ACL-8112DG

ACL-8112DG - Adlink Technology Inc.

AT AD Card 100kS/s 12bit 16SE/8DI

PC Add-On Cards are devices that can be added to a personal computer to increase its functionality. A/D Cards are one type of add-on card that can be used to convert analog signals into digital signals. A/D Cards High Speed are designed to process these signals at high speed, and A/D High Speed ISA cards are specifically designed for use with the ISA bus. These cards can be used to capture and process audio, video, and other types of data..
332,00 €
incl. VAT 395,08 €

Description

  • 100kS/s 12bit 16SE/8DI AD card with AD774/±1,25/2,5/5/10V or 0-1,25/2,5/5/10V
  • with DC/DC converter
  • 2*12bit DA 0-5/10V 30µs
  • 16/16 DIO
  • IRQ3/5-7/9-12/15
  • 2 cascaded 16bit timer for pacer
  • 1 counter 16bit
  • 37pin D-type female and 2*20pin
  • 163*123mm
  • Adlink

Details

  • Width: 163 mm
  • Height: 123 mm
  • Weight: 0.9kg
  • Manufacturer: Adlink Technology Inc.
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8473 3020 000

Manuals

Downloads

Accessories
