- **PCI Express® x1 Compliant:** Fully compatible with PCI Express Base Specification Revision 1.1. - **Dual IEEE 1394b Ports:** Two independent FireWire 800 (9-pin) ports supporting up to 800 Mb/s each. - **High-Speed Image Transfer:** Optimized for real-time image acquisition and transmission in machine vision systems. - **Industrial Screw-Lock Connectors:** Ensures secure and vibration-resistant cable connections. - **Channel Status LEDs:** Two front-panel green LEDs indicate active camera connections for each port. - **Integrated Power Supply:** 4-pin ATX connector provides +12 V power to connected IEEE 1394b cameras. - **Short-Circuit Protection:** Built-in overcurrent protection for each port (1 A @ +12 V). - **Compact Half-Length Form Factor:** Suitable for space-constrained industrial PCs. - **Plug-and-Play Operation:** IEEE 1394b standard supports automatic device recognition and configuration. - **Software Compatibility:** Supports Windows® XP, XP Embedded, and Vista (32-bit). - **User EEPROM:** 2 Kbit onboard EEPROM for configuration and identification data storage.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **PCI Express x4 Compliant:** Fully compliant with PCI Express Base Specification Revision 1.1. - **High-Speed Data Transfer:** Supports IEEE 1394b (FireWire 800) with data rates of 100, 200, 400, and 800 Mb/s per port, totaling up to 3.2 Gbps across four channels. - **Four Independent IEEE 1394b Ports:** Each port supports screw-lock connectors for secure industrial connections. - **Isolated Digital I/O:** Four optically isolated digital inputs and four isolated digital outputs for external device interfacing. - **Programmable Trigger Outputs:** Four isolated TTL-level trigger outputs with adjustable delay (0–1000 ms) and pulse width (0.1–50 ms). - **FireWire Short-Circuit Protection:** Built-in protection circuitry ensures safe operation under fault conditions. - **4-Pin ATX Power Connector:** Provides external 12 V power for connected IEEE 1394b cameras. - **Status LEDs:** Four channel-specific LEDs indicate active IEEE 1394b connections. - **Industrial-Grade Isolation:** 1000 V isolation voltage for digital and trigger I/O channels. - **Software Support:** Compatible with Windows XP, XP Embedded, and Vista (32-bit). - **Compact Form Factor:** 129.5 mm (W) × 111.15 mm (L) PCIe card suitable for standard PC enclosures.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **PCI Express x4 Compliant Interface:** Fully compliant with PCI Express Base Specification Revision 1.1, ensuring high bandwidth and compatibility with modern PC architectures. - **High-Speed Data Transfer:** Supports IEEE 1394b (FireWire 800) data rates up to **800 Mb/s per port**, with an aggregate throughput of **up to 3.2 Gb/s** across four channels. - **Four Independent IEEE 1394b Ports:** Each port supports 100, 200, 400, and 800 Mb/s transfer rates and is fully compliant with IEEE P1394b-2002, IEEE 1394a-2000, and IEEE 1394-1995 standards. - **Isolated Digital I/O and Trigger Channels:** Provides **four isolated digital inputs and four isolated digital outputs**, as well as **four isolated trigger inputs and four isolated trigger outputs**, all photo-coupled for electrical isolation and noise immunity. - **Programmable Trigger Outputs:** Each trigger output supports programmable delay (0–1000 ms, 1 ms steps) and pulse width (0.1–50 ms, 0.1 ms steps), with selectable polarity and enable control. - **Industrial-Grade Connectors:** Equipped with screw-lock IEEE 1394b connectors for secure industrial connections. - **Status LEDs:** Four front-panel LEDs indicate active channel connections for easy monitoring. - **Power Supply for Cameras:** Includes a **4-pin ATX 12 V connector** to supply power directly to connected IEEE 1394b cameras. - **Software and OS Support:** Compatible with **Windows XP, XP Embedded, and Windows Vista (32-bit)** platforms. Includes driver and function library for digital I/O and trigger control. - **Applications:** Ideal for **machine vision inspection**, **automatic optical inspection (AOI)**, **scientific imaging**, and **medical research instrumentation**.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Dual Independent Gigabit Ethernet Ports:** Two fully integrated Gigabit Ethernet MAC and PHY interfaces supporting IEEE 802.3, 802.3u, and 802.3ab standards for 10/100/1000 Mbps operation. - **PCI Express x4 Interface:** Compliant with PCI Express x4 specification, ensuring high bandwidth and low latency data transfer between the host system and connected cameras. - **High Data Throughput:** Supports data transfer rates up to 1 GB/s per channel, suitable for high-resolution, high-frame-rate imaging. - **Jumbo Frame Support:** Capable of handling jumbo frames up to 9 KB, improving efficiency in large image data transfers. - **Isolated Digital I/O:** Includes 2 isolated digital inputs and 2 isolated digital outputs for external device control and synchronization. - **Programmable Triggering:** Two isolated trigger inputs and two isolated trigger outputs with programmable delay, pulse width, and polarity for precise timing control. - **Industrial-Grade Design:** Equipped with screw-lock RJ-45 connectors for secure cable attachment in industrial environments. - **Onboard Memory Buffer:** Integrated 128 MB DDR RAM buffer for stable and reliable data streaming. - **Software Support:** Compatible with Windows XP, XP Embedded, and Vista operating systems. Includes driver and function library for easy integration. - **Compact Form Factor:** Dimensions of 129.5 mm (W) × 111.15 mm (L) suitable for standard PC chassis.