IP66 fanless Jetson AGX Orin 64GB computer with 4x PoE+ GbE and 1x 10GbE.
IP66 fanless Jetson AGX Orin 64GB computer with 4x PoE+ GbE and 1x 10GbE. IP66 fanless Jetson AGX Orin 64GB computer with 4x PoE+ GbE and 1x 10GbE. IP66 fanless Jetson AGX Orin 64GB computer with 4x PoE+ GbE and 1x 10GbE.

NRU-240S-AWP-JAO64

IP66 fanless Jetson AGX Orin 64GB computer with 4x PoE+ GbE and 1x 10GbE.
Angebot anfragen
  • Hersteller Neousys Technology
  • Kategorie: Industrial Computer
  • Der NRU-240S-AWP-JAO64 bietet NVIDIA Jetson AGX Orin Rechenleistung mit 64 GB LPDDR5 in einem lüfterlosen, wasserdichten IP66-System. Vier M12-basierte PoE+-Gigabit-Ethernet-Ports versorgen und verbinden Industrie- oder IP-Kameras, während ein zusätzlicher 10GbE-Anschluss schnelle Datenkommunikation ermöglicht. USB-C kombiniert USB 3.2 mit einem DisplayPort-Ausgang bis 4K bei 60 Hz. Für Fahrzeug- und Maschinenanbindung stehen isolierte CAN-, RS-485-, DI- und DO-Schnittstellen sowie RS-232 bereit. NVMe, zwei SATA-Plätze und Erweiterungssockel ergänzen den 8-bis-48-V-DC-Eingang mit integrierter Zündsteuerung.
IP66 fanless edge AI computer with NVIDIA Jetson AGX Orin, 64GB LPDDR5, 64GB eMMC, four PoE+ Gigabit Ethernet ports, one 10GBASE-T port, USB 3.2/DisplayPort, isolated CAN and serial I/O, NVMe and SATA expansion, and 8V to 48V DC input with ignition control. Supports non-throttling operation at 55°C in JAO64 MAXN mode and has no GMSL2 camera ports.
  • Processor Module NVIDIA Jetson AGX Orin
  • System Memory 64 GB LPDDR5
  • Onboard eMMC 64 GB
  • GMSL2 Camera Ports 0 ports
  • PoE+ Gigabit Ethernet Ports 4 ports
  • PoE Power Budget 100 W
  • 10 Gigabit Ethernet Ports 1 port
  • DC Input Range 8 to 48 V DC
  • Ingress Protection IP66
  • Form Factor IP66 rugged fanless computer; wall mount
  • Connector 5x M12 X-coded Ethernet; M12 A-coded I/O; M12 L-coded power; waterproof USB-C
  • Dimensions 225 x 194 x 88.5 mm without rubber feet; 225 x 194 x 89.5 mm with rubber feet
  • Full-Function Operating Temperature -25 to 60 °C
  • Operating Temperature -25°C to 70°C without 10GbE transmission and PoE load; -25°C to 60°C with full function
  • MAXN Non-Throttling Temperature 55 °C
  • System Monitoring Controller Automotive-grade MCU
  • Key Features NVIDIA Jetson AGX Orin 64GB; IP66 waterproof and dustproof; fanless operation; 4x PoE+ GbE; 1x 10GBASE-T; 55°C non-throttling in JAO64 MAXN mode; isolated I/O; ignition control
  • Bus Interface PCIe Gen4 x2 NVMe; mini PCIe; USB 3.1/3.2; SATA
  • Digital I/O 1x isolated DI; 2x isolated DO; 2x isolated CAN 2.0; isolated RS-485; RS-232
  • Resolution DisplayPort up to 3840x2160 at 60 Hz
  • Accessories PA-160W-OW, PA-280W-CW6P-2P, Cblkit-FP-NRU-230V-AWP_NRU-240S-AWP, Cbl-TpCPlug-UTpCF-50CM, Cbl-M12A8M-2U2TA-180CM1, Cbl-M12A8M-2DB9M_OW2-180CM1, Cbl-M12X8M-RJ45F-100CM
