G-M1D061-M
Device Port Ethernet to RS232 metal case
89,00 EUR
including VAT 105.91 EUR
- Ethernet‑to‑RS232 Conversion: Provides transparent communication between Ethernet networks and serial RS‑232 devices.
- Industrial‑Grade Metal Housing: Rugged metal enclosure ensures mechanical durability and electromagnetic shielding for factory‑floor environments.
- Wolf Series Architecture: Shares the same modular design principles as Advanio’s Wolf RS‑485 remote I/O modules—compact, DIN‑rail mountable, and hot‑swappable.
- Wide Power Input Range: Operates from +10 to +60 V DC, supporting 12 V, 24 V, 36 V, and 48 V industrial supplies.
- High Isolation Protection: 3 kV DC isolation between power, communication, and I/O circuits prevents noise‑induced damage.
- Hot‑Swap and Auto‑Configuration: Non‑volatile EEPROM retains configuration; modules can be replaced without rewiring.
- Programmable Power‑On and Safety Values: Ensures controlled startup and fail‑safe operation during communication loss.
- EMC‑Certified Design: Complies with CE and FCC Part 15 Class A requirements for EMI/EMS immunity.
- Extended Environmental Range: Operates from –25 °C to +70 °C, humidity 5 – 95 % RH.
- Five‑Year Warranty: Long‑term reliability assurance for industrial deployments.
- Industrial‑Grade Metal Housing: Rugged metal enclosure ensures mechanical durability and electromagnetic shielding for factory‑floor environments.
- Wolf Series Architecture: Shares the same modular design principles as Advanio’s Wolf RS‑485 remote I/O modules—compact, DIN‑rail mountable, and hot‑swappable.
- Wide Power Input Range: Operates from +10 to +60 V DC, supporting 12 V, 24 V, 36 V, and 48 V industrial supplies.
- High Isolation Protection: 3 kV DC isolation between power, communication, and I/O circuits prevents noise‑induced damage.
- Hot‑Swap and Auto‑Configuration: Non‑volatile EEPROM retains configuration; modules can be replaced without rewiring.
- Programmable Power‑On and Safety Values: Ensures controlled startup and fail‑safe operation during communication loss.
- EMC‑Certified Design: Complies with CE and FCC Part 15 Class A requirements for EMI/EMS immunity.
- Extended Environmental Range: Operates from –25 °C to +70 °C, humidity 5 – 95 % RH.
- Five‑Year Warranty: Long‑term reliability assurance for industrial deployments.
Comprehensive Product Summary – Advanio G‑M1D061‑M Ethernet‑to‑RS232 Device Port (Wolf Series)
### 1. Product Overview
Product Name: Device Port Ethernet to RS232 (Metal Case)
Model Number: G‑M1D061‑M
Article Number: G‑M1D061‑M
Series: Wolf Series Industrial I/O and Communication Modules
Manufacturer: Advanio Technology Co., Ltd.
Manufacturer Background:
Advanio Technology Co., Ltd. is a Taiwan‑based industrial automation and IoT hardware manufacturer specializing in advanced input/output (I/O) and communication modules for Industry 4.0 applications. Founded by engineers with over 20 years of field experience, Advanio designs rugged, serviceable, and intelligent data‑acquisition devices for harsh industrial environments. The company’s product portfolio includes RS‑485, CAN, Ethernet, EtherCAT, PROFINET, Modbus/TCP, and wireless (Bluetooth, Wi‑Fi, 3G/4G) connectivity solutions, as well as industrial computing platforms.
### 2. Key Features
- Ethernet‑to‑RS232 Conversion: Provides transparent communication between Ethernet networks and serial RS‑232 devices.
- Industrial‑Grade Metal Housing: Rugged metal enclosure ensures mechanical durability and electromagnetic shielding for factory‑floor environments.
- Wolf Series Architecture: Shares the same modular design principles as Advanio’s Wolf RS‑485 remote I/O modules—compact, DIN‑rail mountable, and hot‑swappable.