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Dual Gigabit Ethernet Ports:** Two fully integrated Gigabit Ethernet MAC/PHY ports supporting 10/100/1000 Mbps operation. - **Power over Ethernet (PoE):** IEEE 802.3af compliant, delivering up to 15.4 W per channel at 48 VDC, eliminating the need for external power supplies for cameras. - **PCI Express x4 Interface:** High-speed PCIe x4 bus interface ensures up to 1 GB/s per channel data throughput. - **Link Aggregation Support:** Enables dual-port bonding for increased bandwidth and redundancy. - **Jumbo Frame Support:** Handles jumbo frames up to 9.5 KB for efficient large image transfers. - **Onboard Memory Buffer:** 128 MB DDR RAM buffer for stable, high-speed image acquisition. - **Isolated Digital I/O:** Two isolated digital inputs and outputs for external device control and synchronization. - **Programmable Trigger Outputs:** Two isolated trigger outputs with adjustable delay, width, and polarity for precise timing control. - **Industrial-Grade Connectors:** Two RJ-45 ports with screw-lock connectors for secure camera connections. - **Compact Form Factor:** 129.5 mm (W) × 111.15 mm (L) PCB size suitable for standard PC enclosures. - **Environmental Robustness:** Operating temperature range of 0°C to 55°C and humidity tolerance up to 90% RH non-condensing. - **Software Development Kit (SDK):** Comprehensive API library supporting C++, C#, and Visual Basic for custom application development.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Four Independent Gigabit Ethernet Ports:** Supports simultaneous connection of up to four GigE Vision cameras for high-speed image acquisition. - **Power over Ethernet (PoE):** IEEE 802.3af compliant, delivering up to 15.4 W per channel at 48 VDC, eliminating the need for separate power supplies for cameras. - **High Data Throughput:** Each channel supports up to 1 Gb/s transfer rate, with total bandwidth exceeding 4 Gb/s when aggregated. - **PCI Express x4 Interface:** Ensures high-speed data transfer between the frame grabber and host system, compliant with PCIe v1.1 (2.5 GT/s). - **IEEE 1588 Synchronization:** Enables precise multi-camera synchronization for time-critical imaging applications. - **Link Aggregation Support:** Allows combining multiple ports for increased bandwidth and redundancy. - **Jumbo Frame Support:** Handles jumbo frames up to 9.5 kB for efficient large-packet data transmission. - **Integrated PoE Protection:** Includes inrush current control, current limiting, and short-circuit protection for reliable operation. - **Status Indicators:** Four dedicated LEDs indicate PoE status for each port. - **Compact Form Factor:** Dimensions of 168 mm (W) × 111.15 mm (L) suitable for standard PCIe slots. - **Environmental Compliance:** Fully RoHS and WEEE compliant, ensuring eco-friendly design and disposal.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **PCI Express® x4 Interface:** Fully compliant with PCIe v2.1 (2.5 GT/s) for high-bandwidth data transfer. - **Dual Independent Gigabit Ethernet Ports:** Two fully integrated MAC/PHY ports supporting up to 1 Gb/s per channel. - **IEEE 802.3at PoE+ Support:** Provides up to 30W per port, enabling direct power delivery to connected cameras or devices. - **Comprehensive PoE Protection:** Safeguards against overvoltage, undervoltage, overcurrent, and overheating. - **Smart PoE Power Management:** Automatic power budget control, programmable PoE on/off switching, and real-time monitoring via SDK and utility. - **Jumbo Frame Support:** 9 KB jumbo frame capability for efficient large-packet data transfer. - **IEEE 1588 PTP Hardware Support:** Enables precise time synchronization across networked devices. - **Multi-Card and Multi-Camera Support:** Multiple PCIe-GIE7x cards can operate simultaneously in a single system without I/O conflicts. - **Wide Operating Temperature Range:** 0°C to +70°C for reliable operation in industrial environments. - **PoE Power Options:** Up to 20W from PCIe slot, 61.6W from 4-pin or 6-pin Molex connector, and up to 120W (PCIe-GIE74 PRO only) when both connectors are used. - **Software Compatibility:** Supports Windows® 7/8.1/10 with APIs for C#, VB.NET, and VC++. - **Optional PRO Features:** Trigger over Ethernet (ToE) for synchronized multi-camera acquisition and integrated software license management.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **PCI Express® x4 Interface:** Fully compliant with PCIe Gen2 x4, ensuring high data throughput and compatibility with modern industrial PCs. - **Dual Independent Gigabit Ethernet Ports:** Supports two fully integrated Gigabit Ethernet MAC and PHY ports for simultaneous multi-camera operation. - **PoE+ (Power over Ethernet Plus):** IEEE 802.3at compliant, delivering up to 30W per port for powering cameras directly through Ethernet cables. - **Comprehensive PoE Protection:** Built-in overcurrent and overvoltage protection with automated power budget control to safeguard connected devices. - **Smart PoE Management Utility:** Real-time monitoring and control of PoE power status via an intuitive software utility and API, enabling predictive maintenance and power prioritization. - **Trigger over Ethernet (ToE):** FPGA-based hardware synchronization for multi-camera triggering using Ethernet Action Commands (PRO models only). - **Software License Management:** Integrated license management system for secure software activation and deployment (PRO models only). - **High-Speed Data Transfer:** Supports up to **1 GB/s per channel** with **9 kB jumbo frame** capability for efficient large image data transmission. - **DDR RAM Buffer:** Equipped with **128 MB DDR RAM** for stable frame buffering and non-drop frame capture. - **Wide Operating Temperature Range:** Operates reliably from **0°C to +70°C**, suitable for fanless and rugged industrial systems. - **Multi-Card Support:** Multiple PCIe-GIE7x cards can be installed in a single system without occupying additional I/O resources, enabling scalable multi-camera setups. - **IEEE 1588 PTP Support:** Hardware-based Precision Time Protocol synchronization for precise timing across networked devices. - **Compact Design:** Small form factor (167.6 mm x 106.6 mm) suitable for space-constrained industrial PCs. - **Industrial-Grade Reliability:** Designed for continuous operation in harsh environments with humidity tolerance from 5% to 90% RH (non-condensing).

