0a ×1 lane, ensuring compatibility with modern PC architectures. - **Compact Form Factor:** Low-profile PCIe card (169.33 mm × 110.18 mm) with included standard and low-profile brackets. - **Connector Type:** 96-pin half-pitch female connector for external wiring. - **Software Support:** Includes API-TOOL drivers for Windows and Linux, and VI-DAQ library for LabVIEW integration. - **Compatibility:** Functionally and electrically compatible with the legacy PCI model PI-64L(PCI)H, allowing easy migration to PCIe systems. - **RoHS Compliant:** Environmentally friendly design meeting EU RoHS directives.

Hersteller: Contec

Kategorie: DIO Isolated PCIe

- **64 Opto-Isolated Digital Outputs:** Provides 64 open-collector output channels, each capable of sinking up to 100 mA at 35 VDC. - **Optical Isolation:** Each output channel is optically isolated from the host system to prevent electrical interference and protect the PC from voltage surges and ground loops. - **Negative Logic (Current Sinking Type):** The outputs operate in negative logic mode, with 16 channels sharing a positive common line. - **Surge and Overcurrent Protection:** Each output transistor includes a Zener diode and polyswitch for protection against voltage surges and overcurrent conditions. - **High Noise Immunity:** Opto-isolation and robust circuit design ensure reliable operation in industrial environments with high electromagnetic interference (EMI). - **Fast Response Time:** Maximum output response time of 200 µs, suitable for most automation and control applications. - **PCI Express Interface:** Fully compliant with PCI Express Base Specification Rev. 1.0a ×1, ensuring high-speed data transfer and compatibility with modern PCs. - **Compact Board Size:** 169.33 mm (L) × 110.18 mm (H), suitable for standard or low-profile PCIe slots (standard bracket included). - **Software Support:** Includes license-free drivers for Windows and Linux, as well as LabVIEW VI libraries (VI-DAQ) for easy integration into test and measurement systems. - **RoHS Compliant:** Environmentally friendly design meeting EU RoHS directives.

Hersteller: Contec

Kategorie: DIO Isolated PCIe

- **High-Density I/O:** 64 opto-isolated digital inputs and 64 opto-isolated open-collector digital outputs on a single PCIe card. - **Optical Isolation:** Each I/O channel is isolated via opto-couplers to protect the host PC from electrical noise, surges, and ground potential differences. - **Negative Logic Operation:** Supports current sinking (negative logic) configuration; 16 output channels share a positive common line. - **Interrupt Functionality:** 16 input signals can be configured as interrupt sources, combined into one interrupt request signal (INTA). - **Digital Filtering:** Built-in digital filter prevents false triggering due to noise or signal chattering. - **Surge and Overcurrent Protection:** Output transistors include integrated Zener diodes and polyswitches for surge suppression and overcurrent protection. - **High Reliability:** Industrial-grade design ensures stable operation in electrically noisy environments. - **Software Support:** Includes license-free Windows and Linux drivers (API-TOOL), and LabVIEW VI-DAQ library for easy integration with data acquisition systems. - **RoHS Compliant:** Environmentally friendly, lead-free design. - **Compatibility:** Functionally and connector-pin compatible with the PCI-compliant model PIO-64/64L(PCI)H.

Hersteller: Contec

Kategorie: DIO Isolated PCIe

- **Bus‑isolated architecture:** Digital isolators separate the PC bus from external analog and digital circuits, enhancing noise immunity and protecting the host system. - **16 analog input channels:** Single‑ended inputs with bipolar ±10 V range (absolute maximum ±20 V). - **High resolution and speed:** 16‑bit A/D conversion at 10 µs per channel (100 kS/s aggregate). - **Integrated buffer memory:** 1 k‑word FIFO or ring buffer for continuous background sampling independent of software latency. - **Flexible trigger and clock control:** Sampling start/stop can be controlled by software, external TTL triggers, or comparison events; sampling clock selectable from internal or external sources. - **Digital I/O and counter:** 4 isolated TTL inputs and 4 isolated TTL outputs plus one 32‑bit counter (up to 1 MHz) with gate and up‑clock inputs and count‑match output. - **Software calibration:** All gain/offset adjustments performed via software; user can store custom calibration data in addition to factory settings. - **Digital filtering:** 1 µs software‑selectable filter to suppress chattering and noise on external trigger, clock, and digital input signals. - **Driver and software support:** Windows and Linux drivers (API‑AIO WDM/LNX), C‑LOGGER data‑logger software, and libraries for MATLAB (ML‑DAQ) and LabVIEW (VI‑DAQ). - **Compatibility:** Connector and function compatible with legacy PCI board ADI16‑16(LPCI)L for easy system migration. - **Compact PCIe form factor:** 169.33 mm × 110.18 mm board size with standard slot bracket.

