EX9018-M - TOPSCCC
8 AD,16-bit, 10Hz,thermocouple, Modbus
Network Ethernet - Serial Over IP is an industrial device server that enables users to connect Modbus Modules and Modbus AD In. With this device, users can easily integrate Modbus Modules and Modbus AD In into their existing network, allowing for efficient communication and data exchange..
218,00 €
incl. VAT 259,42 €
incl. VAT 259,42 €
Description
- The EX9018-M Analog In 16 bit Modbus RTU module for thermocouple excels at use for temperature measurement with one of the sensors J
- K
- T
- E
- R
- S
- B or N or may be used to measure analogue voltages in the measuring ranges ±15mV/±50mV/±100mV/±500mV/±1V and ±2,5V or currents between ±20mA (with resistor 125Ohm)
- with a sampling rate of 10 Hz
- The Analog In RS485 module has open-loop detection and can be operated in a wide temperature range
- features: measure voltages in measuring ranges from ±15mV to ±2,5V
- support all popular thermocouple
- break-line detection
- output as RS485 interface
- Communicate via Modbus-RTU
- In- and Output galvanically isolated
- manual configuration or with supplied software
- power supply 10 - 30VDC
Details
- Width: 94.9 mm
- Height: 23 mm
- Depth: 144.3 mm
- Form factor: Box
- Manufacturer: TOPSCCC
- Country of Origin: Taiwan R.O.C.
- Customs code: 8517 6200 900
