Nuvo-6023 - Neousys

Core i3/i5/i7 H110 Fanless System PCIe*16 2*PCIe*4 2*PCI

This company specializes in industrial computers and embedded systems, offering a wide range of Core i7/i5/i3 Embedded solutions, including the Nuvo-6000/7000/8000-Series. Their products are designed to provide reliable and cost-effective solutions for industrial automation and control applications. With their advanced technology and superior customer service, they are committed to providing the best possible solutions for their customers..

Description

  • Intel Core 6th-Gen i3/i5/i7 LGA1151 CPU Skylake fanless barbone system with Intel H110 chipset
  • 1*PCIe*16 (16 lanes) 1*PCIe*4 (2 lanes) 1*PCIe*4 (1 lane) 2*PCI slot
  • up to 16GB DDR4 SODIMM (1 socket)
  • 3*ports 2,5" SATA III HDD/SSD
  • 1*full-size mSATA
  • 1* Intel I219-LM and 1* Intel I210-IT GbE ports
  • Intel HD Graphics 530/510 with 2*DVI-D/2 2*DVI/HDMI
  • 4* USB 3.0
  • 2* RS232/422/485 (software-programmable) and 2*RS232 ports
  • 1* Speaker out
  • operating temperature -25°...+60°C
  • vibration resistance up to 5Grms (5-500Hz 3 axes with SSD according to IEC60068-2-64)
  • shock resistance up to 50Grms (half-sine 11ms duration with SSD according to IEC60068-2-27)
  • power supply 12 VDC built in (120W AC/DC adapter optional)
  • 184*225*174mm
  • 3,5kg
  • Neousys

Details

  • Width: 184 mm
  • Height: 225 mm
  • Depth: 174 mm
  • Net weight: 3.5 kg
  • Weight: 4kg
  • Manufacturer: Neousys
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8471 5000 000

Data Sheets

Manuals

Accessories

  • Nuvo-PA-160W
    160W AC/DC Power Adapter for Nuvo-1300af/3005 PoE models
  • Nuvo-PA-120W
    120W AC/DC Power Adapter for Nuvo-3000 series