Hersteller: Contec

Kategorie: A/D Isolated PCIe

- **Bus‑Isolated Architecture:** Digital isolators separate the PC bus from external analog and digital circuits, enhancing noise immunity and protecting the host system. - **High‑Resolution Analog I/O:** 16‑bit resolution for both A/D and D/A conversion with ±10 V bipolar range and 100 k samples per second (10 µs per channel). - **Multifunction Integration:** 8 analog inputs, 2 analog outputs, 4 digital inputs, 4 digital outputs, and 1 32‑bit counter on a single board. - **Trigger and Clock Flexibility:** Sampling start/stop controlled by software commands or external TTL triggers; supports internal or external sampling clocks. - **Buffered Data Acquisition:** 1 k‑word FIFO/RING buffer for both input and output enables continuous background operation independent of PC load. - **Digital Filtering:** Programmable 1 µs filter to suppress chattering and false triggering on external signals. - **Software Calibration:** All gain/offset adjustments performed in software; user can store custom calibration data in addition to factory settings. - **Safety Startup:** Analog outputs are forced to 0 V at power‑on to prevent damage to connected equipment. - **Software Support:** Bundled API‑PAC(W32) driver library for Windows and Linux, C‑LOGGER data logger, and free downloadable MATLAB (ML‑DAQ) and LabVIEW (VI‑DAQ) libraries. - **Compatibility:** Connector and function compatible with legacy PCI board ADAI16‑8/2(LPCI)L for easy system migration.

Hersteller: Contec

Kategorie: A/D Isolated PCIe

- **Bus‑Isolated Analog Output:** Four 16‑bit D/A channels with ±10 V bipolar range, isolated from the host PC by a digital isolator to enhance noise immunity and protect against ground loops. - **High‑Speed Conversion:** 10 µs conversion time per channel (100 kS/s aggregate rate) enabling precise waveform generation and real‑time control. - **Integrated Digital I/O:** Four isolated TTL‑level digital inputs and four isolated TTL‑level digital outputs (positive logic) for auxiliary control and status signaling. - **32‑bit Counter Function:** One isolated up‑count channel (1 MHz max) with gate and up‑clock inputs and a count‑match pulse output for event counting or frequency measurement. - **1 k‑Word Buffer Memory:** On‑board FIFO/RING buffer supports continuous or cyclic analog output independent of host CPU timing. - **Flexible Trigger and Clock Control:** Start/stop of sampling selectable via software command, external trigger, or specified sample count; internal or external sampling clock supported. - **Digital Filtering:** Optional 1 µs digital filter suppresses chattering and noise on external trigger, sampling clock, digital input, and counter signals. - **Safety Power‑On Design:** All analog outputs automatically reset to 0 V when power is applied, preventing transient voltages that could damage connected equipment. - **Software‑Based Calibration:** Full calibration performed via software; user can store additional adjustment data to compensate for environmental variations. - **Comprehensive Software Support:** Includes Windows and Linux drivers (API‑PAC W32), C‑LOGGER data‑logging software, and libraries for MATLAB (ML‑DAQ) and LabVIEW (VI‑DAQ). - **Compatibility:** Connector pinout and functions are compatible with the legacy PCI board DAI16‑4(LPCI)L, simplifying migration to PCI Express systems.

Hersteller: Contec

Kategorie: D/A Isolated PCIe

- **High‑precision analog input:** 16 single‑ended channels, 16‑bit resolution, bipolar ±10 V input range, 100 kS/s (10 µs/channel) conversion rate. - **Digital I/O:** 4 TTL‑level inputs + 4 TTL‑level outputs (positive logic). - **Counter:** 1 channel, 32‑bit up‑counter, max frequency 10 MHz (1 MHz for isolated variant). - **Buffer memory:** 1 k‑word onboard FIFO/RING buffer enabling background sampling independent of host CPU load. - **Trigger and clock control:** Sampling start/stop selectable by software command, external trigger, or comparison of conversion data; internal or external sampling clock. - **Digital filter:** 1 µs software‑selectable filter suppresses chattering on external trigger, sampling clock, digital input, and counter signals. - **Software calibration:** All analog calibration performed in software; user can store additional adjustment data to compensate for environmental drift. - **Bus isolation (variant AI‑1616LI‑PE):** Digital isolator separates PC bus from external I/O circuits, improving noise immunity. - **Compatibility:** Connector and function compatible with legacy PCI ADI16‑16(LPCI)L boards, simplifying migration. - **Comprehensive software support:** Windows and Linux drivers, C‑LOGGER data‑logger, MATLAB ML‑DAQ library, and LabVIEW VI‑DAQ plug‑ins. - **Low‑profile PCI Express x1 interface:** Compliant with PCI Express Base Specification Rev 1.0a; fits compact industrial PCs. - **Operating environment:** 0 – 50 °C, 10 – 90 % RH (non‑condensing).

