DIO-6464L-PE - Contec
PCIe isolated 64/64 chan DO Card
PC Add-On Cards are specialized cards that can be used to add additional features and functionality to a computer. DIO Cards are a type of PC Add-On Card that provide digital input and output (DIO) capabilities. DIO Isolated cards are specialized DIO cards that provide isolation from the computer and other connected devices. DIO Isolated PCIe cards are PCIe-based DIO cards that provide isolation from the computer and other connected devices..
430,00 €
incl. VAT 511,70 €
incl. VAT 511,70 €
Description
- PCIe opto-isolated 64 channel digital input and 64 channel digital output card (negative logic: 16 outputs share a positive common)
- out 35VDC 100mA (per channel)
- response time 200µs
- In: 12-24VDC
- 16 interrupt signals combine to one IRQ signal as INTA
- 2*100-pin female HDRA
- 169*110mm
- Contec
Details
- Width: 176 mm
- Height: 107 mm
- Depth: 19 mm
- Weight: 0.8kg
- Manufacturer: Contec
- Country of Origin: Japan
- Customs code: 8473 3020 000
