Name: Jetson Orin NX edge AI computer with 16GB memory and six USB 3.2 camera ports.
Brand: Neousys Technology
SKU: NRU-156-JON16

INDUSTRIELLE LÖSUNG?

Entdecken Sie Embedded-, Kommunikations- und Automatisierungslösungen für Ihre Anwendung.

NRU-156-JON16

Jetson Orin NX edge AI computer with 16GB memory and six USB 3.2 camera ports.

Angebot anfragen

Hersteller Neousys Technology
Kategorie: Industrial Computer
Der NRU-156-JON16 verbindet NVIDIA Jetson Orin NX mit 16 GB LPDDR5 und einer 128-GB-NVMe inklusive vorinstalliertem Systemabbild. Sechs verschraubbare USB-3.2-Ports – zwei Gen2 mit 10 Gbit/s und vier Gen1 mit 5 Gbit/s – stellen die volle Bandbreite für industrielle USB3-Kameras bereit. Weitere Schnittstellen sind USB 2.0, Gigabit Ethernet, DisplayPort, RS-232 und isoliertes RS-485. Dank des flachen Kühlkörpers lässt sich die Wärme an ein Metallgehäuse ableiten. Unter den spezifizierten Montagebedingungen arbeitet der kompakte Rechner lüfterlos von -25 bis 60 °C.

Compact fanless edge AI computer with NVIDIA Jetson Orin NX, 16GB LPDDR5, 128GB NVMe and a pre-installed system image. Camera connectivity comprises two USB 3.2 Gen2 ports and four USB 3.2 Gen1 ports, all with screw locks. It also provides two USB 2.0 ports, one GbE port, DisplayPort, RS-232 and isolated RS-485. The flattop heatsink supports conduction-cooled cabinet installation. Dimensions are 116 x 171 x 27 mm; fanless operating temperature is -25°C to 60°C under the specified mounting conditions.

Processor Platform NVIDIA Jetson Orin NX with NVIDIA Ampere GPU and ARM Cortex CPU
Installed Memory 16 GB LPDDR5
Series AI Inference Performance Up to 100 TOPS
Key Features NVIDIA Jetson Orin NX; 16GB LPDDR5; up to 100 TOPS series performance; 128GB NVMe; 6x screw-lock USB 3.2; full-bandwidth camera connectivity; flattop conduction heatsink; fanless operation; JetPack support
Included NVMe Capacity 128 GB
NVMe Interface M.2 2242 M-key, PCIe Gen4 x2
USB 3.2 Gen2 Ports 2 ports
USB 3.2 Gen1 Ports 4 ports
USB 2.0 Ports 2 ports
Ethernet Ports 1 GbE port
Serial Interfaces 1x RS-232; 1x isolated RS-485
Maximum Display Resolution 3840 x 2160 at 60Hz
Dimensions 116 x 171 x 27 mm
Weight 1.0 kg
Form Factor Compact fanless wall-mount computer with flattop conduction heatsink
Connector 2x USB 3.2 Gen2, 4x USB 3.2 Gen1, 2x USB 2.0, 1x GbE, DisplayPort, RS-232, isolated RS-485, micro USB OTG, 12V DC input
Dimensions 116 x 171 x 27 mm
Operating Temperature -25 to 60 °C
Storage Temperature -40 to 85 °C
Operating Temperature -25°C to 60°C fanless at 20W TDP with specified heat-conduction mounting
DC Input 12 V DC
Bus Interface M.2 2242 M-key, PCIe Gen4 x2
Resolution DisplayPort up to 3840 x 2160 at 60Hz
Accessories PA-60W-OW