- Wide Power Input Range: Operates from +10 to +60 V DC, supporting 12 V, 24 V, 36 V, and 48 V industrial supplies.
- High Isolation Protection: 3 kV DC isolation between power, communication, and I/O circuits prevents noise‑induced damage.
- Hot‑Swap and Auto‑Configuration: Non‑volatile EEPROM retains configuration; modules can be replaced without rewiring.
- Programmable Power‑On and Safety Values: Ensures controlled startup and fail‑safe operation during communication loss.
- EMC‑Certified Design: Complies with CE and FCC Part 15 Class A requirements for EMI/EMS immunity.
- Extended Environmental Range: Operates from –25 °C to +70 °C, humidity 5 – 95 % RH.
- Five‑Year Warranty: Long‑term reliability assurance for industrial deployments.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Power Supply | +10 V DC to +60 V DC (reverse‑polarity protected) |
| Power Consumption | Approx. 1.6 W @ 24 V DC |
| Communication Interface | Ethernet 10/100 Base‑T to RS‑232 serial port |
| Protocol Support | Modbus RTU / Modbus TCP / transparent serial tunneling |
| Isolation Voltage | 3,000 V DC between power, communication, and I/O |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –30 °C to +75 °C |
| Humidity | 5 % to 95 % RH (non‑condensing) |
| Enclosure Material | Aluminum alloy, anodized finish |
| Mounting | DIN‑rail 35 mm or wall‑mount |
| Dimensions (typ.) | 47.2 mm (W) × 115 mm (H) × 130 mm (D) |
| Weight | Approx. 0.9 kg |
| Connectors | Plug‑in terminal blocks (#16 – 30 AWG) for power and RS‑232; RJ‑45 for Ethernet |
| Communication Distance (RS‑232) | Up to 15 m (standard RS‑232 limit) |
| Communication Distance (Ethernet) | 100 m per segment (standard Cat 5e/6 cabling) |
| Baud Rate (Serial) | 1200 – 115.2 kbps selectable |
| Indicators | Power LED, System LED, Communication LED (status and diagnostic patterns) |
| Watchdog Timers | Hardware (module) 1.6 s fixed; software (system) programmable (0 – 25.5 s) |
| Isolation Type | Photo‑coupler and DC/DC converter isolation |
| Compliance | CE EMC, FCC Part 15 Class A, RoHS Directive 2011/65/EU |
### 4. Functionality
Operating Principle:
The G‑M1D061‑M functions as a serial‑device server, bridging Ethernet‑based control systems (PLCs, SCADA, DCS, or industrial PCs) with legacy RS‑232 equipment such as sensors, controllers, or instrumentation. It encapsulates serial data into TCP/IP packets for network transmission and converts incoming Ethernet data back to RS‑232 signaling.
Use Cases and Applications:
- Remote data acquisition and process monitoring
- Industrial automation and machine control
- Energy management and power‑distribution monitoring
- Building automation and HVAC control
- Laboratory instrumentation and test systems
- Security and access‑control integration
- Supervisory control and data logging
Compatibility:
- Fully interoperable with Modbus RTU and Modbus TCP protocols.
- Compatible with Advanio Wolf RS‑485 I/O modules, EtherCAT and PROFINET networks via gateway integration.
- Supports standard Ethernet infrastructure (switches, routers, industrial hubs).
