PCI-8136 - Adlink Technology Inc.

6-CH Quadrature Encoder and Multi-function IO Card

This is a set of PC add-on cards for motion control and EtherCAT PCI applications. The set includes DIO cards, motion control plug-in cards, and motion control/EtherCAT PCI cards. The cards are designed to provide reliable and precise motion control for a wide range of applications. They offer a variety of features including high speed data transfer, motion control, and EtherCAT support. They are easy to install and configure, making them an ideal choice for motion control applications..

Description

  • PCI bus card with 6-CH 32-bit industrial counter for three kinds of differential pulse trains
  • including A/B phase
  • CW/CCW
  • and Pulse/Direction
  • 6-CH differential pulse generators up to 500 kHz
  • 6-CH 32-bit position compare with interrupt function
  • 6-CH 16-bit ±10V analog output
  • 6-CH 12-bit 133 kHz analog single-ended input
  • 19-CH opto-isolated DI
  • 7-CH open collector DO
  • Digital I/Os and counters are 2500 VRMS isolated
  • 100pin SCSI II connector
  • Adlink

Details

  • Connectors: SCSI-II-100f
  • Weight: 0.9kg
  • Manufacturer: Adlink Technology Inc.
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8473 3020 000

Data Sheets

Manuals

Downloads

Accessories

  • DIN-100M15
    100pin SCSI-II servo driver panel 1,5m cable
  • DIN-100M30
    100pin SCSI-II servo driver panel 3m cable
