Comprehensive Product Summary – TGAP‑6620⁺‑M12 Dual Wireless Access Point
### 1. Product Overview
Product Name: TGAP‑6620⁺‑M12
Article Number: TGAP‑6620⁺‑M12
Series: TGAP‑620(+)/6620(+)-M12 Industrial Wireless Access Point Series
Manufacturer: ORing Industrial Networking Corp.
Product Type: Dual‑band industrial wireless access point with dual Gigabit Ethernet M12 connectors and EN50155 compliance
Intended Use: Industrial and transportation environments, particularly rolling stock and railway applications requiring ruggedized wireless connectivity
The TGAP‑6620⁺‑M12 is a dual‑radio IEEE 802.11 a/b/g/n wireless access point designed for harsh industrial and transportation environments. It provides two independent Gigabit Ethernet interfaces with M12 connectors, dual power inputs, and full EN50155 certification for railway applications. The “+” variant supports Power‑over‑Ethernet (PoE PD) on the ETH2 port with 1 kV isolation.
### 2. Key Features
- Dual Wireless Modules: Two independent 802.11 a/b/g/n radios supporting simultaneous 2.4 GHz and 5 GHz operation.
- High‑Speed Connectivity: Wireless throughput up to 300 Mbps per radio using IEEE 802.11n MIMO technology.
- Industrial‑Grade Design: EN50155‑certified for railway and rolling stock use; resistant to vibration, shock, and temperature extremes.
- Rugged Connectors: M12 A‑coded connectors for Ethernet, DI/DO, relay, and console; M23 connector for dual DC power input.
- Flexible Operation Modes: Supports AP, Client, Bridge, and AP‑Client modes; dual AP/dual client operation for redundant or segmented networks.
- Secure Communication: WEP (64/128‑bit), WPA/WPA2 (AES/TKIP), WPA‑PSK (256‑bit), and 802.1X authentication.
- Management Interfaces: Web‑based GUI, HTTPS, SNMP, RADIUS, and ORing’s Open‑Vision Windows utility.
- Event Notification: Syslog, e‑mail alerts, SNMP traps, and relay output for fault indication.
- Redundant Power Inputs: Dual 12–48 V DC inputs via M23 connector for high reliability.
- PoE Support: ETH2 port supports IEEE 802.3af PoE PD with 1 kV isolation (TGAP‑6620⁺‑M12 only).
- Environmental Protection: IP40 metal enclosure, DIN‑rail or wall‑mountable, designed for ‑25 °C to 70 °C operation.
- Comprehensive LED Indicators: Power, Ethernet link/activity, WLAN link/activity, and fault relay status LEDs.
### 3. Technical Specifications
Wireless Standards: IEEE 802.11 a/b/g/n
Radio Type: DSSS, OFDM
Modulation:
- 802.11b: CCK, DQPSK, DBPSK
- 802.11g/a/n: OFDM with BPSK, QPSK, 16QAM, 64QAM
Frequency Bands:
- FCC (US): 2.412–2.462 GHz (11 ch), 5.180–5.240 GHz & 5.745–5.825 GHz (9 ch)
- CE/ETSI (EU): 2.412–2.472 GHz (13 ch), 5.180–5.240 GHz (4 ch)
Data Rates:
- 802.11b: 1/2/5.5/11 Mbps
- 802.11a/g: 6/9/12/18/24/36/48/54 Mbps
- 802.11n: up to 300 Mbps
Transmit Power:
- 802.11a: 12 dBm ± 1.5 dBm
- 802.11b: 18 dBm ± 1.5 dBm
- 802.11g: 15 dBm ± 1.5 dBm
- 802.11n HT20: 13 dBm ± 1.5 dBm @ 150 Mbps
- 802.11n HT40: 12 dBm ± 1.5 dBm @ 300 Mbps
Receiver Sensitivity:
- 802.11a/g: ‑68 dBm ± 2 dB @ 54 Mbps
- 802.11b: ‑82 dBm ± 2 dB @ 11 Mbps
- 802.11n HT20: ‑64 dBm ± 2 dB @ 150 Mbps
- 802.11n HT40: ‑60 dBm ± 2 dB @ 300 Mbps
Encryption & Security:
WEP (64/128‑bit), WPA/WPA2 (AES/TKIP), WPA‑PSK (256‑bit), 802.1X authentication, SSID broadcast enable/disable.
Ethernet Interfaces:
- 2 × 10/100/1000 Base‑T(X) M12 A‑coded connectors (Auto MDI/MDIX)
- Daisy‑chain topology supported
- Cable length up to 100 m (Cat 5/5e UTP)
Digital I/O:
- 4 × DI + 4 × DO via M12 (5‑pin A‑coding)
- Dry contact: ON = short to GND, OFF = open
- Wet contact: ON = 0–3 V DC, OFF = 10–30 V DC
Relay Output: 1 × M12 (5‑pin A‑coding), 1 A @ 24 V DC N.C.
