ARS-1200 - Vecow Co., Ltd

Fanless D525 Syst. 2*GbE 4*COM 8*DIO 1*PC/104+ 3*1394a 2*CAN

Industrial Computers and Embedded Systems powered by Atom are powerful solutions for businesses and industries. They are designed to be reliable, high performance and energy efficient. They provide a cost effective way to manage and control industrial processes, and can be used in a wide range of applications. Atom powered embedded systems are ideal for applications that require low power consumption and long term reliability..

Description

  • Intel Atom D525 fanless system (1M Cache
  • 1,8GHz
  • ICH8M)
  • customized chassis color or front panel
  • 2*GbE Intel WG82583V
  • dual display VGA DB15 DVI/HDMI
  • internal 2,5" SATA/SATA II for HDD/SSD
  • 2*DDR3 SO-DIMM up to 4GB
  • external accessible CFast port
  • 5*USB 2.0 ports
  • 3*serial 1*RS232 and 1*RS232/422/485 ports
  • programmable GPIO isolated 8*DI and 8*DO 24V
  • onboard EPROM
  • onboard USB dongle support
  • internal microphone and stereo headphone
  • OS support WinXP embedded WInXP or later Linux Fedora 11 Ubuntu 10.04 Cent OS 5.3
  • wall mount or DIN rail mount
  • rugged -20°..+70°C fanless operation
  • power supply 16..28 VDC built in
  • 186*147*79mm
  • ~2,1kg
  • Vecow

Details

  • Width: 230 mm
  • Height: 175 mm
  • Depth: 74 mm
  • Manufacturer: Vecow Co., Ltd
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8471 5000 000

Data Sheets

Accessories

  • EC-PWA60W
    60W AC/DC Power Adapter for EC-Systems
