Comprehensive Product Summary: ADLINK cPCI-6208V/R-GL

---

### 1. Product Overview

Product Name: cPCI-6208V/R-GL
Model: cPCI-6208V/R-GL
Series: 6208/6216-GL Series (Multi-channel Analog Output Cards)
Article Number: cPCI-6208V/R-GL
Manufacturer: ADLINK Technology Inc.

Product Description:
The ADLINK cPCI-6208V/R-GL is an 8-channel, 16-bit analog output card designed for CompactPCI systems with rear I/O connectivity. It provides bipolar ±10 V voltage outputs with a maximum output current of ±5 mA per channel. The module features a high-speed 2 µs settling time, integrated DC/DC converter, and additional 4-channel digital input and 4-channel digital output lines. It is fully compliant with the CompactPCI PICMG 2.0 R2.1 standard and is optimized for industrial automation, process control, and signal generation applications.

---

### 2. Key Features

- High-Resolution Analog Output:
8 independent 16-bit digital-to-analog (D/A) channels with ±10 V bipolar output range and 15-bit guaranteed monotonicity.

- Rear I/O Configuration:
Rear I/O interface for CompactPCI backplane integration, enabling clean front-panel design and simplified cabling.

- Fast Response and Accuracy:
Typical settling time of 130 µs for a 20 V step and a typical slew rate of 26 V/µs, ensuring precise and rapid signal generation.

- Integrated DC/DC Converter:
Provides stable power isolation and improved noise immunity for industrial environments.

- Digital I/O Support:
4 TTL-compatible digital input channels and 4 TTL-compatible digital output channels for auxiliary control and monitoring.

- CompactPCI Compliance:
3U Eurocard form factor, fully compliant with PICMG 2.0 R2.1 CompactPCI specifications.

- Software and OS Compatibility:
Supports Windows 7/8 (x86/x64) and Linux operating systems. Compatible with LabVIEW™, MATLAB®, Visual Studio.NET, C/C++, and Visual Basic.

- Plug and Play Configuration:
Automatic resource allocation via PCI Plug and Play BIOS, eliminating manual jumper or switch settings.

- High Reliability:
Designed for industrial-grade operation with wide temperature and humidity tolerance.

---

### 3. Technical Specifications

Analog Voltage Output:
- Channels: 8 voltage output channels
- Resolution: 16-bit (15-bit guaranteed monotonicity)
- Output Range: ±10 V bipolar
- Output Drive Capability: ±5 mA maximum per channel
- Slew Rate: 26 V/µs typical
- Settling Time: 130 µs typical for a 20 V step
- Gain Error: ±0.2% maximum
- Differential Nonlinearity (DNL): ±1 LSB typical
- Output Initial Status: 0 V after reset or power-on
- Data Transfer Mode: Programmed I/O

Digital I/O:
- Channels: 4 digital inputs and 4 digital outputs
- Logic Level: 5 V TTL compatible
- Input Voltage:
- Logic Low: 0–0.8 V
- Logic High: 2.0–5.5 V
- Output Voltage:
- Logic Low: ≤0.4 V
- Logic High: ≥2.4 V
- Drive Capability:
- Sink: 8 mA at 0.5 V
- Source: 0.4 mA at 2.7 V

General:
- I/O Connector: One 37-pin D-sub female connector (rear I/O)
- Operating Temperature: 0°C to +50°C (32°F to 122°F)
- Storage Temperature: -20°C to +80°C (-4°F to 176°F)
- Relative Humidity: 5% to 95%, non-condensing
- Power Requirements:
- +5 VDC @ 500 mA typical
- +12 VDC @ 200 mA typical
- Dimensions: 160 mm × 100 mm (6.24” × 3.9”)
- Form Factor: 3U Eurocard, CompactPCI

---

### 4. Functionality

Operational Overview:
The cPCI-6208V/R-GL converts digital input data into precise analog voltage outputs across eight independent channels. Each channel is equipped with a dedicated 16-bit DAC, allowing simultaneous or individual updates. The card interfaces with the CompactPCI backplane through a 32-bit PCI bus, supporting plug-and-play configuration.

