Name: Jetson Orin NX edge AI computer with 16GB memory and six USB 3.2 camera ports.
Brand: Neousys Technology
SKU: NRU-156-JON16

INDUSTRIAL SOLUTION?

Discover embedded, communication and automation solutions tailored to your application.

NRU-156-JON16

Jetson Orin NX edge AI computer with 16GB memory and six USB 3.2 camera ports.

Request a quote

Manufacturer Neousys Technology
Category: Industrial Computer
The NRU-156-JON16 combines NVIDIA Jetson Orin NX with 16GB LPDDR5 and a 128GB NVMe drive containing a pre-installed system image. Six screw-lock USB 3.2 ports—two 10Gbps Gen2 and four 5Gbps Gen1 connections—provide full bandwidth for industrial USB3 cameras. Additional interfaces include USB 2.0, Gigabit Ethernet, DisplayPort, RS-232 and isolated RS-485. Its flattop heatsink conducts heat to a metal enclosure, allowing the compact computer to operate fanlessly from -25°C to 60°C under the specified mounting conditions.

Compact fanless edge AI computer with NVIDIA Jetson Orin NX, 16GB LPDDR5, 128GB NVMe and a pre-installed system image. Camera connectivity comprises two USB 3.2 Gen2 ports and four USB 3.2 Gen1 ports, all with screw locks. It also provides two USB 2.0 ports, one GbE port, DisplayPort, RS-232 and isolated RS-485. The flattop heatsink supports conduction-cooled cabinet installation. Dimensions are 116 x 171 x 27 mm; fanless operating temperature is -25°C to 60°C under the specified mounting conditions.

Processor Platform NVIDIA Jetson Orin NX with NVIDIA Ampere GPU and ARM Cortex CPU
Installed Memory 16 GB LPDDR5
Series AI Inference Performance Up to 100 TOPS
Key Features NVIDIA Jetson Orin NX; 16GB LPDDR5; up to 100 TOPS series performance; 128GB NVMe; 6x screw-lock USB 3.2; full-bandwidth camera connectivity; flattop conduction heatsink; fanless operation; JetPack support
Included NVMe Capacity 128 GB
NVMe Interface M.2 2242 M-key, PCIe Gen4 x2
USB 3.2 Gen2 Ports 2 ports
USB 3.2 Gen1 Ports 4 ports
USB 2.0 Ports 2 ports
Ethernet Ports 1 GbE port
Serial Interfaces 1x RS-232; 1x isolated RS-485
Maximum Display Resolution 3840 x 2160 at 60Hz
Dimensions 116 x 171 x 27 mm
Weight 1.0 kg
Form Factor Compact fanless wall-mount computer with flattop conduction heatsink
Connector 2x USB 3.2 Gen2, 4x USB 3.2 Gen1, 2x USB 2.0, 1x GbE, DisplayPort, RS-232, isolated RS-485, micro USB OTG, 12V DC input
Dimensions 116 x 171 x 27 mm
Operating Temperature -25 to 60 °C
Storage Temperature -40 to 85 °C
Operating Temperature -25°C to 60°C fanless at 20W TDP with specified heat-conduction mounting
DC Input 12 V DC
Bus Interface M.2 2242 M-key, PCIe Gen4 x2
Resolution DisplayPort up to 3840 x 2160 at 60Hz
Accessories PA-60W-OW
