AHM-6104 - Aplex

10.4" Industrial Fanless Touch Panel Computer SGA 800*600

Industrial Computers, Embedded Systems, and HMI are key components of industrial automation that provide a platform for data acquisition, control, and monitoring. Industrial Computers provide an industrial-grade computing platform for data acquisition, control, and monitoring. Embedded Systems are specialized computers designed for specific tasks and can be used in a variety of industrial applications. HMI (Human Machine Interface) provides a user interface for interacting with the system and allows for remote monitoring and control..

Description

  • 10.4" SGA 800*600 Industrial Fanless Touch Panel Computer
  • CPU VIA Eden 400MHz
  • 256MB SDRAM up to 512GB
  • with resistive touch screen
  • space for 2,5"HDD and 1*CF slot
  • 1*RS232 1*RS232/422/485 1*10/100LAN 2*USB2.0 1*parallel
  • SVGA 800*600 400cd/qm 130┬░ 40.000hrs
  • black alloy bezel with metal housing
  • VESA 75
  • supply voltage 11..28VDC
  • cut out 301*227mm
  • 317*243*74mm
  • ~4,3kg
  • Aplex

Details

  • Width: 317 mm
  • Height: 243 mm
  • Depth: 74 mm
  • Net weight: 4.3 kg
  • Weight: 4.3kg
  • Manufacturer: Aplex
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8471 4100 000
