Name: IP66 10.1-inch Jetson Orin AI panel PC with six GMSL2 camera ports.
Brand: Neousys Technology
SKU: NRU-171V-PPC

INDUSTRIELLE LÖSUNG?

Entdecken Sie Embedded-, Kommunikations- und Automatisierungslösungen für Ihre Anwendung.

IP66 10.1-inch Jetson Orin AI panel PC with six GMSL2 camera ports.

NRU-171V-PPC

IP66 10.1-inch Jetson Orin AI panel PC with six GMSL2 camera ports.

Angebot anfragen

Hersteller Neousys Technology
Kategorie: Industrial Computer
Der NRU-171V-PPC ist ein lüfterloser, IP66-geschützter 10,1-Zoll-AI-Panel-PC für mobile und semiausgesetzte Edge-Anwendungen. NVIDIA Jetson Orin NX oder Orin Nano stellt bis zu 100 TOPS Rechenleistung bereit. Sechs wasserdichte GMSL2-Anschlüsse unterstützen ausgewählte Fahrzeugkameras. Das helle Touchdisplay bietet 1920 x 1200 Pixel, 1000 cd/m² und Bedienung mit einem Finger bei Nässe. GbE, CAN FD, RS-232, USB, GPS-PPS, Mobilfunk- und NVMe-Erweiterungen sowie 8 bis 35 VDC mit Zündsteuerung erleichtern die Integration in Fahrzeuge und Maschinen.

IP66 fanless 10.1-inch AI panel PC powered by NVIDIA Jetson Orin NX or Orin Nano, with up to 100 TOPS. It provides six waterproof GMSL2 FAKRA Z camera ports, one GbE port, CAN FD, RS-232, two USB 2.0 ports, an isolated GPS PPS input and 8–35 VDC input with ignition control. The 1920 x 1200 touchscreen offers 1000 cd/m² brightness. Expansion includes mini-PCIe, M.2 B-key and M.2 NVMe.

Processor Platform NVIDIA Jetson Orin NX or Jetson Orin Nano SoM
Software Platform NVIDIA JetPack bundled
Maximum AI Performance Up to 100 TOPS
Resolution 1920 x 1200 touchscreen
Orin NX Memory Options 16 GB or 8 GB LPDDR5 at 3200 MHz
Orin Nano Memory Options 8 GB or 4 GB LPDDR5 at 2133 MHz
Display Size 10.1 inch
Display Resolution 1920 x 1200 pixels
Display Brightness 1000 cd/m²
Contrast Ratio 1000:1
Touch Operation Single-finger touch when wet; optical bonding; anti-glare and anti-fingerprint glass
GMSL2 Camera Ports 6 ports
GMSL2 Connector Waterproof FAKRA Z
Supported Camera Configurations 6x AC-IMX390 at 2 MP/30 FPS; 6x AC-ISX031 at 3 MP/30 FPS; 4x AC-IMX490 at 5 MP/30 FPS
Gigabit Ethernet Ports 1 port
Ethernet Connector M12 X-coded 8-pin
CAN Interface 1x CAN FD
Serial Port 1x RS-232
USB Ports 2x USB 2.0; 1x USB Type-C for flashing and OTG
Isolated GPS PPS Input 1 input
Digital I/O 1x isolated GPS PPS input
Mini PCI Express Socket 1x full-size mini-PCIe, PCIe plus USB 2.0
Cellular Module Socket 1x M.2 3042/3052 B-key with USB 3.2 Gen 1 and USB 2.0; dual micro-SIM
NVMe Storage Socket 1x M.2 2242 M-key, PCIe Gen3 x1
DC Input Range 8 to 35 VDC
Ignition Power Control Built-in
Dimensions 257 x 65 x 176 mm
Weight 3.8 kg
Mounting VESA 75
Form Factor 10.1-inch rugged panel PC; VESA 75 mount
Connector 6x waterproof FAKRA Z GMSL2; 1x M12 X-coded GbE; M12 A-coded power, USB, RS-232/CAN FD/PPS; USB Type-C
Dimensions 257 x 65 x 176 mm (W x D x H)
Ingress Protection IP66
Operating Temperature -25 to 60 °C
Storage Temperature -40 to 85 °C
Relative Humidity 10 to 90, non-condensing %
Vibration Compliance MIL-STD-810H Method 514.8 Category 4
Shock Compliance MIL-STD-810H Method 516.8 Procedure I
Operating Temperature -25°C to 60°C fanless; full CPU/GPU stress: -25°C to 60°C with 25W TDP mode
Bus Interface GbE; CAN FD; RS-232; USB 2.0; USB Type-C; mini-PCIe; M.2
Key Features NVIDIA Jetson Orin NX or Orin Nano; up to 100 TOPS; IP66 waterproof and dustproof; 10.1-inch 1000 cd/m² touchscreen; 6x GMSL2 camera ports; fanless operation; CAN FD and RS-232; ignition power control; cellular and NVMe expansion
Accessories PA-60W-OW, PA-160W-OW, AC-ISX031-H60, AC-ISX031-H120, AC-ISX031-H190, AC-IMX390-H60, AC-IMX390-H120, AC-IMX390-H190, AC-IMX490-H30, AC-IMX490-H60, AC-IMX490-H120, Cblkit-NRU-171V-PPC, Cbl-FAKRA-ZFM-ZFM-12M, Cbl-M12X8M-RJ45F-100CM, Cbl-M12A8M-2U2TA-180CM1, Cbl-M12A8M-2DB9M_OW2-180CM1