Hersteller: Contec

Kategorie: A/D General Purpose PCIe

- **Multi‑function Analog I/O:** Combines 8 analog input channels (16‑bit, ±10 V), 2 analog output channels (16‑bit, ±10 V), 4 digital inputs, 4 digital outputs, and one 32‑bit counter. - **High‑Resolution Conversion:** 16‑bit A/D and D/A converters deliver precise signal acquisition and generation up to 100 kS/s per channel. - **Buffer Memory:** 1 k‑word FIFO or ring buffer for both analog input and output, enabling background operation independent of host CPU load. - **Trigger and Clock Flexibility:** Supports software, external trigger, and external clock synchronization for both input and output. - **Software Calibration:** All analog channels can be calibrated via software; user calibration data can be stored in addition to factory settings. - **Digital Filtering:** 1 µs selectable digital filter on digital inputs, counter inputs, and external control signals to suppress chattering and noise. - **Low Profile Design:** Compliant with PCI Express Base Specification Rev. 1.0a (x1 lane). Supplied with both low‑profile and full‑height brackets. - **Comprehensive Software Support:** Includes Windows API‑PAC(W32) driver library, Linux API‑AIO(LNX) drivers, C‑LOGGER data logger, and free downloadable MATLAB (ML‑DAQ) and LabVIEW (VI‑DAQ) libraries. - **Data Logging and Visualization:** C‑LOGGER software enables real‑time graphing, file storage, and Excel data export without programming. - **RoHS and VCCI Compliant:** Meets environmental and electromagnetic compatibility standards.

Hersteller: Contec

Kategorie: A/D General Purpose PCIe

- **High‑precision 16‑bit Analog Output:** Sixteen independent unisolated channels with bipolar ±10 V range and ≤ 1 Ω output impedance provide fine‑resolution voltage generation for control and simulation tasks. - **High Speed Conversion:** 10 µs conversion time per channel (100 kS/s aggregate rate) enables smooth waveform generation and dynamic signal output. - **Integrated Digital I/O:** Four LVTTL‑level inputs and four LVTTL‑level outputs (positive logic) allow synchronous digital control and status monitoring. - **32‑bit Counter/Timer:** One LVTTL‑level up‑count channel with gate and up inputs and a count‑match pulse output supports event counting up to 10 MHz. - **Flexible Trigger and Clock Control:** Sampling start/stop can be initiated by software commands or external LVTTL triggers; sampling clock can be internal or external with edge selection (rising/falling). - **1 k‑word On‑board Buffer:** Configurable as FIFO or RING memory for continuous or cyclic output independent of host CPU load. - **Digital Filter on External Signals:** 1 µs software‑selectable filter suppresses chattering and false trigger detection on external and digital inputs. - **Safe Power‑on Design:** All analog outputs are forced to 0 V at power‑up to protect connected equipment from transients. - **Software Calibration:** Full software‑based gain/offset adjustment with storage of user calibration data in non‑volatile memory. - **Driver and Library Support:** Bundled Windows and Linux drivers (API‑PAC W32/LNX) with sample programs; MATLAB ML‑DAQ and LabVIEW VI‑DAQ libraries available free from CONTEC. - **Compatibility:** Connector and function compatible with legacy PCI board DA16‑16(LPCI)L for easy system migration. - **Dual Bracket Support:** Supplied with both low‑profile and standard PCI brackets for installation flexibility. - **Regulatory Compliance:** RoHS and VCCI certified.

