1. Product Overview
Product Name: AX5301
Model Number: AX5301
Series: AX5300 Series Expansion Modules
Article Number: AX5301
Manufacturer: Axiom
The Axiom AX5301 is a high-performance 2-channel Digital-to-Analog (DA) extension card designed as an expansion module for the Axiom AX5300 series. It provides precise analog output capabilities with 12-bit resolution and supports multiple output ranges, including current and voltage modes. The AX5301 is engineered for industrial automation, process control, and data acquisition systems requiring reliable, isolated analog output channels. It integrates seamlessly with the AX5300 main unit, allowing users to expand analog output capacity up to a total of eight DA channels per system.
2. Key Features
- 2 Isolated Analog Output Channels: Provides two independent DA channels for flexible analog signal generation.
- 12-bit Resolution: Ensures fine granularity and precision in analog output control, suitable for demanding industrial applications.
- Multiple Output Ranges: Supports configurable output ranges including 0–20 mA, 4–20 mA, ±5 V, ±10 V, 0–5 V, and 0–10 V, enabling compatibility with a wide range of sensors, actuators, and control systems.
- High Isolation Protection: 500 VDC isolation between channels and between each channel and the PCI bus, enhancing system safety and minimizing interference.
- Integrated DC/DC Converter: Provides isolated power for each channel, ensuring stable operation and reducing noise coupling.
- PCI Bus Interface: Designed for easy integration into PCI-based control systems, offering plug-and-play expansion for the AX5300 main controller.
- Compact Half-Size Form Factor: Optimized for space-constrained installations, allowing efficient use of rack or chassis space.
- Expandable System Architecture: When used with the AX5300 main unit, supports up to eight DA channels in total, enabling scalable analog output configurations.
- Industrial-Grade Reliability: Built for continuous operation in industrial environments, with robust electrical isolation and durable construction.
3. Technical Specifications
- Bus Interface: PCI bus (compatible with AX5300 main unit)
- Number of Channels: 2 isolated analog output channels
- Resolution: 12 bits
- Output Ranges:
- Current: 0–20 mA, 4–20 mA
- Voltage: ±5 V, ±10 V, 0–5 V, 0–10 V
- Isolation Voltage: 500 VDC channel-to-channel and channel-to-bus isolation
- Isolation Type: Galvanic isolation with integrated DC/DC converter
- Form Factor: Half-size PCI card
- Power Supply: Derived from PCI bus with onboard DC/DC conversion for isolation
- Maximum Expansion: Up to 8 DA channels total when combined with AX5300 main unit
- Manufacturer: Axiom
- Model Compatibility: Designed for use exclusively with AX5300 series main modules
*Physical Characteristics:*
- Dimensions: Half-size PCI card (approx. 175 mm length × 107 mm height × 20 mm width, typical for half-size format)
- Weight: Approximately 150–200 g (typical for half-size PCI expansion cards)
- Material: Multi-layer PCB with industrial-grade components, metal bracket for PCI mounting
*Environmental Specifications:*
- Operating Temperature: Typically 0°C to +60°C (industrial range)
- Storage Temperature: -20°C to +85°C
- Humidity: 10–90% RH, non-condensing
- Cooling: Passive, convection-cooled
4. Functionality
The AX5301 functions as a Digital-to-Analog (DA) output expansion card that converts digital control signals from the AX5300 main unit into precise analog voltage or current outputs. Each of the two channels operates independently, allowing simultaneous generation of different analog signals.
Operation Principle:
- The AX5301 receives digital data from the AX5300 controller via the PCI bus.
- The onboard 12-bit DAC circuitry converts the digital values into corresponding analog signals.
- The integrated DC/DC converter provides isolated power to each channel, ensuring electrical separation and minimizing noise.
- The analog outputs can be configured for voltage or current mode depending on the connected device or system requirement.
Use Cases and Applications:
- Industrial process control systems requiring analog actuator control (e.g., valves, motors, drives).
- Data acquisition and signal generation in laboratory or test environments.
- SCADA and PLC systems needing additional analog output channels.
- Automation systems for temperature, pressure, or flow control loops.
- Integration with analog instrumentation and transducers.
Compatibility:
- Fully compatible with Axiom AX5300 main control units.
- Designed for PCI bus systems supporting Axiom’s modular expansion architecture.
- Works with standard industrial analog devices accepting 0–10 V, ±10 V, or 4–20 mA signals.
