Comprehensive Product Summary – ORing IAP‑W522+ Industrial Wireless Access Point

---

### 1. Product Overview

Product Name: IAP‑W522+
Model: IAP‑W522+
Series: IAP‑W520+/W522+ Series
Article Number: IAP‑W522+
Manufacturer: ORing Industrial Networking Corp.
Manufacturer Website: [www.oring-networking.com](http://www.oring-networking.com)
Contact:
- Tel: +886‑2‑2218‑1066
- Fax: +886‑2‑2218‑1014
- Email: support@oring-networking.com
Headquarters: 3F., No.542‑2, Zhongzheng Rd., Xindian Dist., New Taipei City 23148, Taiwan (R.O.C.)

The ORing IAP‑W522+ is a ruggedized, industrial‑grade outdoor wireless access point designed for demanding environments requiring reliable 5 GHz IEEE 802.11 a/n connectivity. It supports multiple operating modes—Access Point (AP), Client, Repeater, and AP‑Client—allowing flexible deployment in industrial, transportation, and outdoor wireless infrastructures. The unit features an IP67‑rated waterproof and dust‑tight enclosure, dual 10/100Base‑T(X) Ethernet ports (one with IEEE 802.3af PoE PD support), and two external N‑type antenna connectors for extended range and performance.

---

### 2. Key Features

- Industrial‑grade 5 GHz WLAN: IEEE 802.11 a/n compliant, supporting OFDM modulation with data rates up to 300 Mbps (air link) and throughput exceeding 80 Mbps.
- High Power Output: 500 mW (27 dBm) transmit power for long‑distance wireless links.
- Multiple Operating Modes: Configurable as Access Point, Client, AP‑Client, Bridge, or Repeater.
- Fast Roaming: X‑Roaming capability with handover latency under 100 ms for mobile applications.
- Dual Ethernet Ports: Two 10/100Base‑T(X) RJ‑45 ports with auto‑negotiation; one port supports IEEE 802.3af PoE PD input.
- External Antenna Support: Two N‑type connectors for flexible antenna selection and extended coverage.
- Rugged Construction: IP67‑rated aluminum enclosure for outdoor and industrial use; resistant to dust, water, and harsh weather.
- Wide Temperature Range: Operates from ‑20 °C to +70 °C; storage from ‑40 °C to +85 °C.
- Comprehensive Security: WEP (64/128‑bit), WPA/WPA2, WPA‑PSK/WPA2‑PSK (TKIP/AES), and 802.1X authentication.
- Advanced Management: Web‑based GUI with HTTPS, SNMP, Syslog, and e‑mail event notifications.
- Flexible Mounting: Wall or pole mounting kits included for outdoor installation.
- Power over Ethernet: Fully compliant with IEEE 802.3af PoE PD standard, simplifying installation and reducing cabling costs.
- Industrial Protocol Support: ARP, BOOTP, DHCP, DNS, HTTPS, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, and STP (IEEE 802.1D).
- LED Indicators: Power, Ethernet link/activity, and WLAN signal strength indicators for quick status monitoring.

---

### 3. Technical Specifications

Wireless Interface
- Standards: IEEE 802.11 a/n
- Frequency Bands:
- FCC (US): 5.180 – 5.240 GHz and 5.745 – 5.825 GHz (9 channels)
- CE/ETSI (EU): 5.180 – 5.240 GHz (4 channels)
- Modulation:
- 802.11a: OFDM with BPSK, QPSK, 16‑QAM, 64‑QAM
- 802.11n: BPSK, QPSK, 16‑QAM, 64‑QAM
- Data Rates:
- 802.11a: up to 54 Mbps
- 802.11n: up to 150 Mbps per stream (300 Mbps total)
- Transmit Power: 500 mW (27 dBm) maximum
- Receiver Sensitivity: ‑97 dBm typical
- Antenna Connectors: 2 × N‑type female connectors (external antennas not included)
- Antenna Type: External N‑type (user‑selectable)

