Comprehensive Product Summary – CONTEC PI‑64L(PC) Opto‑Isolated 64‑Channel Digital Input AT Card
### 1. Product Overview
Product Name: Opto‑Isolated 64‑Channel Digital Input AT Card
Model: PI‑64L(PC)
Series: PI‑L Series (Digital Input Interface Boards)
Article Number: PI‑64L(PC)
Manufacturer: CONTEC Co., Ltd. (Japan)
Product Category: Industrial Automation / Measurement and Control / Digital I/O Interface Boards
Bus Type: ISA AT Bus (PC/AT compatible)
The CONTEC PI‑64L(PC) is a high‑density, opto‑isolated digital input interface card designed for PC/AT‑compatible systems. It provides 64 independent optically isolated input channels for reliable signal acquisition in electrically noisy industrial environments. The board is part of CONTEC’s long‑standing PI‑L series, which includes a range of digital input and output interface boards for various bus architectures (ISA, PCI, CompactPCI, USB, and PC Card).
### 2. Key Features
- 64 Opto‑Isolated Digital Inputs:
Provides 64 independent input channels, each isolated via high‑quality opto‑couplers to protect the host system from voltage surges, ground loops, and electrical noise.
- Wide Input Voltage Range:
Accepts 12–24 V DC input signals, suitable for industrial sensors, switches, and control devices.
- High Isolation Voltage:
Isolation withstands up to 5 kV between the PC logic and external input circuits, ensuring robust protection against transient voltages.
- Input Resistance:
Each input channel includes a 2 kΩ resistor for current limiting and signal conditioning.
- Multiple Interrupt Lines:
Supports up to four interrupt request (IRQ) lines selectable from IRQ 3–7, 9–12, 14, 15, allowing flexible interrupt‑driven input monitoring.
- Low Power Consumption:
Operates from the PC’s +5 V DC supply with a maximum current draw of 100 mA, minimizing system power load.
- High Noise Immunity:
Opto‑coupler isolation and robust circuit design provide excellent noise resistance, ideal for factory automation and process control.
- Standard Industrial Connector:
Equipped with a 96‑pin half‑pitch D‑type female connector for compact, high‑density wiring.
- Compact Form Factor:
Board dimensions of 160 mm × 122 mm (6.3 in × 4.8 in) fit standard ISA AT expansion slots.
- Software Support:
Compatible with CONTEC’s API‑PAC(W32) driver library for Windows and Linux, and supported by LabVIEW VI‑DAQ libraries for rapid application development.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Bus Interface | ISA AT Bus |
| Input Channels | 64 opto‑isolated inputs |
| Input Type | Opto‑coupler isolation (current sinking type) |
| Input Voltage Range | 12 V DC – 24 V DC (nominal) |
| Input Resistance | 2 kΩ per channel |
| Isolation Voltage | 5 kV (between input and logic circuits) |
| Input Current | Approx. 4 mA @ 12 V, 8 mA @ 24 V |
| Response Time | ≤ 1 ms typical |
| Interrupt Capability | 4 IRQ lines selectable (IRQ 3–7, 9–12, 14, 15) |
| I/O Address Range | Any 8‑byte or 16‑byte boundary (configurable) |
| Power Supply | +5 V DC from ISA bus |
| Power Consumption | Max. 100 mA |
| Isolation Method | Opto‑coupler (phototransistor type) |
| Maximum Wiring Distance | 50 m (typical, shielded cable recommended) |
| Connector Type | 96‑pin half‑pitch D‑type female |
| Board Dimensions | 160 mm (L) × 122 mm (H) |
| Operating Temperature | 0 °C – 50 °C (typical) |
| Storage Temperature | –10 °C – 60 °C |
| Humidity | 10 % – 90 % RH (non‑condensing) |
| Weight | Approx. 200 g |
### 4. Functionality
The PI‑64L(PC) functions as a digital input interface between field devices and a PC‑based control or monitoring system. Each input channel detects the ON/OFF state of external DC signals (12–24 V DC) and transfers the logic state to the host computer through the ISA bus.