Hersteller: Contec

Kategorie: D/A General Purpose PCIe

- **High‑Precision Analog Output:** Four non‑isolated 16‑bit analog output channels with bipolar ±10 V range and maximum output current of ±3 mA. - **High‑Speed Conversion:** 100 kS/s (10 µs per conversion) per channel, suitable for waveform generation and control applications. - **Integrated Digital I/O:** Four TTL‑level digital inputs and four TTL‑level digital outputs (positive logic, non‑isolated). - **Built‑in Counter Function:** One 32‑bit up‑counter channel with maximum response frequency of 10 MHz, supporting gate and up‑clock inputs and a count‑match output. - **Buffer Memory:** 1 k‑word buffer memory for analog output, supporting FIFO or ring operation modes for continuous or cyclic waveform generation. - **Software‑Based Calibration:** Full software calibration for analog outputs, allowing adjustment and storage of calibration data according to the operating environment. - **Trigger and Clock Synchronization:** Supports software, external trigger, and external clock synchronization for precise timing control. - **Digital Filtering:** 1 µs digital filter (software‑selectable) on digital inputs, counter inputs, and external control signals to suppress noise and chattering. - **Cross‑Platform Driver Support:** Includes Windows and Linux driver libraries (API‑PAC(W32), API‑AIO(WDM), API‑AIO(LNX)) with sample programs. - **MATLAB and LabVIEW Integration:** Dedicated plug‑in libraries (ML‑DAQ and VI‑DAQ) available free of charge for seamless integration with MATLAB and National Instruments LabVIEW. - **Compact Low Profile Design:** 121.69 mm (L) × 67.90 mm (H), 60 g weight, suitable for space‑constrained systems. - **RoHS and VCCI Compliant:** Environmentally friendly and compliant with Japanese VCCI electromagnetic standards.

Hersteller: Contec

Kategorie: D/A General Purpose PCIe

- **Eight 16‑bit Analog Outputs:** Unisolated bipolar ±10 V range with ≤ 1 Ω output impedance and ±3 mA maximum drive current per channel. - **High Speed Conversion:** 10 µs conversion time (100 kS/s aggregate) for precise waveform generation and control applications. - **Integrated 1 k‑word Buffer Memory:** Configurable as FIFO or RING for continuous or repetitive output without CPU intervention. - **Flexible Trigger and Clock Control:** Start/stop sampling via software command or external LVTTL trigger; internal or external clock selectable. - **Digital I/O and Counter:** 4 × LVTTL inputs and 4 × LVTTL outputs (positive logic) plus one 32‑bit up‑counter with 10 MHz max response frequency. - **Digital Filter Function:** 1 µs software‑selectable filter to suppress chattering and noise on external trigger, clock, and I/O signals. - **Safe Power‑On Design:** All analog outputs forced to 0 V at power‑up to protect connected equipment. - **Software Calibration:** Full software‑based gain/offset adjustment with user‑storable calibration data. - **Driver and Library Support:** API‑PAC(W32) for Windows and Linux (API‑AIO WDM/LNX), plus free ML‑DAQ (MATLAB) and VI‑DAQ (LabVIEW) libraries. - **Compatibility:** Connector and function compatible with legacy PCI board DA16‑8(LPCI)L for easy system migration. - **Dual Bracket Support:** Includes both low‑profile and standard PCI brackets for installation flexibility. - **RoHS and VCCI Compliant.**

Hersteller: Contec

Kategorie: D/A General Purpose PCIe

- **IEEE-488.1 / IEEE-488.2 Compliance:** Fully conforms to both IEEE-488.1 and IEEE-488.2 standards, ensuring compatibility with a wide range of GPIB instruments. - **High-Speed Data Transfer:** Achieves up to **1.5 MByte/sec** maximum transfer rate, supporting high-throughput data acquisition and control. - **Bus Master Operation:** Enables direct memory access (DMA) transfers between the board and system memory without CPU overhead, improving system efficiency. - **Dual 2Kbyte FIFO Buffers:** Independent 2Kbyte send and receive buffers allow smooth, high-speed data flow and minimize latency during communication. - **SPAS Event Function:** Supports the SPAS (Serial Poll Active State) event, enhancing flexibility in serial polling and system control. - **High-Precision Internal Timer:** Integrated timer allows accurate time monitoring and synchronization under Windows environments. - **Long-Term Availability:** Utilizes CONTEC’s proprietary high-speed GPIB controller (µPD7210 register compatible), ensuring product longevity and stable supply. - **Diagnostic Utility:** Includes a diagnostic program for verifying hardware operation, interrupts, I/O addresses, and performing communication tests. - **Low Profile and Standard Slot Support:** Ships with a low-profile bracket pre-installed and includes a standard bracket for full-height PCIe slots. - **Software Development Support:** Compatible with CONTEC’s API-PAC(W32) driver library, supporting Win32 API-based programming languages and LabVIEW integration.