### 5. Components & Accessories
Included Items:
- G‑M1D061‑M module (metal housing)
- Detachable DIN‑rail mounting base and plastic grounding tab
- 14‑pin signal connector for RS‑232 and power terminals
- Quick Start Guide and documentation
Optional Accessories:
- G‑M1E001: RS‑232 to RS‑485 converter (isolated)
- G‑M1A001: USB to RS‑485 converter
- G‑M1F001: RS‑485 repeater (for extended distance > 1200 m)
- DIN‑rail grounding tabs (metal or plastic for frame ground isolation)
- Wall‑mount brackets and screw kits
Connectors:
- Power Input: 2‑pin terminal (+VS, GND)
- Frame Ground (F.G.): dedicated terminal or DIN‑rail ground tab
- RS‑232 Port: DB9 male or terminal block depending on configuration
- Ethernet Port: RJ‑45 10/100 Base‑T auto‑negotiation
### 6. Installation & Setup
Requirements:
- DC power supply 10 – 60 V DC (≤ 5 V ripple Vpp)
- Host PC or controller with Ethernet or RS‑232 port
- Standard Cat 5e/6 Ethernet cable and shielded serial cable
Mounting Options:
1. DIN‑Rail Mounting: Attach the detachable base to a DIN 35 mm rail; modules can be docked side‑by‑side using 14‑pin connecting arrays for power and communication bus continuity.
2. Wall Mounting: Secure the base to a flat surface using screw holes provided; insert the module vertically.
Grounding:
- When mounted on metal DIN rails, use the rail as frame ground (F.G.).
- For non‑conductive mounting, connect F.G. via the power connector terminal.
- Plastic grounding tabs may be used to isolate modules from noisy grounds.
Configuration:
- Node Address: Set via two rotary switches (0x01 – 0xF7).
- Baud Rate and Parity: Configurable through Advanio Setup Utility or Modbus register 44107 (0x100A).
- Factory Reset: Press INIT button for 3 seconds to restore defaults (9600 bps, N, 8, 1).
- EEPROM Backup: Stores all parameters; can be transferred to replacement modules for instant recovery.
Network Topologies:
- Daisy Chain: Modules connected serially via RS‑485 bus or Ethernet switch.
- Star: Multiple modules connected to central switch or repeater.
- Hybrid/Random: Combination for complex plant layouts.
### 7. Performance & Capabilities
- Communication Speed: Serial 1200 – 115.2 kbps; Ethernet 10/100 Mbps auto‑negotiation.
- Transmission Distance: RS‑232 ≤ 15 m; Ethernet ≤ 100 m per segment (extendable via switches or repeaters).
- Throughput: Optimized for low‑latency Modbus RTU/TCP transactions.
- Isolation Protection: 3 kV DC galvanic isolation between power, communication, and I/O.
- Watchdog Recovery: Hardware watchdog resets module after 1.6 s of fault; software watchdog monitors host polling intervals and forces safe state on timeout.
- Reliability Features: Reverse‑polarity protection, over‑voltage protection, and surge suppression on communication lines.
- Environmental Endurance: Designed for continuous operation in harsh industrial conditions with high EMI and temperature fluctuations.
- Maintenance Efficiency: LED diagnostics and rotary switch addressing allow on‑site service without a computer.
Limitations:
- Single RS‑232 channel per module.
- Ethernet segment limited to 100 m without repeater.
- Configuration changes require power cycle to take effect.
### 8. Standards & Compliance
- Electrical Safety: Designed for industrial control equipment per EN 61010‑1.
- EMC Compliance: Tested for EMI and EMS per EN 55032 and EN 61000‑6‑2.
- FCC Compliance: Part 15 Class A — device may not cause harmful interference and must accept any received interference.
- CE Marking: Conforms to European EMC Directive 2014/30/EU.
- RoHS Compliance: Meets Directive 2011/65/EU for hazardous substance restriction.
- Quality Assurance: All modules undergo functional burn‑in and environmental stress testing prior to shipment.
### 9. Additional Information
Warranty:
- Duration: 5 years from date of original purchase.
- Coverage: Free repair or replacement for defects in materials or workmanship.
- Exclusions: Damage from improper installation, modification, or misuse by non‑certified personnel.
- Procedure: Contact authorized dealer for RMA number; return product with proof of purchase and completed repair form.
Technical Support:
- Email: service@advanio.com.tw
- Website: [https://www.advanio.com.tw](https://www.advanio.com.tw)
- Response Time: Within 2 business days.
- Information Required: Model number, serial number, firmware version, host configuration, and detailed problem description.