Working Principle:
- External DC signals are applied to the input terminals.
- Each input passes through a current‑limiting resistor and drives an opto‑coupler.
- The opto‑coupler converts the electrical signal into an optical signal, isolating the external circuit from the PC logic.
- The optical signal is reconverted to a logic‑level signal within the board and read by the host system.
Typical Applications:
- Monitoring of limit switches, proximity sensors, and photoelectric sensors.
- Status acquisition from relays, contactors, and PLC outputs.
- Industrial process monitoring and alarm systems.
- Machine control and safety interlock systems.
- Data logging and event capture in manufacturing automation.
Compatibility:
- Designed for PC/AT‑compatible computers with ISA expansion slots.
- Compatible with CONTEC’s accessory cables and terminal blocks (e.g., PCB96P, PCB96PS, PCB96W, PCB96WS).
- Supported by CONTEC’s API‑PAC(W32) driver suite for Windows and Linux, and LabVIEW VI‑DAQ libraries.
### 5. Components & Accessories
Included Components:
- PI‑64L(PC) main board.
- User manual and setup documentation.
- Software driver package (API‑PAC(W32) for Windows, Linux driver modules).
Optional Accessories:
- Cables:
- PCB96P / PCB96PS – 96‑pin half‑pitch cable (male‑female).
- PCB96W / PCB96WS – 96‑pin half‑pitch cable with wiring terminals.
- PCA96P / PCA96PS – alternative cable assemblies.
- Terminal Blocks:
- EPD‑96, EPD‑37A, EPD‑37 – screw terminal boards for easy wiring.
- CM‑64(PC)E, CM‑32(PC)E – compact terminal modules.
- CCB‑96 – clamp‑type terminal block.
- Connector Sets:
- CN5‑H96F – 96‑pin half‑pitch connector set.
- Mounting Accessories:
- DIN‑rail or panel mounting kits for terminal blocks.
These accessories simplify wiring between the PI‑64L(PC) and external devices, ensuring reliable signal transmission and easy maintenance.
### 6. Installation & Setup
System Requirements:
- IBM PC/AT‑compatible computer with available ISA AT expansion slot.
- +5 V DC power supplied from the ISA bus.
- Operating system supported by CONTEC drivers (Windows 10/11, Linux kernel modules).
Installation Procedure:
1. Power off the host PC and remove the cover.
2. Insert the PI‑64L(PC) into an available ISA slot, ensuring proper alignment.
3. Secure the board with the bracket screw.
4. Connect the external I/O cable to the 96‑pin half‑pitch connector.
5. Attach the other end of the cable to a terminal block or field wiring interface.
6. Power on the PC and install the driver software.
Configuration:
- I/O address and interrupt lines are configured via software or jumper settings.
- IRQ lines can be assigned to IRQ 3–7, 9–12, 14, 15.
- Input logic polarity and filtering can be managed through the driver API.
- Verify operation using CONTEC’s diagnostic utility or LabVIEW VI‑DAQ test panels.
Mounting Options:
- Standard ISA bracket for internal PC installation.
- External wiring via 96‑pin half‑pitch cable to terminal block mounted on DIN rail or panel.
### 7. Performance & Capabilities
- Input Response Time: ≤ 1 ms typical, ensuring accurate detection of fast‑changing signals.
- Isolation Voltage: 5 kV between input and logic circuits, providing superior protection.
- Input Range: 12–24 V DC, compatible with most industrial sensors and controllers.
- Noise Immunity: Opto‑coupler isolation and internal filtering minimize false triggering.
- Interrupt Handling: Up to four simultaneous interrupt lines allow event‑driven data acquisition.
- Power Efficiency: Consumes only 100 mA at 5 V DC, suitable for multi‑board systems.
- Wiring Distance: Supports up to 50 m cable length with shielded twisted‑pair wiring.