Use Cases and Applications:
- Industrial process control and automation
- Servo and motion control systems
- Signal and waveform generation
- Reference voltage generation
- Automated test equipment (ATE)
- SCADA and HMI integration

Compatibility:
- CompactPCI backplanes compliant with PICMG 2.0 R2.1
- Compatible with ADLINK terminal boards and cables
- Supported by ADLINK DAQPilot, DAQMaster, and legacy PCIS-DASK drivers
- Integrates with third-party software such as MATLAB®, LabVIEW™, and Agilent VEE™

---

### 5. Components & Accessories

Included Items:
- cPCI-6208V/R-GL analog output card
- ADLINK All-in-One software CD (drivers, utilities, manuals)
- User’s manual
- Rear I/O backplane (cPCI-R6216DB) for rear connectivity

Optional Accessories:
- DIN-37D-01: Terminal board with one 37-pin D-sub connector and DIN-rail mounting
- ACLD-9137-01: General-purpose terminal board with 37-pin D-sub male connector
- ACLD-9137F-01: General-purpose terminal board with 37-pin D-sub female connector
- ACL-10137-1MM: 37-pin D-sub male/male cable, 1 meter
- ACL-10137-1MF: 37-pin D-sub male/female cable, 1 meter

---

### 6. Installation & Setup

Requirements:
- CompactPCI chassis with available 3U slot and rear I/O support
- Proper grounding and anti-static precautions during installation
- Compatible operating system (Windows or Linux) with ADLINK drivers installed

Installation Steps:
1. Power off the CompactPCI system and disconnect all peripherals.
2. Insert the cPCI-6208V/R-GL card into an available 3U CompactPCI slot with rear I/O capability.
3. Secure the card using the mounting screws.
4. Connect the rear I/O transition module (if applicable).
5. Power on the system and allow the BIOS to detect the card automatically.
6. Install ADLINK DAQPilot or DAQMaster software for configuration and testing.

Configuration:
- Fully Plug and Play; no manual jumper settings required.
- Resource allocation (I/O address, IRQ) handled by system BIOS.
- Device management and calibration performed via DAQMaster or utility software.

---

### 7. Performance & Capabilities

Analog Output Performance:
- High-speed D/A conversion with 16-bit resolution
- ±10 V bipolar output range suitable for precision control
- Typical slew rate of 26 V/µs ensures fast signal transitions
- 130 µs settling time for full-scale voltage steps
- ±0.2% gain error and ±1 LSB DNL for high accuracy

Digital I/O Performance:
- TTL-compatible digital lines for control and monitoring
- Reliable signal integrity for industrial automation tasks

Efficiency and Limitations:
- Optimized for voltage output applications (no current output support on this model)
- Maximum output current limited to ±5 mA per channel
- Requires stable power supply and proper grounding for optimal performance

---

### 8. Standards & Compliance

- CompactPCI Compliance: PICMG 2.0 R2.1
- Bus Interface: 32-bit PCI bus (3.3 V or 5 V signaling)
- Form Factor: 3U Eurocard
- Environmental Compliance: Designed for industrial temperature and humidity ranges
- Software Standards:
- DAQPilot SDK for Windows
- DASK/X drivers for Linux
- MATLAB® and LabVIEW™ integration support
- Safety and Quality: Manufactured under ADLINK’s ISO-certified quality management system

---

### 9. Additional Information

Warranty:
Standard ADLINK limited warranty (typically one year). Recalibration recommended annually for optimal accuracy.

Support and Maintenance:
- Global technical support available through ADLINK regional offices.
- Software updates and driver downloads available at [www.adlinktech.com](http://www.adlinktech.com).
- Calibration services provided by ADLINK or authorized service centers.

Documentation and Utilities:
- User’s Manual (Part Number: 50-11234-2020, Revision 4.03)
- Utility Software: 6208UTIL.EXE for DOS-based function testing and calibration
- DAQMaster and DAQPilot for Windows-based configuration and diagnostics

Manufacturer Contact Information:
ADLINK Technology Inc.
9F, No.166 Jian Yi Road, Chungho City, Taipei County 235, Taiwan
Tel: +886-2-8226-5877 | Fax: +886-2-8226-5717
Email: service@adlinktech.com

Regional offices are available in the USA, Germany, France, Japan, Korea, Singapore, China, and India for localized support.

---

### Summary

The ADLINK cPCI-6208V/R-GL is a high-performance, 8-channel, 16-bit analog output card engineered for CompactPCI systems requiring precise voltage generation and robust industrial reliability. With ±10 V bipolar outputs, fast response times, and integrated digital I/O, it is ideal for automation, control, and test applications. Its compliance with PICMG 2.0 R2.1, broad software support, and plug-and-play configuration make it a versatile and dependable choice for system integrators and engineers seeking precision analog output in modular CompactPCI environments.