Maintenance:
- Periodically inspect connectors and DIN‑rail contacts for oxidation or loose fittings.
- Ensure adequate ventilation and avoid exposure to condensation or corrosive gases.
- Firmware updates and configuration utilities available from Advanio website.
Software Tools:
- Advanio Setup Utility (ARIO Utility): Windows‑based configuration and diagnostic software for Wolf series modules.
- Mobile Access: Advanio Cloud App (Android/iOS) for remote monitoring and sales support.
### Summary
The Advanio G‑M1D061‑M is an industrial‑grade Ethernet‑to‑RS‑232 device port housed in a robust metal enclosure, designed for seamless integration of serial equipment into modern Ethernet‑based control networks. As part of the Wolf Series, it inherits modularity, high isolation, and reliability features proven in Advanio’s remote I/O systems. With a wide 10 – 60 V DC input range, 3 kV isolation, and compliance with CE and FCC standards, the G‑M1D061‑M is ideal for industrial automation, process control, and data acquisition applications requiring secure and stable serial‑to‑Ethernet communication.
Its combination of hot‑swappable design, EEPROM‑based auto‑configuration, and five‑year warranty ensures long‑term serviceability and minimal downtime in mission‑critical environments.
### 1. Product Overview
Product Name: Device Port Ethernet to RS232 (Metal Case)
Model Number: G‑M1D061‑M
Article Number: G‑M1D061‑M
Series: Wolf Series Industrial I/O and Communication Modules
Manufacturer: Advanio Technology Co., Ltd.
Manufacturer Background:
Advanio Technology Co., Ltd. is a Taiwan‑based industrial automation and IoT hardware manufacturer specializing in advanced input/output (I/O) and communication modules for Industry 4.0 applications. Founded by engineers with over 20 years of field experience, Advanio designs rugged, serviceable, and intelligent data‑acquisition devices for harsh industrial environments. The company’s product portfolio includes RS‑485, CAN, Ethernet, EtherCAT, PROFINET, Modbus/TCP, and wireless (Bluetooth, Wi‑Fi, 3G/4G) connectivity solutions, as well as industrial computing platforms.
### 2. Key Features
- Ethernet‑to‑RS232 Conversion: Provides transparent communication between Ethernet networks and serial RS‑232 devices.
- Industrial‑Grade Metal Housing: Rugged metal enclosure ensures mechanical durability and electromagnetic shielding for factory‑floor environments.
- Wolf Series Architecture: Shares the same modular design principles as Advanio’s Wolf RS‑485 remote I/O modules—compact, DIN‑rail mountable, and hot‑swappable.
- Wide Power Input Range: Operates from +10 to +60 V DC, supporting 12 V, 24 V, 36 V, and 48 V industrial supplies.
- High Isolation Protection: 3 kV DC isolation between power, communication, and I/O circuits prevents noise‑induced damage.
- Hot‑Swap and Auto‑Configuration: Non‑volatile EEPROM retains configuration; modules can be replaced without rewiring.
- Programmable Power‑On and Safety Values: Ensures controlled startup and fail‑safe operation during communication loss.
- EMC‑Certified Design: Complies with CE and FCC Part 15 Class A requirements for EMI/EMS immunity.
- Extended Environmental Range: Operates from –25 °C to +70 °C, humidity 5 – 95 % RH.