- Reliability: Industrial‑grade components ensure long‑term stability and low maintenance.
Limitations:
- Input‑only device (no output channels).
- Requires external 12–24 V DC signal sources.
- ISA bus interface limits use to legacy or industrial PCs with ISA slots.
### 8. Standards & Compliance
- Bus Standard: ISA AT Bus (Industry Standard Architecture).
- Electrical Isolation: 5 kV opto‑coupler isolation compliant with industrial safety standards.
- EMC Compliance: Designed for industrial environments with high noise immunity.
- RoHS Compliance: Manufactured in accordance with RoHS environmental directives.
- CE Marking: Meets European safety and EMC requirements (when used with certified accessories).
- Software Standards:
- Windows API‑PAC(W32) driver conforms to Win32 API standards.
- Linux driver modules follow standard kernel device driver architecture.
- LabVIEW VI‑DAQ library compatible with National Instruments’ DAQ VI format.
### 9. Additional Information
Warranty:
Standard CONTEC limited warranty (typically one year) covering defects in materials and workmanship.
Technical Support:
- Online resources and driver downloads available at [www.contec.com](https://www.contec.com).
- Email and phone support for installation, configuration, and troubleshooting.
- Sample programs and API documentation included with driver package.
Maintenance:
- Periodic inspection of connectors and cables recommended.
- Keep board free from dust and moisture.
- No user‑serviceable internal components; return to CONTEC for repair if necessary.
Software Updates:
- Free driver and firmware updates available from CONTEC’s global portal.
- API‑PAC(W32) and Linux drivers updated regularly for OS compatibility.
- VI‑DAQ library updates ensure continued LabVIEW integration.
Related Products:
- PI‑32L(PC): 32‑channel opto‑isolated input AT card.
- PO‑64L(PC): 64‑channel opto‑isolated output AT card.
- PIO‑32/32L(PC): 32‑input/32‑output opto‑isolated I/O AT card.
- PI‑64L(PCI)H: PCI‑bus version of the same 64‑channel input board.
- PI‑64L(CPCI): CompactPCI version for embedded systems.
Applications Summary:
The PI‑64L(PC) is ideal for industrial automation, process control, and data acquisition systems requiring reliable, isolated digital input. It is widely used in manufacturing lines, test benches, and monitoring systems where electrical isolation and signal integrity are critical.
### Summary Table
| Attribute | Details |
|----------------|-------------|
| Model | PI‑64L(PC) |
| Manufacturer | CONTEC Co., Ltd. |
| Bus Type | ISA AT |
| Input Channels | 64 opto‑isolated |
| Input Voltage Range | 12–24 V DC |
| Input Resistance | 2 kΩ |
| Isolation Voltage | 5 kV |
| Response Time | ≤ 1 ms |
| Interrupt Lines | 4 (IRQ 3–7, 9–12, 14, 15) |
| Power Supply | +5 V DC (100 mA max) |
| Connector | 96‑pin half‑pitch D‑type female |
| Dimensions | 160 mm × 122 mm |
| Wiring Distance | 50 m max |
| Software Support | Windows, Linux, LabVIEW |
| Accessories | PCB96P/PS/W/WS cables, EPD‑96 terminal blocks |
| Compliance | CE, RoHS |
| Warranty | 1 year (typical) |
### Conclusion
The CONTEC PI‑64L(PC) is a robust, industrial‑grade digital input interface card offering 64 opto‑isolated channels for reliable signal acquisition in PC‑based control systems. Its 12–24 V DC input range, 5 kV isolation, and flexible interrupt configuration make it suitable for demanding automation and monitoring applications. With comprehensive driver support for Windows, Linux, and LabVIEW, and a wide range of compatible accessories, the PI‑64L(PC) provides a complete, scalable solution for integrating field‑level digital signals into PC‑based industrial control architectures.
