EX9017F-M - TOPSCCC
8*AD, 12-bit, 50~60Hz, isolated Modbus-RTU
Network Ethernet - Serial Over IP is an industrial device server that enables users to connect Modbus Modules and Modbus AD In. With this device, users can easily integrate Modbus Modules and Modbus AD In into their existing network, allowing for efficient communication and data exchange..
218,00 €
incl. VAT 259,42 €
incl. VAT 259,42 €
Description
- The EX9017F-M Analog In 12 bit module can easily be integrated to a RS485 network
- The Analog In 12 bit module has 8 analogue inputs
- It may be used to measure analogue voltages in the measuring ranges ±150mV/±500mV/±1V/±5V and ±10V or currents in the range of ±20mA
- The Analog In 12 bit module has 60 Hz sampling rate
- The Analog In 12 bit module can be used in a wide temperature range
- features: 8 analog inputs
- measure voltages in measuring ranges from ±150mV to ±10V
- up to 60Hz sampling rate
- output as RS485 interface
- communicate via Modbus-RTU protocol
- In- and Output galvanically isolated
- manual configuration or with supplied software
- power supply 10 - 30VDC
Details
- Width: 57 mm
- Height: 90 mm
- Depth: 18 mm
- Form factor: Box
- Manufacturer: TOPSCCC
- Country of Origin: Taiwan R.O.C.
- Customs code: 8517 6200 900
