ECS-7800-PoE - Vecow Co., Ltd

Ivy-Bridge i3/i5/i7 Fanless Barebone System 4*PoE GbE

We provide a wide range of industrial computers and embedded systems, from Core i7/i5/i3 Embedded to the Nuvo-2000-Series and others. Our products are designed to meet the needs of the most demanding applications, offering reliable performance and robustness. We also offer a variety of customization options to meet your specific requirements..

Description

  • Core i3/i5/i7 Ivy Bridge fanless barebone system QM77 with 4* 802.3at PoE+ ports
  • up to 16GB DDR3 SODIMM (2 slots)
  • 2* 2,5" SATA III HDD/SSD
  • 1* SATA II for horizontal SATA DOM
  • 2* mSATA II
  • 1* Intel 82574L 1* Intel 82579LM GbE ports
  • 4* Intel 82574L IEEE802.3at PoE+ GbE ports
  • Intel GMA HD 4000 graphics with VGA/DVI-D/2*DP/LVDS connectors
  • 2* Mini-PCIe expansion slots (1* with SIM card socket)
  • 4* USB 3.0 2* USB 2.0 and 2* internal USB 2.0 ports
  • 1* external CFast slot
  • 3*RS232 and 1*RS232/422/485 ports
  • Infineon SLB9635 TPM (optional)
  • rugged -25°..+70°C fanless operation
  • power supply 6..36 VDC built in (120W AC/DC adapter optional) with LT4356 80VDC surge protection
  • 260*215*79mm
  • 3kg
  • Vecow

Details

  • Width: 260 mm
  • Height: 175 mm
  • Depth: 79 mm
  • Net weight: 3 kg
  • Weight: 3kg
  • Manufacturer: Vecow Co., Ltd
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8471 5000 000
