IP69K fanless 2U edge AI computer with NVIDIA L4 and eight M12 Ethernet ports.

SEMIL-2048GC

IP69K fanless 2U edge AI computer with NVIDIA L4 and eight M12 Ethernet ports.

Angebot anfragen

Hersteller Neousys Technology
Kategorie: Industrial Computer
Der SEMIL-2048GC ist ein lüfterloser Edge-AI-Computer für besonders anspruchsvolle Einsatzbedingungen. Das IP69K-geschützte 2U-19-Zoll-Gehäuse aus korrosionsbeständigem Edelstahl und Aluminium widersteht Staub, Wasser, Stößen und Vibrationen. Eine NVIDIA L4 GPU arbeitet mit Intel Core Prozessoren der 14., 13. oder 12. Generation und bis zu 128 GB ECC- oder Non-ECC-DDR5. Acht robuste M12-Ethernet-Ports umfassen zwei 10GbE-, einen GbE-, einen 2.5GbE- und vier 2.5GbE-PoE+-Anschlüsse. CAN, USB, serielle I/O, 8–48 VDC und Zündsteuerung runden das System ab.

Extreme-rugged 2U 19-inch rack-mount computer with NVIDIA L4 GPU and Intel 14th/13th/12th Gen Core processor support. Features up to 128 GB ECC/non-ECC DDR5, eight M12 Ethernet ports including 2x 10GbE and 4x 2.5GbE PoE+, isolated CAN and serial interfaces, NVMe and SATA storage, 8–48 VDC input, IP69K protection and fanless operation from -40°C to 70°C with a 35 W CPU.

Supported Processor Generations Intel Core 14th, 13th and 12th Gen
Chipset Intel R680E
GPU NVIDIA L4
Maximum Memory 128 GB
Memory Type ECC/non-ECC DDR5-4800 SDRAM, two SODIMM slots
Ethernet Ports 2x 10GbE, 4x 2.5GbE PoE+, 1x GbE, 1x 2.5GbE
PoE+ Ports 4 ports
PoE Power Budget 100 W
CAN Bus Ports 2x isolated CAN 2.0 with SocketCAN support
Serial Ports 1x isolated 3-wire RS-232; 1x RS-422/485
USB Ports 2x USB 3.2 Gen1 Type-C; 2x USB 2.0
SATA Drive Support 2x internal 2.5-inch SATA HDD/SSD, RAID 0/1
NVMe Socket 1x M.2 2280 M key, PCIe Gen4 x4
Expansion Sockets 3x full-size mini PCIe; 1x M.2 B key
DC Input Range 8–48 VDC
Ignition Control Built-in
Dimensions 440 x 310 x 90.5 mm
Weight 12 kg
Form Factor 2U 19-inch rack-mount / wall-mount
Connector M12 X-coded Ethernet; M12 A-coded I/O; M12 L-coded power; USB Type-C
Dimensions 440 x 310 x 90.5 mm
Ingress Protection IP69K
Operating Temperature -40 to 70 with 35 W CPU; -40 to 60 in 65 W TDP mode °C
Vibration Compliance MIL-STD-810H 514.8C-VII, Category 4
Shock Compliance MIL-STD-810H 516.8 Procedure I
Operating Temperature -40°C to 70°C with 35 W CPU; -40°C to 60°C in 65 W TDP mode
Bus Interface 3x full-size mini PCIe; M.2 PCIe Gen4 x4; M.2 B key
Key Features IP69K waterproof construction;NVIDIA L4 GPU;fanless wide-temperature operation;8x Ethernet ports;2x 10GbE;4x 2.5GbE PoE+;ECC/non-ECC DDR5;2x isolated CAN 2.0;8–48 VDC input;MIL-STD-810H compliant
Accessories PA-280W-CW6P-2P, PA-600W-C4PY-4P, Cblkit-M12-SEMIL2008