Hersteller: Contec

Kategorie: IEEE (GPIB) Cards

- **IEEE-488.1 / IEEE-488.2 Compliance:** Fully compliant with both IEEE-488.1 and IEEE-488.2 standards, ensuring compatibility with a wide range of GPIB instruments and controllers. - **High-Speed Data Transfer:** Supports a maximum transfer rate of **1.5 Mbyte/sec**, enabling rapid communication with multiple instruments. - **Bus Master Transfer:** Allows direct data transfer between the PC and the board without CPU load, improving system efficiency and throughput. - **Integrated GPIB Bus Analyzer:** Provides real-time monitoring and analysis of GPIB bus signals, enabling debugging and performance optimization. - **2Kbyte FIFO Memory:** Onboard FIFO buffers for both transmission and reception ensure stable, high-speed data flow and reduced latency. - **High-Precision Timer:** Built-in timer for precise time measurement and synchronization in Windows environments. - **Low Profile PCI Express Form Factor:** Compliant with PCI Express Base Specification Rev. 1.0a ×1; includes both low-profile and standard brackets for flexible installation. - **Multi-Board Support:** Up to four boards can be installed in a single system, allowing expansion of GPIB channels. - **Interrupt Handling:** One interrupt request signal (INTA#) for efficient event-driven communication. - **Long-Term Availability:** Uses CONTEC’s proprietary high-speed GPIB controller (compatible with PD7210 and later), ensuring stable long-term supply and support. - **Diagnostic and Utility Software:** Includes diagnostic tools for hardware verification, interrupt testing, and communication validation. - **Line Monitoring:** Capable of reading control line states (IFC, ATN, SRQ, REN, EOI, DAV, NRFD, NDAC) and data line status (DIO1–DIO8). - **Cross-Platform Software Support:** Compatible with Windows and Linux API-TOOL drivers, MATLAB, and LabVIEW environments. - **RoHS and Lead-Free Compliance:** Environmentally friendly design meeting modern regulatory standards.

Hersteller: Contec

Kategorie: IEEE (GPIB) Cards

- **PCI Express Bus Compliance:** Fully compliant with PCI Express Base Specification Rev. 1.0a (x1 lane). Compatible with standard and low-profile PCIe slots. - **High-Speed TTL-Level I/O:** Provides 16 unisolated TTL-level inputs and 16 open-collector TTL-level outputs. Input response time: within 200 nanoseconds. Output response time: within 200 nanoseconds (variable with pull-up resistance). - **Interrupt Functionality:** All 16 input channels can be configured as interrupt inputs. Supports rising-edge or falling-edge interrupt triggering. Interrupts can be enabled or disabled per bit. - **Digital Filtering:** Built-in digital filter prevents false triggering due to noise or contact chattering. Filter time adjustable from 0 to 131.072 milliseconds (21-step range). - **Compact Low-Profile Design:** Dimensions: 121.69 mm (L) × 67.90 mm (H). Supplied with both low-profile and standard PCI brackets for flexible installation. - **Software Compatibility:** Bundled with CONTEC’s API-PAC(W32) driver library for Windows and API-DIO(LNX) for Linux. Supports LabVIEW via VI-DAQ library. Includes diagnostic and sample programs for rapid development. - **Electrical Performance:** Output rating: 30 VDC, 40 mA per channel (open collector). Input resistance: 10 kΩ (1 TTL load). Power consumption: 3.3 VDC, 300 mA (max). - **Connector Interface:** 50-pin Mini-Ribbon connector (3M 10250-52A2JL or equivalent). Compatible with CONTEC’s optional cables and terminal blocks. - **Compatibility:** Functionally equivalent to CONTEC’s PIO-16/16T(LPCI)H PCI board. Connector pin assignments are identical, ensuring easy migration.