### 1. Product Overview
Product Name: Opto‑Isolated 64‑Channel Digital Input AT Card
Model: PI‑64L(PC)
Series: PI‑L Series (Digital Input Interface Boards)
Article Number: PI‑64L(PC)
Manufacturer: CONTEC Co., Ltd. (Japan)
Product Category: Industrial Automation / Measurement and Control / Digital I/O Interface Boards
Bus Type: ISA AT Bus (PC/AT compatible)
The CONTEC PI‑64L(PC) is a high‑density, opto‑isolated digital input interface card designed for PC/AT‑compatible systems. It provides 64 independent optically isolated input channels for reliable signal acquisition in electrically noisy industrial environments. The board is part of CONTEC’s long‑standing PI‑L series, which includes a range of digital input and output interface boards for various bus architectures (ISA, PCI, CompactPCI, USB, and PC Card).
### 2. Key Features
- 64 Opto‑Isolated Digital Inputs:
Provides 64 independent input channels, each isolated via high‑quality opto‑couplers to protect the host system from voltage surges, ground loops, and electrical noise.
- Wide Input Voltage Range:
Accepts 12–24 V DC input signals, suitable for industrial sensors, switches, and control devices.
- High Isolation Voltage:
Isolation withstands up to 5 kV between the PC logic and external input circuits, ensuring robust protection against transient voltages.
- Input Resistance:
Each input channel includes a 2 kΩ resistor for current limiting and signal conditioning.
- Multiple Interrupt Lines:
Supports up to four interrupt request (IRQ) lines selectable from IRQ 3–7, 9–12, 14, 15, allowing flexible interrupt‑driven input monitoring.
- Low Power Consumption:
Operates from the PC’s +5 V DC supply with a maximum current draw of 100 mA, minimizing system power load.
- High Noise Immunity:
Opto‑coupler isolation and robust circuit design provide excellent noise resistance, ideal for factory automation and process control.
- Standard Industrial Connector:
Equipped with a 96‑pin half‑pitch D‑type female connector for compact, high‑density wiring.
- Compact Form Factor:
Board dimensions of 160 mm × 122 mm (6.3 in × 4.8 in) fit standard ISA AT expansion slots.
- Software Support:
Compatible with CONTEC’s API‑PAC(W32) driver library for Windows and Linux, and supported by LabVIEW VI‑DAQ libraries for rapid application development.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Bus Interface | ISA AT Bus |
| Input Channels | 64 opto‑isolated inputs |
| Input Type | Opto‑coupler isolation (current sinking type) |
| Input Voltage Range | 12 V DC – 24 V DC (nominal) |
| Input Resistance | 2 kΩ per channel |
| Isolation Voltage | 5 kV (between input and logic circuits) |
| Input Current | Approx. 4 mA @ 12 V, 8 mA @ 24 V |
| Response Time | ≤ 1 ms typical |
| Interrupt Capability | 4 IRQ lines selectable (IRQ 3–7, 9–12, 14, 15) |
| I/O Address Range | Any 8‑byte or 16‑byte boundary (configurable) |
| Power Supply | +5 V DC from ISA bus |
| Power Consumption | Max. 100 mA |
| Isolation Method | Opto‑coupler (phototransistor type) |
| Maximum Wiring Distance | 50 m (typical, shielded cable recommended) |
| Connector Type | 96‑pin half‑pitch D‑type female |
| Board Dimensions | 160 mm (L) × 122 mm (H) |
| Operating Temperature | 0 °C – 50 °C (typical) |
| Storage Temperature | –10 °C – 60 °C |
| Humidity | 10 % – 90 % RH (non‑condensing) |
| Weight | Approx. 200 g |
### 4. Functionality
The PI‑64L(PC) functions as a digital input interface between field devices and a PC‑based control or monitoring system. Each input channel detects the ON/OFF state of external DC signals (12–24 V DC) and transfers the logic state to the host computer through the ISA bus.
Working Principle:
- External DC signals are applied to the input terminals.
- Each input passes through a current‑limiting resistor and drives an opto‑coupler.
- The opto‑coupler converts the electrical signal into an optical signal, isolating the external circuit from the PC logic.