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **PCI Express® x4 Compliant:** Fully compatible with PCIe v2.1 (2.5 GT/s) interface, ensuring high data throughput and low latency. - **Four Independent Gigabit Ethernet Ports:** Each port supports up to 1 Gb/s data transfer rate, enabling simultaneous multi-camera operation. - **IEEE 802.3at PoE+ Support:** Provides up to 30W per port, delivering both power and data over a single Ethernet cable. - **Comprehensive PoE Protection:** Safeguards against overvoltage, undervoltage, overcurrent, and overheating. - **Automated Power Budget Control:** Dynamically allocates available power based on source and port priority. - **Smart PoE Management Utility and API:** Real-time monitoring and control of PoE status, power consumption, and port configuration. - **Multi-Card Support:** Multiple PCIe-GIE7x cards can be installed in a single system for large-scale vision setups. - **Wide Operating Temperature Range:** 0°C to +70°C for 60W operation; 0°C to +40°C for 120W operation. - **IEEE 1588 Precision Time Protocol (PTP):** Hardware-based synchronization for precise timing across devices. - **Trigger over Ethernet (ToE):** (PRO models only) Enables hardware-level synchronization of multiple cameras. - **Software License Management:** (PRO models only) Integrated EEPROM for secure software licensing without external dongles. - **Jumbo Frame Support:** 9 kB jumbo frames for efficient large-packet data transmission. - **Link Aggregation:** Supports network redundancy and bandwidth aggregation. - **PoE Power Source Flexibility:** Power can be drawn from PCIe slot, 4-pin, or 6-pin Molex connectors. - **LED Indicators:** Provide visual feedback for link, activity, and PoE status. - **Compatibility:** Windows® 7/8.1/10; supports C#, VB.NET, and VC++ development environments.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **PCI Express® x4 Compliant:** Fully compatible with PCIe Gen2 x4 interface, ensuring high bandwidth and low latency data transfer. - **Four Independent Gigabit Ethernet Ports:** Each port supports up to 1 Gb/s throughput for simultaneous multi-camera operation. - **IEEE 802.3at PoE+ Support:** Provides up to 30W per port, enabling direct power delivery to cameras and other PoE devices. - **Comprehensive PoE Protection:** Built-in overvoltage, undervoltage, overcurrent, and overtemperature protection mechanisms safeguard connected devices. - **Smart PoE Power Management:** Automatic power budget control, programmable PoE on/off switching, and real-time monitoring via SDK and utility. - **Trigger over Ethernet (ToE):** FPGA-based hardware synchronization for multi-camera triggering with minimal latency (PRO models only). - **Software License Management:** Integrated secure EEPROM for software licensing, eliminating the need for external dongles (PRO models only). - **IEEE 1588 PTP Hardware Support:** Enables precise time synchronization across multiple cameras and devices. - **Jumbo Frame Support:** 9 kB jumbo frame capability for efficient large-packet data transmission. - **Multi-Card Scalability:** Supports installation of multiple PCIe-GIE7x cards in a single system for large-scale vision setups. - **Wide Operating Temperature Range:** 0°C to +70°C operation ensures reliability in industrial environments. - **PoE Power Source Flexibility:** Power can be drawn from PCIe slot, 4-pin, or 6-pin Molex connectors, supporting up to 120W total PoE output. - **Software Compatibility:** Supports Windows® 7/8.1/10 with APIs for C#, VB.NET, and VC++.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Full HD Uncompressed Capture:** Supports 1920 × 1080p at 60 frames per second (fps) with 170 MHz sampling rate. - **Multi-Format Input Support:** Accepts both digital (DVI 1.0, HDMI 1.3 non-HDCP) and analog (RGB, YPbPr) video signals. - **PCI Express® x4 Interface:** High-speed data transfer with full compliance to PCIe x4 standard. - **Hardware Color Space Conversion:** Real-time RGB/YUV/monochrome conversion offloads CPU processing. - **512 MB DDR2 SDRAM Frame Buffer:** Dedicated onboard memory for stable, high-throughput video streaming. - **Configurable EDID (Extended Display Identification Data):** Allows custom EDID configuration for display compatibility. - **Digital I/O and Triggering:** 4 TTL digital inputs, 4 TTL digital outputs, and 1 TTL trigger input/output for synchronization. - **FPGA-Based Processing:** Field Programmable Gate Array enables flexible, low-latency image processing. - **DirectShow SDK and API Support:** Includes comprehensive software development kit for Windows platforms. - **ViewCreatorPro™ Utility:** GUI-based configuration and testing tool for video capture, I/O, and EDID management. - **Applications:** Medical imaging, scientific imaging, military/defense, video surveillance, and HD video testing.