Ethernet Interface
- Ports: 2 × 10/100Base‑T(X) RJ‑45 (auto MDI/MDIX)
- PoE: IEEE 802.3af PD compliant (48 V DC input via PoE port)
- Pin Assignment (RJ‑45):
1 – TD+, 2 – TD‑, 3 – RD+, 6 – RD‑

Power
- Input Voltage: 48 V DC via PoE port
- Power Consumption: 9 W typical

Physical Characteristics
- Enclosure: IP67‑rated aluminum housing
- Dimensions: 162 (W) × 101.5 (D) × 47.3 (H) mm (6.38 × 4.0 × 1.86 in.)
- Weight: Approx. 790 g
- Mounting: Wall or pole mount (kits included)

Environmental
- Operating Temperature: ‑20 °C to +70 °C (‑4 °F to +158 °F)
- Storage Temperature: ‑40 °C to +85 °C (‑40 °F to +185 °F)
- Humidity: 5 % – 95 % RH, non‑condensing

Regulatory & Safety
- EMI: FCC Part 15, CISPR (EN55022) Class A
- EMS: EN61000‑4‑2 (ESD), EN61000‑4‑3 (RS), EN61000‑4‑4 (EFT), EN61000‑4‑5 (Surge), EN61000‑4‑6 (CS), EN61000‑4‑8, EN61000‑4‑11
- Shock: IEC 60068‑2‑27
- Vibration: IEC 60068‑2‑6
- Free Fall: IEC 60068‑2‑32
- Safety: EN60950‑1

Warranty: 3 years standard (5 years for selected ORing products)

---

### 4. Functionality

The IAP‑W522+ functions as a high‑performance wireless bridge or access point for industrial and outdoor networks. It supports multiple operation modes:

- Access Point (AP): Provides wireless connectivity to multiple clients.
- Client (Station): Connects to another AP to extend network coverage.
- AP‑Client (Bridge): Combines AP and client functions for point‑to‑point or point‑to‑multipoint bridging.
- Repeater: Extends wireless range by relaying signals between APs.

Use Cases & Applications:
- Outdoor wireless backhaul links between buildings or industrial sites.
- Wireless connectivity for surveillance systems, transportation depots, or remote monitoring stations.
- Integration into SCADA, automation, or logistics networks requiring robust wireless communication.
- Mobile or vehicular applications requiring fast roaming (< 100 ms).

Compatibility:
- Compatible with standard IEEE 802.11 a/n devices.
- Supports secure management via HTTPS, SNMP, and Syslog.
- Works with ORing’s OpenVision management utility for centralized monitoring.

---

### 5. Components & Accessories

Package Contents:
- 1 × IAP‑W522+ Access Point
- 1 × CD (documentation and utilities)
- 2 × N‑type antenna rubber seals (for antenna connectors)
- 2 × RJ‑45 rubber seals (for Ethernet ports)
- 2 × Pole‑mount steel band straps
- 1 × Quick Installation Guide (QIG)

Optional Accessories:
- External N‑type antennas (various gain options)
- PoE injector (IEEE 802.3af compliant)
- Wall‑mount screws and anchors (standard hardware)

Connectors:
- 2 × RJ‑45 Ethernet ports (1 × PoE PD, 1 × LAN)
- 2 × N‑type female antenna connectors
- 1 × Reset button (recessed, screw‑protected)

---

### 6. Installation & Setup

Mounting Options:
- Wall Mount: Use the provided screw holes on the enclosure edges; leave ~2 mm clearance for sliding installation.
- Pole Mount: Use the included adjustable steel straps; thread through mounting holes and tighten around the pole.

Power & Wiring:
- Power supplied via PoE (48 V DC) through the PoE port.
- Ensure RJ‑45 rubber seals are installed for outdoor waterproofing.
- Verify the Power LED (PWR) illuminates after connection.

Reset Procedure:
- Remove protective screw cap.
- Press and hold the reset button for 5 seconds to restore factory defaults.