Hersteller: Contec

Kategorie: DIO Non-Isolated PCIe

- **48‑Channel Bi‑Directional Digital I/O:** Provides 48 LVTTL‑level I/O channels, configurable in 8‑bit units for input or output. Each channel can be individually controlled by software. - **High‑Speed Response:** Non‑isolated LVTTL (positive logic) I/O with a maximum response time of **200 ns**, suitable for high‑frequency digital control and monitoring. - **Interrupt Capability:** All 48 input signals can be used as interrupt sources. Interrupts can be enabled/disabled per bit, and the trigger edge (rising/falling) is software‑selectable. - **Digital Filtering:** Built‑in programmable digital filter suppresses noise and contact chattering. Filter time selectable from **0.25 µs to 131 ms** in 21 steps. - **i8255 Mode 0 Compatibility:** Emulates the Intel 8255 PPI Mode 0 interface, ensuring compatibility with legacy digital I/O systems and software. - **Low‑Profile PCIe Form Factor:** Compliant with PCI Express Low Profile mechanical specification. Includes both low‑profile and standard brackets for flexible installation. - **Software‑Configurable I/O Direction:** Each 8‑bit port can be dynamically configured for input or output via software control words. - **Comprehensive Software Support:** Bundled with CONTEC’s **API‑PAC(W32)** driver library for Windows and **API‑DIO(LNX)** for Linux. Includes sample programs, diagnostics, and LabVIEW VI‑DAQ support. - **Full Interrupt and Filter Control via API:** Interrupt masks, edge selection, and filter parameters are programmable through the driver API. - **Compact and Lightweight:** Board dimensions **121.69 mm (L) × 67.90 mm (H)**; weight approximately **60 g**. - **Compatible with Existing CONTEC Boards:** Functionally equivalent to PCI and CardBus models **PIO‑48D(PCI)**, **PIO‑48D(LPCI)H**, and **PIO‑48D(CB)H**, ensuring easy migration to PCI Express systems.

Hersteller: Contec

Kategorie: DIO Non-Isolated PCIe

- **32 LVTTL I/O Channels:** Provides 32 unisolated LVTTL‑level channels (3.3 V DC, positive logic) configurable via software as 32 inputs, 32 outputs, or 16 inputs + 16 outputs. Response time: 20 ns. - **High‑Speed Sampling and Generation (50 MHz max):** Independent bus‑mastering DMA channels for input and output allow simultaneous sampling and generation at up to 50 MHz. Each direction has a dedicated 4 K‑sample FIFO buffer and supports scatter/gather DMA up to 2 GB per channel. - **Synchronization of Multiple Boards:** A synchronization control (SC) connector enables synchronized operation of up to 16 boards, allowing multi‑channel expansion and coordinated timing with other CONTEC boards. - **Interrupt Functionality:** Up to 4 input lines can be configured as interrupt request sources (rising‑edge triggered). Interrupts can be enabled or disabled per bit. - **Flexible Pull‑Up Voltage Selection:** Input and control signal pull‑ups can be configured for None, 3.3 V, or 5 V, facilitating connection to both LVTTL and 5 V TTL logic devices. - **Bus Master Transfer:** Supports 64/32‑bit DMA bus mastering with a maximum transfer rate of 360 MB/s, enabling efficient high‑volume data movement without CPU overhead. - **Software Support:** Includes Windows driver library **API‑PAC(W32)** with **API‑DIO(WDM)** driver, sample programs (Visual Basic, C++), and diagnostic utilities. Supports **LabVIEW** through downloadable **DAQfast** and **VI‑DAQ** libraries for seamless integration. - **Compatibility:** Connector pinout and functions are compatible with CONTEC’s PCI PIO‑32DM(PCI), DIO‑32DM‑PE, and DIO‑32DM2‑PE boards, simplifying system upgrades. - **External Control and Handshake Signals:** Dedicated external clock, start, stop, REQ, and ACK signals for both input and output channels allow precise synchronization with external devices. - **Compact PCI Express Form Factor:** Compliant with PCI Express Base Specification Rev. 2.0 ×1; compact board size 169.33 × 110.18 mm, weight 150 g.

Hersteller: Contec

Kategorie: DIO Non-Isolated PCIe

- **PCI Express Bus Compliance:** Fully compliant with PCI Express Base Specification Rev. 1.0a (x1 lane). Compatible with standard PCIe slots in industrial and commercial PCs. - **16 Input / 16 Output Channels:** Provides 16 TTL-level digital input channels and 16 open-collector digital output channels, all operating under negative logic. - **High-Speed Response:** Input and output response time of **200 nanoseconds (max)** ensures rapid signal processing suitable for high-speed control and monitoring applications. - **Interrupt Functionality:** All 16 input channels can be configured as interrupt inputs. The board supports edge-triggered interrupts (rising or falling edge selectable). Four event signals can be combined into one interrupt request (IntA). - **Digital Filtering:** Built-in digital filter function prevents false triggering due to noise or contact chattering. Filter time is programmable from 0 to 131.072 ms. - **Compact PCIe Form Factor:** Board dimensions of **121.69 mm (L) × 67.90 mm (H)** allow installation in compact or low-profile systems. - **Connector Interface:** Equipped with a **37-pin D-type female connector** for external I/O connection. - **Robust Electrical Design:** Input resistance of 10 kΩ ensures stable signal detection. Output channels support up to **30 VDC / 40 mA** per channel. - **Software Support:** Includes CONTEC’s **API-PAC(W32)** driver library for Windows and **API-DIO(LNX)** for Linux. Compatible with **LabVIEW VI-DAQ** for graphical programming environments. - **Industrial Reliability:** Designed for continuous operation in industrial environments (0–50°C, 10–90% RH, non-condensing).