- The optical signal is reconverted to a logic‑level signal within the board and read by the host system.
Typical Applications:
- Monitoring of limit switches, proximity sensors, and photoelectric sensors.
- Status acquisition from relays, contactors, and PLC outputs.
- Industrial process monitoring and alarm systems.
- Machine control and safety interlock systems.
- Data logging and event capture in manufacturing automation.
Compatibility:
- Designed for PC/AT‑compatible computers with ISA expansion slots.
- Compatible with CONTEC’s accessory cables and terminal blocks (e.g., PCB96P, PCB96PS, PCB96W, PCB96WS).
- Supported by CONTEC’s API‑PAC(W32) driver suite for Windows and Linux, and LabVIEW VI‑DAQ libraries.
### 5. Components & Accessories
Included Components:
- PI‑64L(PC) main board.
- User manual and setup documentation.
- Software driver package (API‑PAC(W32) for Windows, Linux driver modules).
Optional Accessories:
- Cables:
- PCB96P / PCB96PS – 96‑pin half‑pitch cable (male‑female).
- PCB96W / PCB96WS – 96‑pin half‑pitch cable with wiring terminals.
- PCA96P / PCA96PS – alternative cable assemblies.
- Terminal Blocks:
- EPD‑96, EPD‑37A, EPD‑37 – screw terminal boards for easy wiring.
- CM‑64(PC)E, CM‑32(PC)E – compact terminal modules.
- CCB‑96 – clamp‑type terminal block.
- Connector Sets:
- CN5‑H96F – 96‑pin half‑pitch connector set.
- Mounting Accessories:
- DIN‑rail or panel mounting kits for terminal blocks.
These accessories simplify wiring between the PI‑64L(PC) and external devices, ensuring reliable signal transmission and easy maintenance.
### 6. Installation & Setup
System Requirements:
- IBM PC/AT‑compatible computer with available ISA AT expansion slot.
- +5 V DC power supplied from the ISA bus.
- Operating system supported by CONTEC drivers (Windows 10/11, Linux kernel modules).
Installation Procedure:
1. Power off the host PC and remove the cover.
2. Insert the PI‑64L(PC) into an available ISA slot, ensuring proper alignment.
3. Secure the board with the bracket screw.
4. Connect the external I/O cable to the 96‑pin half‑pitch connector.
5. Attach the other end of the cable to a terminal block or field wiring interface.
6. Power on the PC and install the driver software.
Configuration:
- I/O address and interrupt lines are configured via software or jumper settings.
- IRQ lines can be assigned to IRQ 3–7, 9–12, 14, 15.
- Input logic polarity and filtering can be managed through the driver API.
- Verify operation using CONTEC’s diagnostic utility or LabVIEW VI‑DAQ test panels.
Mounting Options:
- Standard ISA bracket for internal PC installation.
- External wiring via 96‑pin half‑pitch cable to terminal block mounted on DIN rail or panel.
### 7. Performance & Capabilities
- Input Response Time: ≤ 1 ms typical, ensuring accurate detection of fast‑changing signals.
- Isolation Voltage: 5 kV between input and logic circuits, providing superior protection.
- Input Range: 12–24 V DC, compatible with most industrial sensors and controllers.
- Noise Immunity: Opto‑coupler isolation and internal filtering minimize false triggering.
- Interrupt Handling: Up to four simultaneous interrupt lines allow event‑driven data acquisition.
- Power Efficiency: Consumes only 100 mA at 5 V DC, suitable for multi‑board systems.
- Wiring Distance: Supports up to 50 m cable length with shielded twisted‑pair wiring.
- Reliability: Industrial‑grade components ensure long‑term stability and low maintenance.
Limitations:
- Input‑only device (no output channels).
- Requires external 12–24 V DC signal sources.
- ISA bus interface limits use to legacy or industrial PCs with ISA slots.
### 8. Standards & Compliance
- Bus Standard: ISA AT Bus (Industry Standard Architecture).