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Full HD Uncompressed Capture:** Supports 1920×1080p at 60 fps with 10-bit ADC precision. - **Multi-Format Video Input:** HDMI, DVI, RGB, YPbPr, S-Video, and NTSC/PAL composite. - **Audio Capture:** HDMI and S/PDIF (optical Toslink and RCA coaxial) digital audio input. - **High Bandwidth:** 170 MHz DVI input bandwidth for high-speed data throughput. - **Color Depth Support:** RGB 32/30/24-bit, YCrCb 4:4:4/4:2:2, and 8-bit monochrome. - **Hardware Acceleration:** FPGA-based color space conversion and image cropping. - **Configurable EDID:** Software-configurable Extended Display Identification Data (EDID 1.3). - **HDCP Support:** High-Bandwidth Digital Content Protection compliant. - **DirectShow SDK:** Full software development kit for Windows DirectShow and LabVIEW. - **Cross-Platform Software:** Compatible with Windows XP, Vista, and Windows 7 (32/64-bit). - **ViewCreatorPro Utility:** GUI-based configuration and testing tool for video/audio capture. - **PXI Express Variant:** PXIe-HDV62A version compliant with PXI Express Rev. 1.0.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Single-Channel HDMI 1.4 Capture:** Supports one HDMI 1.4 input channel for simultaneous video and audio capture. - **PCI Express x4 Gen3 Interface:** High-bandwidth PCIe Gen3 interface ensures stable, low-latency data transfer between the capture card and host system. - **Full HD Video Capture:** Capable of capturing high-definition video signals up to 1080p resolution at standard frame rates. - **Embedded Audio Support:** Captures both video and embedded HDMI audio streams, maintaining synchronization between audio and video data. - **Real-Time Acquisition:** Designed for real-time video capture and processing with minimal frame delay, ideal for live applications. - **Compact Design:** 150 mm × 98 mm PCB size allows easy integration into standard PCIe slots in desktop or industrial chassis. - **High Reliability:** Built with industrial-grade components for continuous operation in mission-critical environments. - **Broad Compatibility:** Compatible with major operating systems and software development environments for easy integration into custom applications. - **Low CPU Overhead:** Hardware-based capture and DMA transfer minimize CPU utilization during operation. - **Scalable Integration:** Multiple cards can be installed in a single system for multi-channel capture configurations.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **High-Definition Video Capture:** Supports HDMI 2.0 input with resolutions up to **4K/UHD (3840 × 2160) at 60 fps**, ensuring smooth, high-quality video acquisition. - **PCI Express Gen3 x4 Interface:** Provides high-bandwidth data transfer for real-time video streaming and minimal latency. - **Audio Capture Support:** Integrated audio input over HDMI for synchronized audio-video recording and streaming. - **Professional-Grade HDMI 2.0 Compatibility:** Ensures full compliance with HDMI 2.0 standards, supporting deep color, wide color gamut, and HDCP content protection (where applicable). - **Compact Form Factor:** Dimensions of **168 mm × 111 mm**, suitable for standard PCIe slots in desktop, workstation, and industrial PC environments. - **Low-Latency Streaming:** Optimized for real-time applications such as live broadcasting, video conferencing, surveillance, and machine vision. - **Multi-Platform Support:** Compatible with major operating systems and software frameworks for video capture and processing. - **Robust Build Quality:** Designed for continuous operation in demanding environments, with industrial-grade components ensuring reliability and longevity.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Dual Independent Gigabit Ethernet Ports:** Equipped with two Intel® 82574L Gigabit Ethernet controllers, each port supports full‑duplex 1000 Mb/s operation. - **Power over Ethernet (PoE) Support:** Fully compliant with IEEE 802.3af standard, each port can supply up to **15.4 W** of power to connected PoE devices such as cameras or sensors. - **PCI Express x4 Interface:** Utilizes a PCIe x4 interface providing a total bandwidth of **1 GB/s**, ensuring high‑speed data throughput for demanding imaging applications. - **9 kB Jumbo Frame Support:** Enables efficient transmission of large image data packets, reducing CPU overhead and improving throughput. - **Link Aggregation (Teaming):** Supports IEEE 802.3ad link aggregation for increased bandwidth and redundancy. - **No External Power Required:** The PCIe‑PoE2+ draws both 3.3 V and 12 V power directly from the PCIe bus, eliminating the need for an external 12 V DC input. - **Compact and Robust Design:** Industrial‑grade construction with a compact form factor (167.7 mm × 111.2 mm) suitable for integration into standard PC chassis. - **Wide Operating Temperature Range:** Operates reliably from **0 °C to 60 °C** with adequate airflow. - **Plug‑and‑Play Driver Support:** Includes Neousys Drivers & Utilities DVD with “One‑Click” automatic driver installation for Windows operating systems.