- Five‑Year Warranty: Long‑term reliability assurance for industrial deployments.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Power Supply | +10 V DC to +60 V DC (reverse‑polarity protected) |
| Power Consumption | Approx. 1.6 W @ 24 V DC |
| Communication Interface | Ethernet 10/100 Base‑T to RS‑232 serial port |
| Protocol Support | Modbus RTU / Modbus TCP / transparent serial tunneling |
| Isolation Voltage | 3,000 V DC between power, communication, and I/O |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –30 °C to +75 °C |
| Humidity | 5 % to 95 % RH (non‑condensing) |
| Enclosure Material | Aluminum alloy, anodized finish |
| Mounting | DIN‑rail 35 mm or wall‑mount |
| Dimensions (typ.) | 47.2 mm (W) × 115 mm (H) × 130 mm (D) |
| Weight | Approx. 0.9 kg |
| Connectors | Plug‑in terminal blocks (#16 – 30 AWG) for power and RS‑232; RJ‑45 for Ethernet |
| Communication Distance (RS‑232) | Up to 15 m (standard RS‑232 limit) |
| Communication Distance (Ethernet) | 100 m per segment (standard Cat 5e/6 cabling) |
| Baud Rate (Serial) | 1200 – 115.2 kbps selectable |
| Indicators | Power LED, System LED, Communication LED (status and diagnostic patterns) |
| Watchdog Timers | Hardware (module) 1.6 s fixed; software (system) programmable (0 – 25.5 s) |
| Isolation Type | Photo‑coupler and DC/DC converter isolation |
| Compliance | CE EMC, FCC Part 15 Class A, RoHS Directive 2011/65/EU |
### 4. Functionality
Operating Principle:
The G‑M1D061‑M functions as a serial‑device server, bridging Ethernet‑based control systems (PLCs, SCADA, DCS, or industrial PCs) with legacy RS‑232 equipment such as sensors, controllers, or instrumentation. It encapsulates serial data into TCP/IP packets for network transmission and converts incoming Ethernet data back to RS‑232 signaling.
Use Cases and Applications:
- Remote data acquisition and process monitoring
- Industrial automation and machine control
- Energy management and power‑distribution monitoring
- Building automation and HVAC control
- Laboratory instrumentation and test systems
- Security and access‑control integration
- Supervisory control and data logging
Compatibility:
- Fully interoperable with Modbus RTU and Modbus TCP protocols.
- Compatible with Advanio Wolf RS‑485 I/O modules, EtherCAT and PROFINET networks via gateway integration.
- Supports standard Ethernet infrastructure (switches, routers, industrial hubs).
### 5. Components & Accessories
Included Items:
- G‑M1D061‑M module (metal housing)
- Detachable DIN‑rail mounting base and plastic grounding tab
- 14‑pin signal connector for RS‑232 and power terminals
- Quick Start Guide and documentation
Optional Accessories:
- G‑M1E001: RS‑232 to RS‑485 converter (isolated)
- G‑M1A001: USB to RS‑485 converter
- G‑M1F001: RS‑485 repeater (for extended distance > 1200 m)
- DIN‑rail grounding tabs (metal or plastic for frame ground isolation)
- Wall‑mount brackets and screw kits
Connectors:
- Power Input: 2‑pin terminal (+VS, GND)
- Frame Ground (F.G.): dedicated terminal or DIN‑rail ground tab
- RS‑232 Port: DB9 male or terminal block depending on configuration
- Ethernet Port: RJ‑45 10/100 Base‑T auto‑negotiation
### 6. Installation & Setup
Requirements:
- DC power supply 10 – 60 V DC (≤ 5 V ripple Vpp)
- Host PC or controller with Ethernet or RS‑232 port
- Standard Cat 5e/6 Ethernet cable and shielded serial cable
Mounting Options:
1. DIN‑Rail Mounting: Attach the detachable base to a DIN 35 mm rail; modules can be docked side‑by‑side using 14‑pin connecting arrays for power and communication bus continuity.
2. Wall Mounting: Secure the base to a flat surface using screw holes provided; insert the module vertically.
Grounding:
- When mounted on metal DIN rails, use the rail as frame ground (F.G.).
- For non‑conductive mounting, connect F.G. via the power connector terminal.
- Plastic grounding tabs may be used to isolate modules from noisy grounds.
Configuration:
- Node Address: Set via two rotary switches (0x01 – 0xF7).
- Baud Rate and Parity: Configurable through Advanio Setup Utility or Modbus register 44107 (0x100A).
- Factory Reset: Press INIT button for 3 seconds to restore defaults (9600 bps, N, 8, 1).