5. Components & Accessories
Included Items:
- AX5301 2-channel DA extension card
- PCI mounting bracket (pre-installed)
- User documentation or quick installation guide (depending on package)
Optional Accessories:
- Shielded analog output cables (for noise-sensitive environments)
- Terminal breakout boards for easier wiring and signal distribution
- Additional AX5300 modules for system expansion
- Mounting hardware for rack or chassis integration
Connectors:
- Standard analog output connector (type depends on AX5300 system interface, typically terminal block or D-sub connector)
- PCI edge connector for data and power interface with AX5300 main unit
6. Installation & Setup
Requirements:
- AX5300 main unit with available PCI expansion slot
- Compatible operating environment (industrial PC or control chassis supporting PCI bus)
- Proper grounding and shielding for analog signal integrity
Installation Steps:
1. Power down the AX5300 system and disconnect from mains.
2. Insert the AX5301 card into an available PCI expansion slot on the AX5300 main unit.
3. Secure the card using the mounting bracket screw.
4. Connect analog output wiring to the designated output terminals or connector.
5. Power on the system and verify recognition of the new DA channels.
6. Configure output ranges and channel parameters via the AX5300 control software or system interface.
Mounting Options:
- Standard PCI slot mounting within the AX5300 chassis.
- Can be used in rack-mounted or desktop industrial PCs supporting half-size PCI cards.
Configuration:
- Output range and mode (voltage or current) selectable via software or hardware jumpers (depending on system configuration).
- Calibration and scaling performed through AX5300 software tools.
7. Performance & Capabilities
Analog Output Performance:
- Resolution: 12 bits (4096 discrete output levels)
- Accuracy: Typically ±0.1% of full scale (depending on calibration and environment)
- Update Rate: Determined by AX5300 system clock and bus speed; suitable for real-time control applications.
- Load Resistance:
- Voltage output: ≥2 kΩ recommended
- Current output: ≤500 Ω recommended
- Output Drive Capability: Sufficient to drive standard industrial loads and instrumentation inputs.
Speed and Capacity:
- Two simultaneous analog outputs per AX5301 card.
- Up to four AX5301 cards can be used with one AX5300 main unit, providing a total of eight DA channels.
- High-speed PCI bus communication ensures low-latency data transfer between the main controller and the DA card.
Efficiency and Reliability:
- Integrated DC/DC converter ensures efficient power isolation and minimal cross-channel interference.
- Low power consumption due to efficient analog circuitry design.
- Stable operation under continuous load conditions.
Limitations:
- Designed exclusively for use with AX5300 systems; not a standalone PCI DA card.
- Limited to 12-bit resolution; for higher precision, other Axiom models may be required.
- Environmental conditions must remain within specified operating limits for optimal performance.
8. Standards & Compliance
Certifications and Compliance:
- Electrical Safety: Complies with industrial safety standards for isolated analog output modules.
- EMC Compliance: Designed to meet electromagnetic compatibility requirements for industrial environments (EN 61000 series).
- RoHS Compliance: Manufactured in accordance with Restriction of Hazardous Substances (RoHS) directives.
- Quality Standards: Produced under ISO 9001-certified manufacturing processes.
Industry Standards:
- PCI bus interface standard compliance (PCI Local Bus Specification).
- Analog output signal ranges conform to common industrial instrumentation standards (0–10 V, 4–20 mA).
- Isolation and grounding practices consistent with IEC 61010-1 for measurement and control equipment.
9. Additional Information
Warranty:
- Standard manufacturer’s warranty (typically 1–2 years, depending on region and distributor).
- Covers defects in materials and workmanship under normal operating conditions.
Support:
- Technical support available through Axiom’s customer service and online resources.
- Firmware and software updates provided for AX5300 system compatibility.
- Documentation includes installation guides, wiring diagrams, and configuration instructions.
Maintenance:
- Minimal maintenance required; periodic inspection of connectors and wiring recommended.
- Ensure proper ventilation and dust-free environment for long-term reliability.
- Calibration checks may be performed periodically to maintain output accuracy.
Updates and Compatibility:
- Fully compatible with current AX5300 firmware and software versions.
- Future firmware updates may enhance configuration flexibility and diagnostic capabilities.
- Backward-compatible with earlier AX5300 system revisions supporting PCI expansion.
Summary
The Axiom AX5301 is a robust, precision-engineered 2-channel 12-bit DA extension card designed for seamless integration with the AX5300 series. It provides flexible analog output options (current and voltage), high isolation (500 VDC), and reliable performance in industrial automation and control systems. With its half-size PCI form factor, integrated DC/DC converter, and expandable architecture supporting up to eight DA channels, the AX5301 delivers scalable, high-quality analog output functionality for demanding applications.
Built to meet industrial standards for safety, EMC, and reliability, the AX5301 exemplifies Axiom’s commitment to modular, high-performance control solutions. It is ideal for engineers and system integrators seeking a dependable, isolated analog output expansion module for precision control and data acquisition environments.
