UTS211 - Rayon

USB 2.0 to 2*RS232 and Isolated 1*RS232 1*RS485/422 Conv.

This product is a set of PC Add-On Cards that provide communication with a variety of devices. It includes RS232, RS485, IEEE, Converter USB, RS232, RS485, RS422, TTY20mA, and USB RS232 Converter. These cards allow for easy communication between PCs and devices with different communication protocols. They are ideal for industrial applications and provide reliable and secure communication..

Description

  • USB 2.0 to 2*RS232 and isolated 1*RS232 and isolated 1*RS422/485 external converter module in metal case
  • for monitor or backup in one module
  • MOS chip MCS7840
  • FIFO 512Byte per serial port
  • connector: male DB9 (RS232 side) and USB B-type connector
  • LED control per channel
  • power requirement 5VDC 400mA USB bus powered
  • 90*150*27mm
  • Rayon

Details

  • Width: 90 mm
  • Height: 150 mm
  • Depth: 27 mm
  • Manufacturer: Rayon
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8473 3020 000

Data Sheets

Manuals

Downloads

Accessories

  • TB485
    DB9 Female to RS485 terminal screw block kit
