Nuvo-9002LP-UL - Neousys

Intel 14/13/12G rugged PC 2x2.5GbE,USB-C,MezIO,2.5" HDD,UL

We provide rugged embedded computers powered by Intel® 14th/13th/12th-Gen Core™ processors with up to 24 cores and 32 threads. Our Nuvo-9000 series delivers exceptional computational performance with DDR5 memory support, PCIe Gen4 NVMe storage, and versatile I/O including up to 6× 2.5GbE ports, USB 3.2 type-C, and triple independent display outputs. Designed for harsh industrial environments, the systems feature fanless operation from -25°C to 70°C, patented expansion Cassettes for PCIe/PCI add-on cards, and the flexible MezIO® interface for function expansion. With proven reliability, high performance, and extensive connectivity, our rugged embedded platforms are optimized for applications ranging from industrial automation to in-vehicle computing and machine vision..

Description

  • Intel® 14th/13th/12th Gen Core™ i9/i7/i5/i3 rugged embedded computer with LGA1700 socket (65 W/35 W TDP) and Intel® Q670E chipset. Supports up to 64 GB DDR5-4800 via 2× DIMM slots. Integrated Intel® UHD Graphics 770/730
  • cassette-less low-profile design
  • 1× hot-swappable 2.5″ HDD/SSD tray (7 mm) + 1× internal 2.5″ SATA (RAID 0/1)
  • 1× 2.5GbE (Intel I226/I225) + 1× GbE (Intel I219-LM) LAN ports
  • 1× USB 3.2 Gen2x2 Type-C
  • 4× USB 3.2 Gen2
  • 2× USB 3.2 Gen1
  • 2× USB 2.0
  • VGA
  • DisplayPort
  • 2× RS-232/422/485
  • 2× RS-232
  • audio I/O
  • 1× M.2 2280 Gen4 NVMe slot
  • 1× mini-PCIe
  • 1× M.2 B-Key with SIM
  • MezIO® expansion
  • remote power control
  • rugged -25 °C…+70 °C fanless operation
  • 8–48 V DC input
  • wall-mount chassis 240×225×79 mm
  • 3.36 kg
  • UL certified
  • Neousys.

Details

  • Width: 240 mm
  • Height: 79 mm
  • Depth: 225 mm
  • Net weight: 3.36 kg
  • Weight: 3.36kg
  • Manufacturer: Neousys
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8471 5000 000