Hersteller: Contec

Kategorie: DIO Non-Isolated PCIe

- **PCI Express Bus Interface:** Compliant with PCI Express Base Specification Rev. 1.0a, x1 lane configuration, ensuring high-speed data transfer and compatibility with modern PC architectures. - **64 Total I/O Channels:** Provides 32 digital input and 32 digital output channels, all operating at TTL logic levels. - **Negative Logic Operation:** Inputs and outputs are configured for negative logic, simplifying integration with standard TTL devices. - **High-Speed Response:** Input and output response times are within 200 nanoseconds, enabling precise timing control in automation and measurement systems. - **Interrupt Functionality:** Supports up to four event triggers combined into one interrupt request (IntA) on rising or falling edge transitions, allowing efficient event-driven control. - **Compact Design:** Board dimensions of 122 × 107 × 19 mm allow installation in standard PCIe slots without occupying excessive space. - **Standard Connector Interface:** Equipped with a 37-pin D-sub female connector for easy connection to external devices and terminal blocks. - **Robust Electrical Characteristics:** Input resistance of 10 kΩ, output capability up to 30 VDC and 40 mA per channel. - **Cross-Platform Software Support:** Includes free Windows and Linux drivers, as well as LabVIEW VI-DAQ library for seamless integration with National Instruments environments. - **Industrial Reliability:** Designed for continuous operation in industrial environments, with stable performance and long-term support from CONTEC.

Hersteller: Contec

Kategorie: DIO Non-Isolated PCIe

- **High-Density I/O:** Provides 64 digital input and 64 digital output channels on a single PCIe card, enabling large-scale digital control and monitoring within compact systems. - **TTL-Level Interface:** Operates at standard 5V TTL logic levels (negative logic), suitable for direct connection to logic circuits, sensors, and actuators. - **High-Speed Response:** Input response time of approximately 200 nanoseconds and output switching within 1 microsecond, supporting high-frequency digital operations. - **Interrupt Functionality:** Supports up to four event inputs combined into one interrupt request (INTA#). Interrupts can be triggered on rising or falling edges, allowing event-driven control. - **Flexible Signal Handling:** Each input channel has a 10 kΩ pull-up resistor; outputs are open-collector type capable of sinking up to 40 mA at 30 VDC maximum. - **Compact PCIe Form Factor:** Short-size PCI Express x1 board (121.69 × 107 × 19 mm) compatible with standard and low-profile PCIe slots. - **Standard Connector Interface:** Equipped with a 37-pin D-sub female connector for external wiring. - **Software Support:** Fully supported by CONTEC’s API-TOOL driver suite for Windows and Linux, and compatible with LabVIEW via VI-DAQ library. - **Industrial Reliability:** Designed for continuous operation in industrial environments with robust electrical characteristics and stable performance.

Hersteller: Contec

Kategorie: DIO Non-Isolated PCIe

- **IEEE‑488.1 / IEEE‑488.2 Compliance:** Fully conforms to the international GPIB communication standards, ensuring compatibility with a wide range of laboratory and industrial instruments. - **Compact PCMCIA Type II Form Factor:** Designed for notebook PCs and embedded systems with PC Card slots, providing portable GPIB connectivity without external power. - **Data Transfer Rate:** Supports up to **50 Kbyte/sec** maximum transmission speed, suitable for standard instrument control and data acquisition tasks. - **Interrupt Flexibility:** Selectable IRQ levels (3–7, 9–12, 14, or 15) for optimal system integration and conflict avoidance. - **Electrical Interface:** 8 parallel data lines and 3 handshake lines, negative logic signaling (Low ≤ 0.8 V, High ≥ 2.0 V). - **Device Connectivity:** Supports up to **15 GPIB devices** on a single bus segment. - **Cable Length:** Up to **4 m between devices** and **20 m total bus length**, compliant with IEEE‑488 specifications. - **Plug‑and‑Play Operation:** Automatically recognized by PCMCIA‑compliant operating systems; no manual configuration required. - **Software Support:** Compatible with CONTEC’s **ACX‑PAC(W32)** and **API‑PAC(W32)** driver libraries, enabling integration with Windows‑based control software and development environments such as LabVIEW and MATLAB. - **High Reliability:** Uses CONTEC’s proprietary GPIB controller technology for long‑term supply stability and robust operation. - **Lightweight and Portable:** Approximately **250 g including cable**, ideal for field measurement and mobile test setups.

