IMG-110T - Planet

Isolated Port Modbus-/Serial-Ethernet Gateway

Network Ethernet - Serial Over IP and Modbus Gateways are technologies used to connect devices and systems to a network. These technologies allow for the transmission of data between devices over a network, and enable the integration of different systems and devices. They are commonly used in industrial automation, manufacturing, and other commercial applications..


  • Modbus TCP to 1*Modbus RTU/ASCII gateway
  • supports transparent Serial-Ethernet conversion
  • 1* RS232/485 serial ports with 5 screw connectors
  • Modbus gateway modes: Slave RTU/Slave ASCII/Master RTU/Master ASCII
  • Serial-Ethernet gateway modes: TCP server/TCP client
  • 300bps up to 1115,2kbps data rate on serial port
  • 1*10/100Mb Ethernet port
  • supports Telnet/web/serial console configuration (Windows configuration utility included)
  • -40..75°C operating temperature
  • DIN-rail mounting
  • 9...48VDC power input
  • ~1,25W@9VDC
  • ~238gr
  • 69*100*22mm
  • Planet


  • Width: 69 mm
  • Height: 100 mm
  • Depth: 22 mm
  • Net weight: 0.238 kg
  • Weight: 0.7kg
  • Form factor: Box
  • Manufacturer: Planet
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8517 6200 900
