• CPU Intel Elkhart Lake Atom x6425E
• Processor Intel Elkhart Lake Atom x6425E quad-core 2.0/3.0 GHz 12W
• Ethernet Ports 3x 2.5GbE
• USB 3.1 Ports 2x USB 3.1 Gen1
• USB 3.1 Ports 2x USB 3.1 Gen1 (5 Gbps)
• USB 2.0 Ports 2x USB 2.0
• Form Factor Ultra-compact DIN-rail fanless rugged computer
• Dimensions 56 x 108 x 153 mm
• Weight 0.96 kg
• Mounting DIN-rail mount standard; Wall-mount optional
• Form Factor Ultra-compact DIN-rail fanless embedded computer
• Connector 3-pin terminal block DC input; DisplayPort; RJ-45; USB Type-A; DB9; 3.5 mm audio jack
• Dimensions 56 x 108 x 153 mm
• Operating Temperature -25 to 70 °C
• Storage Temperature -40 to 85 °C
• Humidity 10% to 90% non-condensing
• Vibration MIL-STD-810G, Method 514.7, Category 4
• Shock MIL-STD-810G, Method 516.7, Procedure I
• Operating Temperature -25°C to 70°C
• Graphics Integrated Intel UHD Graphics
• Maximum Memory 32 GB
• Memory Type DDR4-3200 SDRAM
• TPM fTPM 2.0
• Storage Interface 1x M.2 2280 SATA interface
• DC Input Range 8 to 35 VDC
• Power Connector 3-pin pluggable terminal block
• Ethernet Controller Intel I226-IT/I225-IT
• PoE Not listed
• Display Outputs 2x DisplayPort
• Maximum Display Resolution 4096 x 2160 @ 60Hz
• COM1 1x software-programmable RS-232/422/485
• COM2/3/4 3x 3-wire RS-232 or 1x RS-422/485 on COM2
• Audio Interface 1x 3.5 mm jack for mic-in and speaker-out
• M.2 E Key 1x M.2 2230 E key socket for WiFi, Google TPU or Movidius VPU module
• Expandable I/O 1x MezIO expansion port
• EMC CE/FCC Class A, according to EN 55032 and EN 55035
• Bus Interface 3x 2.5GbE Ethernet
• Analog Output 1x 3.5 mm audio jack for mic-in and speaker-out
• Key Features Intel Atom x6425E; fanless; 3x 2.5GbE; DIN-rail mount; ultra-compact