Manufacturer: Neousys Technology

Category: Frame Grabber

- **Four Gigabit Ethernet Ports:** Equipped with four Intel® I350-AM4 controllers, each supporting full Gigabit bandwidth, IEEE 1588 precision time protocol, and 9.5 KB jumbo frames for high-throughput data transmission. - **PoE+ Power Delivery:** Fully compliant with IEEE 802.3at-2009 (PoE+) standard, each port can deliver up to 25.5 W of power to connected devices such as IP cameras, sensors, or industrial controllers. - **Total Power Budget:** 75 W total PoE power budget, optimized for multi-camera or multi-device setups. - **Low-Profile Design:** Compact 167.7 mm x 69 mm form factor suitable for 2U rackmount servers and space-constrained systems. - **1 kV Surge and 8 kV ESD Protection:** Built-in surge protection compliant with IEC 61000-4-5 Class 2, ensuring durability in harsh industrial or outdoor environments. - **Advanced Networking Features:** Supports teaming, link aggregation, checksum offloading, segmentation offloading, and intelligent interrupt moderation to reduce CPU load and enhance throughput. - **Jumbo Frame Support:** Up to 9.5 KB frame size for efficient large-packet data transmission, ideal for high-resolution video streaming or machine vision data. - **IEEE 1588 Support:** Enables precise time synchronization across networked devices, critical for multi-camera or distributed control systems. - **Server-Grade Reliability:** Designed for continuous operation in industrial and commercial environments with 0°C to 55°C operating range (with airflow). - **Compatibility:** Works with standard CAT-5e or CAT-6 cables up to 100 meters.