- EEPROM Backup: Stores all parameters; can be transferred to replacement modules for instant recovery.
Network Topologies:
- Daisy Chain: Modules connected serially via RS‑485 bus or Ethernet switch.
- Star: Multiple modules connected to central switch or repeater.
- Hybrid/Random: Combination for complex plant layouts.
### 7. Performance & Capabilities
- Communication Speed: Serial 1200 – 115.2 kbps; Ethernet 10/100 Mbps auto‑negotiation.
- Transmission Distance: RS‑232 ≤ 15 m; Ethernet ≤ 100 m per segment (extendable via switches or repeaters).
- Throughput: Optimized for low‑latency Modbus RTU/TCP transactions.
- Isolation Protection: 3 kV DC galvanic isolation between power, communication, and I/O.
- Watchdog Recovery: Hardware watchdog resets module after 1.6 s of fault; software watchdog monitors host polling intervals and forces safe state on timeout.
- Reliability Features: Reverse‑polarity protection, over‑voltage protection, and surge suppression on communication lines.
- Environmental Endurance: Designed for continuous operation in harsh industrial conditions with high EMI and temperature fluctuations.
- Maintenance Efficiency: LED diagnostics and rotary switch addressing allow on‑site service without a computer.
Limitations:
- Single RS‑232 channel per module.
- Ethernet segment limited to 100 m without repeater.
- Configuration changes require power cycle to take effect.
### 8. Standards & Compliance
- Electrical Safety: Designed for industrial control equipment per EN 61010‑1.
- EMC Compliance: Tested for EMI and EMS per EN 55032 and EN 61000‑6‑2.
- FCC Compliance: Part 15 Class A — device may not cause harmful interference and must accept any received interference.
- CE Marking: Conforms to European EMC Directive 2014/30/EU.
- RoHS Compliance: Meets Directive 2011/65/EU for hazardous substance restriction.
- Quality Assurance: All modules undergo functional burn‑in and environmental stress testing prior to shipment.
### 9. Additional Information
Warranty:
- Duration: 5 years from date of original purchase.
- Coverage: Free repair or replacement for defects in materials or workmanship.
- Exclusions: Damage from improper installation, modification, or misuse by non‑certified personnel.
- Procedure: Contact authorized dealer for RMA number; return product with proof of purchase and completed repair form.
Technical Support:
- Email: service@advanio.com.tw
- Website: [https://www.advanio.com.tw](https://www.advanio.com.tw)
- Response Time: Within 2 business days.
- Information Required: Model number, serial number, firmware version, host configuration, and detailed problem description.
Maintenance:
- Periodically inspect connectors and DIN‑rail contacts for oxidation or loose fittings.
- Ensure adequate ventilation and avoid exposure to condensation or corrosive gases.
- Firmware updates and configuration utilities available from Advanio website.
Software Tools:
- Advanio Setup Utility (ARIO Utility): Windows‑based configuration and diagnostic software for Wolf series modules.
- Mobile Access: Advanio Cloud App (Android/iOS) for remote monitoring and sales support.
### Summary
The Advanio G‑M1D061‑M is an industrial‑grade Ethernet‑to‑RS‑232 device port housed in a robust metal enclosure, designed for seamless integration of serial equipment into modern Ethernet‑based control networks. As part of the Wolf Series, it inherits modularity, high isolation, and reliability features proven in Advanio’s remote I/O systems. With a wide 10 – 60 V DC input range, 3 kV isolation, and compliance with CE and FCC standards, the G‑M1D061‑M is ideal for industrial automation, process control, and data acquisition applications requiring secure and stable serial‑to‑Ethernet communication.
Its combination of hot‑swappable design, EEPROM‑based auto‑configuration, and five‑year warranty ensures long‑term serviceability and minimal downtime in mission‑critical environments.
-
Datasheeet_Advanio_Wolf_W-M1B501_W-M1B502.pdf
PDF Catalog
-
Advanio_Catalog_Wolf_Series_General.pdf
PDF Catalog
No accessories available.