- Electrical Isolation: 5 kV opto‑coupler isolation compliant with industrial safety standards.
- EMC Compliance: Designed for industrial environments with high noise immunity.
- RoHS Compliance: Manufactured in accordance with RoHS environmental directives.
- CE Marking: Meets European safety and EMC requirements (when used with certified accessories).
- Software Standards:
- Windows API‑PAC(W32) driver conforms to Win32 API standards.
- Linux driver modules follow standard kernel device driver architecture.
- LabVIEW VI‑DAQ library compatible with National Instruments’ DAQ VI format.
### 9. Additional Information
Warranty:
Standard CONTEC limited warranty (typically one year) covering defects in materials and workmanship.
Technical Support:
- Online resources and driver downloads available at [www.contec.com](https://www.contec.com).
- Email and phone support for installation, configuration, and troubleshooting.
- Sample programs and API documentation included with driver package.
Maintenance:
- Periodic inspection of connectors and cables recommended.
- Keep board free from dust and moisture.
- No user‑serviceable internal components; return to CONTEC for repair if necessary.
Software Updates:
- Free driver and firmware updates available from CONTEC’s global portal.
- API‑PAC(W32) and Linux drivers updated regularly for OS compatibility.
- VI‑DAQ library updates ensure continued LabVIEW integration.
Related Products:
- PI‑32L(PC): 32‑channel opto‑isolated input AT card.
- PO‑64L(PC): 64‑channel opto‑isolated output AT card.
- PIO‑32/32L(PC): 32‑input/32‑output opto‑isolated I/O AT card.
- PI‑64L(PCI)H: PCI‑bus version of the same 64‑channel input board.
- PI‑64L(CPCI): CompactPCI version for embedded systems.
Applications Summary:
The PI‑64L(PC) is ideal for industrial automation, process control, and data acquisition systems requiring reliable, isolated digital input. It is widely used in manufacturing lines, test benches, and monitoring systems where electrical isolation and signal integrity are critical.
### Summary Table
| Attribute | Details |
|----------------|-------------|
| Model | PI‑64L(PC) |
| Manufacturer | CONTEC Co., Ltd. |
| Bus Type | ISA AT |
| Input Channels | 64 opto‑isolated |
| Input Voltage Range | 12–24 V DC |
| Input Resistance | 2 kΩ |
| Isolation Voltage | 5 kV |
| Response Time | ≤ 1 ms |
| Interrupt Lines | 4 (IRQ 3–7, 9–12, 14, 15) |
| Power Supply | +5 V DC (100 mA max) |
| Connector | 96‑pin half‑pitch D‑type female |
| Dimensions | 160 mm × 122 mm |
| Wiring Distance | 50 m max |
| Software Support | Windows, Linux, LabVIEW |
| Accessories | PCB96P/PS/W/WS cables, EPD‑96 terminal blocks |
| Compliance | CE, RoHS |
| Warranty | 1 year (typical) |
### Conclusion
The CONTEC PI‑64L(PC) is a robust, industrial‑grade digital input interface card offering 64 opto‑isolated channels for reliable signal acquisition in PC‑based control systems. Its 12–24 V DC input range, 5 kV isolation, and flexible interrupt configuration make it suitable for demanding automation and monitoring applications. With comprehensive driver support for Windows, Linux, and LabVIEW, and a wide range of compatible accessories, the PI‑64L(PC) provides a complete, scalable solution for integrating field‑level digital signals into PC‑based industrial control architectures.
-
ContecCatalog2011-2012-en-H Digital IO.pdf
PDF Catalog
- DTP-64A - unversal screw terminal with HD D-sub 96f
- PCB96PS-0.5P - Cable 0,5m shielded with 96pin connector at each end
- PCB96PS-1.5P - Cable 1,5m shielded with 96pin connector at each end
- PCB96PS-3P - Cable 3m shielded with 96pin at each end
- PCB96PS-5P - Cable 5m shielded with 96pin at each end