Hersteller: Contec

Kategorie: IEEE (GPIB) Cards

- **24 TTL-Level I/O Channels:** Provides 24 independent digital input/output lines, configurable for general-purpose control and monitoring applications. - **PCMCIA Type II Interface:** Compact form factor suitable for laptops and embedded systems with PCMCIA slots. - **Positive Logic Operation:** All I/O channels operate with positive logic, simplifying integration with standard TTL devices. - **Output Characteristics:** Each output channel supports +5 VDC logic level with a maximum output current of 1 mA per line. - **8255-Compatible Architecture:** Fully compatible with the Intel 8255 Programmable Peripheral Interface standard, ensuring straightforward software control and register-level programming. - **Included Cable:** Supplied with a 0.3-meter connection cable for immediate deployment and easy integration with external devices. - **Plug-and-Play Operation:** Designed for quick installation and automatic recognition by compatible operating systems and drivers. - **Compact and Portable:** Ideal for mobile data acquisition, control, and testing applications where space and portability are critical. - **High Reliability:** Manufactured by Contec, a recognized leader in industrial I/O and measurement solutions, ensuring long-term stability and support.

Hersteller: Contec

Kategorie: CardBus

- **Multifunction Analog I/O:** Combines analog input, analog output, and digital I/O functions in one PCMCIA Type II card. - **High-Speed A/D Conversion:** 12-bit resolution with a maximum conversion speed of 10 µs per channel. - **Analog Output Capability:** Two 12-bit D/A channels with 0 to +4.095 V output range and 16 µs conversion speed. - **Digital I/O Interface:** Four TTL-level digital inputs and four TTL-level digital outputs for control and monitoring. - **FIFO Buffer Memory:** 16,384-word (16K-word) onboard FIFO memory enables continuous high-speed sampling independent of host CPU load. - **Flexible Clocking:** Supports both internal and external sampling clocks, selectable in 100 ns intervals from 10 µs to 104.8576 s. - **Trigger Control:** One TTL-level external trigger input for synchronized sampling and one TTL-level control output for external device coordination. - **Compact PCMCIA Type II Form Factor:** Ideal for laptops and portable measurement systems. - **Software Support:** Compatible with Windows and LabVIEW environments; includes API-TOOLs for Windows and Linux for custom application development. - **Industrial Reliability:** Designed for stable operation in industrial and laboratory environments; conforms to PCMCIA Rel. 2.0 / JEIDA 4.1 standards.

Hersteller: Contec

Kategorie: CardBus

- **Optical Isolation:** Each communication channel is electrically isolated from the PC and other channels, preventing ground loops, signal interference, and damage from electrical noise or surges. - **Surge Protection:** Built-in surge protection circuitry safeguards the communication line from transient voltage spikes, ensuring stable operation in industrial environments. - **RS-422A/RS-485 Compatibility:** Supports both RS-422A (full-duplex) and RS-485 (half-duplex) communication modes, allowing flexible integration with a wide range of industrial devices. - **PCMCIA Type II Interface:** Fully compliant with PCMCIA Release 2.0 and JEIDA 4.1 standards, enabling plug-and-play installation in compatible notebook PCs and embedded systems. - **High Communication Distance:** Supports communication distances up to 1,200 meters (1.2 km), ideal for long-distance industrial control and monitoring applications. - **Standard COM Port Emulation:** Appears as a standard COM port under Windows or Linux, allowing use with existing serial communication software without modification. - **Cross-Platform Driver Support:** Includes standard COM drivers for Windows (XP/2000/Me/98) and Linux, along with the CONTEC COM Setup Disk for easy configuration. - **UART 16550 Compatible Controller:** Provides a 16-byte FIFO buffer for both transmission and reception, ensuring stable data flow and reduced CPU load. - **Compact and Portable:** Designed for mobile computing environments, the PCMCIA form factor allows easy insertion and removal without system shutdown. - **Industrial Reliability:** Engineered for measurement, control, and automation systems requiring robust serial communication in harsh electrical environments.

Hersteller: Contec

Kategorie: CardBus
