Nuvo-5608VR - Neousys

Core i3/i5/i7 Skylake Fanless System Q170 10GbE 8PoE

The Nuvo-5000-Series is a line of industrial computers and embedded systems that are powered by Intel Core i7/i5/i3 Embedded processors. They offer high performance, reliability and low power consumption, making them ideal for a variety of industrial and embedded applications. These computers are designed to provide maximum performance while minimizing size and weight. They are also designed to withstand harsh environments and are suitable for a variety of industrial and embedded applications..

Description

Intel Core i3/i5/i7 Skylake fanless barebone system with Intel Q170 chipset
up to 32GB DDR4 SODIMM (2 slots)
AMT 11.0 and TPM 2.0 support
2* internal 3,5" SATA III HDD/SSD with RAID 0/1 support
1* Intel I219 and 9* Intel I210 GbE ports
with 8* PoE+ P.S.E. functionality compliant to IEEE802.3at for GbE ports (total power budget 120W)
Intel HD Graphics 530 with VGA/DVI-D/2*DisplayPort
4K2K support on DP ports
4* Mini-PCIe expansion slots (1* with front-accessible SIM card socket and 3* with internal SIM card socket)
4* USB 3.0 (via native XHCI controller) and 4* USB 2.0 ports
2* RS232/422/485 (software-programmable) and 1* RS232 ports
1* Mic in and 1* Speaker out
operating temperature -25°...+70°C (with mSATA/SSD) or -10°...+60°C (with 3,5''HDD)
vibration resistance up to 1Grms (5-500Hz 3 axes with SSD according to IEC60068-2-64)
shock resistance up to 30Grms (half-sine 11ms duration with SSD according to IEC60068-2-27)
power supply 8..35 VDC built in (120W AC/DC adapter optional)
240*225*98mm
3.5kg (including 2.5" HDD and 1* DDR3 SODIMM RAM)