Manufacturer: Neousys Technology

Category: Frame Grabber

- **PCI Express Gen2 x4 Interface:** Provides up to 2 GB/s total bandwidth, ensuring high-speed data transfer between the card and host system. - **Dual Intel® I350-AM2 Gigabit Ethernet Controllers:** Each port supports full Gigabit Ethernet throughput with advanced offloading features for optimized CPU utilization. - **IEEE 802.3at-2009 (PoE+) Compliance:** Each of the two ports can deliver up to **25.5 W** of power to connected PoE devices, such as cameras or sensors. - **Per-Port PoE Power Control:** Software-controllable power on/off for each port, allowing remote reset or power cycling of connected devices. - **Jumbo Frame Support:** Supports Ethernet jumbo frames up to **9.5 kB**, improving throughput and reducing CPU overhead for large data transfers. - **IEEE 1588 Precision Time Protocol (PTP):** Enables precise time synchronization across networked devices, essential for multi-camera or distributed vision systems. - **Link Aggregation and Teaming:** Supports network teaming for redundancy or bandwidth aggregation. - **Server-Grade Reliability:** Built with Intel’s enterprise-class Ethernet controller for long-term stability and compatibility with industrial systems. - **Compact PCIe Form Factor:** Standard PCIe x4 card dimensions (167.7 mm x 111.2 mm) suitable for most industrial PCs and servers.

Manufacturer: Neousys Technology

Category: Frame Grabber

- **PCI Express Interface:** x4, Gen2 PCIe interface providing up to 2 GB/s total bandwidth. - **Server-Grade Ethernet Controller:** Utilizes Intel® I350-AM4 controller for superior reliability and performance. - **Four Independent Gigabit Ports:** Each port supports 10/100/1000 Mbps operation with full-duplex capability. - **IEEE 802.3at PoE+ Compliance:** Delivers up to 25.5 W per port, enabling direct power supply to PoE devices such as cameras and sensors. - **Per-Port PoE Power Control:** Software-controllable on/off switching for each PoE port, allowing remote device reset and power management. - **Advanced Networking Features:** - Jumbo frame support up to 9.5 KB - Link aggregation (teaming) for bandwidth scaling and redundancy - IEEE 1588 Precision Time Protocol (PTP) for time synchronization - Checksum and segmentation offloading to reduce CPU load - Intelligent interrupt moderation for optimized throughput - **Flexible Power Input:** Selectable 12 VDC source from PCIe bus or external 4-pin connector via jumper configuration. - **High Compatibility:** Single-bus, multi-port topology minimizes motherboard compatibility issues when multiple cards are installed. - **Industrial-Grade Design:** Operating temperature range of 0°C to 55°C with airflow, suitable for embedded and industrial environments. - **Applications:** Machine vision, automated optical inspection (AOI), surveillance, medical imaging, and traffic enforcement systems.

Manufacturer: Neousys Technology

Category: Frame Grabber

- **Four Independent Gigabit Ethernet Ports:** Equipped with four Intel® 82574L GbE controllers, each port supports full-duplex 1000 Mb/s operation, ensuring high throughput for data-intensive applications. - **Power over Ethernet (PoE) Support:** Fully compliant with IEEE 802.3af standard, each port can deliver up to 15.4 W of power to connected PoE devices such as cameras, sensors, or network modules. - **PCI Express x4 Interface:** Utilizes a PCIe x4 interface providing a total bandwidth of 1 GB/s, ensuring stable and high-speed communication between the card and host system. - **9 kB Jumbo Frame Support:** Enables efficient transmission of large data packets, reducing CPU load and improving overall data throughput—ideal for high-resolution image acquisition. - **Link Aggregation (Teaming):** Supports link aggregation for increased bandwidth and redundancy, allowing multiple ports to operate as a single logical link. - **Extended Cable Length:** Supports CAT-5e or CAT-6 cables up to 100 meters, providing flexibility in system layout and camera placement. - **External Power Input:** Features an onboard 4-pin power connector for additional +12V input, ensuring stable PoE power delivery across all four ports. - **Industrial-Grade Design:** Designed for continuous operation in industrial environments with an operating temperature range of 0°C to 60°C (with airflow). - **Driver and Utility Support:** Includes Neousys Drivers & Utilities DVD with “One-Click” driver installation for Windows XP, Vista, and Windows 7 (32/64-bit).

