Matrix-504 - Artila

ARM-9 400MHz 64RAM Web Serv. 1LAN 4*RS232/485 2*USB 5*DIO SD

ARM-based Embedded Linux / WinCE box computer and intelligent IoT gateways.
200,00 €
incl. VAT 238,00 €

Description

  • ARM-9 ATMEL AT91SAM9G20
  • 400MHz based Industrial Linux Computer
  • web server Linux 2.6.29 pre-built
  • RAM 64MB and NAND Flash Memory 128MB
  • microSD card slot (16GB SDHC max.)
  • 3* RS232/485 1* RS232/422/485 high speed ports
  • 2 additional USB 2.0 12Mbps host ports
  • one 10/100 Ethernet port
  • 5 programmable GP IO channels
  • SSL and SSH 1.0/2.0 etc.
  • upward compatible to Matrix-500 (microSD slot instead of SD)
  • fanless DIN rail mountable metal case
  • all flash based architecture 16/32/64MB Linux kernel 2.6.x
  • GNU C/C++ tool chain for Linux/Windows environment
  • JAVA accelerator
  • 9..48VDC
  • 300mA@12VDC 3W
  • -10°..60°C operation temperature range
  • 78*108*24mm
  • Artila

Details

  • Width: 78 mm
  • Height: 108 mm
  • Depth: 24 mm
  • Weight: 0.85kg
  • Manufacturer: Artila
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8471 5000 000