Initial Configuration:
1. Connect a PC to the LAN port using a CAT 5/5e cable.
2. Set PC IP to same subnet as default device IP (192.168.10.2).
3. Access the web interface via browser: `http://192.168.10.2`.
4. Default credentials: Username: admin  |  Password: admin.
5. Configure SSID, security, and network parameters as required.

Safety Notes:
- Maintain at least 20 cm (7.9 in.) separation between antenna and personnel.
- Do not operate near unshielded blasting caps or explosive environments.
- Keep enclosure sealed; do not remove waterproof casing.

---

### 7. Performance & Capabilities

- Wireless Throughput: > 80 Mbps real throughput under optimal conditions.
- Coverage Range: Up to several kilometers (dependent on antenna gain and environment).
- Roaming Performance: X‑Roaming < 100 ms for seamless handover.
- Transmit Power: 27 dBm (adjustable).
- Receiver Sensitivity: ‑97 dBm for robust signal reception.
- QoS Support: WMM (Wi‑Fi Multimedia) for prioritizing voice, video, and data traffic.
- Network Diagnostics: Built‑in Ping, Traceroute, and Nslookup utilities.
- System Monitoring: Real‑time graphs for CPU load, traffic, wireless signal, and connections.
- Firmware Management: Web‑based upgrade with “Keep Settings” option; backup/restore configuration support.
- Limitations: Operates exclusively in 5 GHz band; not compatible with 2.4 GHz clients.

---

### 8. Standards & Compliance

Wireless Standards: IEEE 802.11 a/n
Ethernet Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3af (PoE PD)
Network Protocols: ARP, BOOTP, DHCP, DNS, HTTPS, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, STP (IEEE 802.1D)

Regulatory Compliance:
- FCC Statement: Complies with Part 15 of FCC Rules; operation subject to non‑interference conditions.
- RF Exposure: Meets FCC/IC exposure limits for uncontrolled environments; maintain 20 cm minimum distance.
- Industry Canada (IC): Complies with RSS‑standards; Class B digital apparatus per ICES‑003.
- CE/ETSI: Conforms to European EMC and safety directives.
- Environmental Tests: IEC 60068‑2‑27 (Shock), IEC 60068‑2‑6 (Vibration), IEC 60068‑2‑32 (Free Fall).
- Safety: EN60950‑1 certified for electrical safety.
- EMC Immunity: EN61000‑4‑2/3/4/5/6/8/11 compliant.

Operational Restrictions:
- 5.15 – 5.25 GHz band limited to indoor use (per FCC).
- Antenna gain must not exceed regulatory EIRP limits.

---

### 9. Additional Information

Warranty & Support:
- Standard 3‑year limited warranty covering defects in materials and workmanship.
- Extended 5‑year warranty available for select ORing products.
- Warranty excludes damage from misuse, unauthorized modification, or improper installation.
- Technical support available via email and online resources.

Maintenance:
- Periodically inspect antenna connectors and seals for corrosion or moisture ingress.
- Keep firmware updated via ORing’s official website to ensure optimal performance and security.
- Backup configuration files before performing firmware upgrades or resets.

Firmware & Software Updates:
- Firmware upgrades available through ORing’s support portal.
- Web‑based interface allows backup/restore and “Keep Settings” during upgrade.
- Supports HTTPS for secure management sessions.

Documentation & Tools:
- User Manual (Version 1.0, November 2014)
- Quick Installation Guide (QIG)
- ORing OpenVision management software (optional centralized monitoring)

---

### Summary

The ORing IAP‑W522+ is a high‑reliability, industrial‑grade 5 GHz wireless access point engineered for outdoor and harsh environments. Its IP67‑rated enclosure, dual Ethernet ports with PoE, and flexible operating modes make it ideal for industrial automation, transportation, and remote connectivity applications. With robust security, advanced management, and compliance with global standards, the IAP‑W522+ delivers stable, high‑performance wireless networking for mission‑critical deployments.