Manufacturer: Neousys Technology

Category: Frame Grabber

- **Dual 10GbE Ports:** Equipped with two Intel® X550-AT2 10 Gigabit Ethernet controllers, enabling simultaneous high-speed data transmission across two independent channels. - **PCI Express Gen3 x4 Interface:** Ensures high data throughput and compatibility with modern industrial PCs and servers. - **IEEE 802.3at PoE+ Support:** Provides up to **25.5W per port**, allowing direct power delivery to connected devices such as cameras, access points, or sensors via Ethernet cables. - **Cable Compatibility:** - 10GBASE-T operation with **CAT 6a cable up to 100 meters** or **CAT 6 cable up to 55 meters**. - NBASE-T (2.5G/5G) operation with **CAT 5e or CAT 6 cables up to 100 meters**. - Backward compatible with **1000BASE-T (Gigabit Ethernet)** networks. - **Advanced Networking Features:** - **15.5 KB jumbo frame** support for efficient large-packet data transfer. - **NIC teaming** for redundancy and load balancing. - **IEEE 1588 Precision Time Protocol (PTP)** support for synchronized data acquisition and time-sensitive applications. - **Per-Port PoE+ Power Control:** Software API allows individual port power on/off management for flexible device control. - **High Reliability and Signal Integrity:** Optimized power design ensures stable 10G PHY operation and consistent bandwidth performance. - **Machine Vision Ready:** Engineered for industrial imaging systems, enabling high-speed data transfer and power delivery to GigE Vision cameras over a single cable.

Manufacturer: Neousys Technology

Category: Frame Grabber

- **Quad‑Channel Real‑Time Capture:** Simultaneous acquisition of four analog video inputs using four BT878A encoders. Supports both color (PAL, NTSC, SECAM) and monochrome (CCIR, EIA/RS‑170) formats. - **Scalable Multi‑Input Architecture:** Expandable up to 16 video inputs using three RTV‑E4 channel extension modules via onboard 10‑pin headers. - **Programmable Image Processing:** Adjustable hue, brightness, contrast, and saturation (0–200 % range). Supports automatic chrominance gain control and optional image scaling down to 1:16. - **Flexible Resolution Control:** Programmable resolutions including square‑pixel (640 × 480 NTSC, 768 × 576 PAL) and broadcast resolutions. Supports arbitrary cropping and region‑of‑interest selection. - **High‑Speed Acquisition:** - NTSC: up to 240 fields (120 fps) across four cameras - PAL: up to 200 fields (100 fps) across four cameras - Continuous real‑time capture across all channels - **Robust I/O and Triggering:** 4 × TTL inputs, 4 × TTL outputs, and 4 × software‑trigger lines. Programmable trigger pulse width from 60 µs to 16 ms. GPIO lines are ESD‑protected and overload‑resistant. - **Hardware Watchdog Timer:** Monitors system activity and automatically resets the host PC after a programmable inactivity timeout, ensuring fault‑tolerant operation. - **User EEPROM:** 1 Kbit onboard EEPROM for user‑defined data storage. - **Software Support:** WDM drivers for Windows 98/NT/2000/XP. Compatible with Visual C++, Visual Basic, Borland C++ Builder, and Delphi. Includes ViewCreator utility for configuration, testing, and image capture. - **Applications:** - PC‑based digital video recorders (DVR) - Security and surveillance systems - Factory and process monitoring - Machine vision inspection - Scientific and medical imaging instrumentation

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Multi‑Channel Real‑Time Video Capture:** Supports up to four composite analog video inputs through a DB‑9 connector, digitized via dual Connexant 878A encoders. Compatible with NTSC, PAL, SECAM, CCIR, and EIA video standards. - **Simultaneous Dual Encoder Operation:** Two 878A chips allow concurrent acquisition of two video streams, ensuring synchronized capture for multi‑camera systems. - **Programmable Resolution and Scaling:** Supports full broadcast and square‑pixel resolutions (NTSC 640×480, PAL 768×576). Programmable region‑of‑interest (ROI) cropping and down‑scaling up to 1:16 ratio. - **Color and Monochrome Support:** Handles composite color (NTSC‑M/J, PAL‑B/D/G/H/I/M/N, SECAM) and monochrome (CCIR, EIA/RS‑170) signals. - **Adjustable Image Parameters:** Software‑controlled hue, brightness, contrast, and saturation (0–200 % range). Automatic chrominance gain control for stable color reproduction. - **General Purpose I/O (GPIO):** One TTL‑compatible input and one output line, configurable for external triggers or alarm signaling. - **User EEPROM:** 1 Kbit non‑volatile memory for user‑defined data storage. - **Software Support:** WDM driver package for Windows 98/NT/2000/XP. Compatible with Visual C++, Visual Basic, Borland C++ Builder, and Delphi. Includes ViewCreator utility for configuration, testing, and image capture. - **Watchdog Timer (via software library):** Programmable watchdog for system reliability and automatic reset on timeout. - **Compact Embedded Form Factor:** 32‑bit, 33 MHz PMC module for integration into cPCI CPU boards or embedded controllers.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Full HD Uncompressed Video:** Supports 1920 × 1080p at 60 frames per second (fps) with 10-bit high-resolution analog-to-digital conversion (ADC). - **Multi-Format Video Input:** Compatible with HDMI, DVI, RGB, YPbPr, S-Video, and NTSC/PAL composite signals. - **Audio Capture:** Supports HDMI and S/PDIF (optical Toslink and coaxial RCA) digital audio inputs. - **High Bandwidth:** 170 MHz video bandwidth for uncompressed RGB 32/30/24-bit and YCrCb 4:4:4/4:2:2 formats. - **HDCP Support:** Compliant with High-Bandwidth Digital Content Protection for secure digital content capture. - **Configurable EDID:** Allows user-defined Extended Display Identification Data for flexible display emulation. - **Integrated Frame Buffer:** 512 MB DDR2 onboard memory for stable, high-speed data streaming. - **DirectShow SDK:** Includes comprehensive software development kit with DirectShow and API support for Windows platforms. - **PXI Express Interface:** Fully compliant with PXI Express Rev. 1.0, ensuring high throughput and synchronization in modular test systems. - **Direct SDK Support:** Provides low-level API for C/C++, C#, and VB.NET for custom application development. - **Environmental Compliance:** RoHS and WEEE compliant, reflecting ADLINK’s environmental responsibility.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Channel Expansion:** Adds four additional composite video input channels to the RTV‑24 base board. - **High‑Performance Video Acquisition:** Supports real‑time capture of multiple analog video streams (PAL, NTSC, CCIR, EIA). - **Scalable Architecture:** Up to 16 total channels can be configured using multiple RTV‑E4 boards connected to the RTV‑24 via onboard 10‑pin headers. - **Flexible Video Formats:** Compatible with NTSC‑M, NTSC‑Japan, PAL‑B/D/G/H/I/M/N, and SECAM color standards, as well as CCIR and EIA monochrome formats. - **Programmable Image Processing:** Adjustable hue, brightness, contrast, and saturation; optional image scaling (down to 1:16) and cropping to region of interest. - **TTL‑Compatible I/O Lines:** 4 digital inputs, 4 outputs, and 4 software trigger lines with overload and ESD protection. - **Watchdog Timer:** Hardware watchdog for system reliability; automatically resets the host PC after a programmable inactivity timeout. - **User EEPROM:** 1 Kbit non‑volatile memory for user‑defined data storage. - **Software Support:** WDM drivers for Windows NT/98/2000/XP; compatible with VC++, VB, Borland C++ Builder, and Delphi. - **Utility Software:** Bundled ViewCreator utility for configuration, testing, and image capture verification. - **Compact PCI/PCI/PMC Compatibility:** Designed for integration with ADLINK’s RTV‑24 PCI frame grabber and compatible Angelo series boards.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber

- **Four Isolated GPIO Channels:** Provides four independent, optically isolated digital I/O channels for enhanced signal integrity and protection against electrical noise and surges. - **Seamless Integration with RTV‑24:** Designed as a plug‑in extension board for the ADLINK RTV‑24 frame grabber, extending its I/O functionality without additional interface hardware. - **TTL‑Compatible Logic Levels:** Supports standard 5 V TTL logic for compatibility with a wide range of industrial sensors, actuators, and control devices. - **Bidirectional Configuration:** Each GPIO line can be configured as input or output, allowing flexible control and monitoring setups. - **Electrostatic and Overload Protection:** Built‑in protection circuitry ensures reliable operation in electrically noisy environments. - **Software‑Configurable I/O:** Fully programmable through ADLINK’s ViewCreator utility and the AngeloRTV API library. - **Real‑Time Triggering Support:** Enables hardware and software triggers for synchronized image capture and external event control. - **Compact Form Factor:** Small, lightweight board designed for internal installation within PC‑based vision systems. - **Industrial Reliability:** Designed for continuous operation in surveillance, machine vision, and automation environments.

Manufacturer: Adlink Technology Inc.

Category: Frame Grabber