Console Port: RS‑232 (M12 5‑pin A‑coding), 115200 bps, 8‑N‑1
Power Input: Dual 12–48 V DC via M23 5‑pin female connector
Power Consumption: ≈ 11 W (typical)
PoE: IEEE 802.3af PD on ETH2 (1 kV isolation)
Enclosure: Metal, IP40 protection
Dimensions: 125.6 (W) × 65 (D) × 196.1 (H) mm (4.94 × 2.55 × 7.72 in.)
Weight: ≈ 965 g
Environmental Ratings:
- Operating Temp: ‑25 °C to 70 °C (‑13 °F to 158 °F)
- Storage Temp: ‑40 °C to 85 °C (‑40 °F to 185 °F)
- Humidity: 5 % – 95 % non‑condensing
### 4. Functionality
The TGAP‑6620⁺‑M12 functions as a dual‑radio access point capable of operating in multiple modes:
- Access Point (AP): Central wireless hub for client devices.
- Client Mode: Acts as a wireless client bridging wired devices to WLAN.
- Bridge Mode: Connects two LAN segments wirelessly using WDS.
- AP‑Client Mode: Combines AP and client functions for flexible topologies.
- Dual AP/Dual Client: Independent operation of two radios for redundancy or separate networks.
Use Cases:
- Onboard train or bus Wi‑Fi systems
- Vehicle‑to‑ground communication in depots
- Industrial automation and SCADA wireless backbones
- Remote monitoring in harsh environments
Compatibility:
Supports standard Ethernet devices (PCs, routers, switches, PLCs) and interoperates with any IEEE 802.11 a/b/g/n compliant equipment.
### 5. Components & Accessories
Package Contents:
- TGAP‑6620⁺‑M12 unit
- 4 × 2.4 GHz/5 GHz antennas (reverse SMA)
- CD with documentation and utilities
- Quick Installation Guide
Optional Accessories:
- DIN‑rail mounting kit
- M12/M23 power and Ethernet cables
- External antennas or RF extension cables
Connectors:
- 2 × M12 8‑pin A‑coded (Ethernet)
- 1 × M12 5‑pin A‑coded (DI/DO)
- 1 × M12 5‑pin A‑coded (Relay)
- 1 × M12 5‑pin A‑coded (Console RS‑232)
- 1 × M23 5‑pin female (Power)
- 4 × Reverse SMA antenna connectors
### 6. Installation & Setup
Mounting Options:
- Wall Mount: Four keyhole slots for screw mounting; leave ~2 mm clearance for sliding fit.
- DIN‑Rail Mount: Optional bracket for panel or cabinet installation.
Power Connection:
1. Insert the M23 power cable into the connector.
2. Rotate the locking ring until secure.
3. Connect redundant power sources (V1+/V1‑, V2+/V2‑).
Grounding:
Connect the grounding pin on the power connector to a proper earth ground to minimize EMI.
Network Setup:
- Default IP: 192.168.10.1
- Default credentials: admin / admin
- Configuration via web browser (HTTP/HTTPS) or ORing Open‑Vision utility.
Reset Procedure:
Press and hold the reset button until the power LED flashes; release to restore factory defaults.
LED Indicators:
- PWR1/PWR2: Green – Power active
- ETH1/ETH2: Green – Link On; Blinking – Data Tx/Rx
- WLAN1/WLAN2: Green – Active; Blinking – Wireless traffic
- Fault: Red – Power or link failure
### 7. Performance & Capabilities
- Wireless Throughput: Up to 300 Mbps per radio (600 Mbps aggregate)
- Ethernet Speed: 2 × Gigabit ports (10/100/1000 Base‑T(X))
- Latency: Optimized for industrial real‑time communication
- Roaming: Supports X‑Roaming protocol for seamless handover
- Reliability: Dual power inputs and relay fault output for redundancy
- Efficiency: Typical power consumption ≈ 11 W
- Limitations: Indoor use only for 5.15–5.25 GHz band per FCC; requires 20 cm minimum separation from personnel.
### 8. Standards & Compliance
Electrical & Safety:
- EN60950‑1 (Safety of IT Equipment)
- EN50155 (Railway Applications – Electronic Equipment on Rolling Stock)
EMI/EMS Compliance:
- FCC Part 15 Class A
- CISPR 22 (EN55022) Class A
- EN50121‑3‑2, EN55011, EN50121‑4
- EN61000‑4‑2 (ESD)
- EN61000‑4‑3 (RS)
- EN61000‑4‑4 (EFT)
- EN61000‑4‑5 (Surge)
- EN61000‑4‑6 (CS)
- EN61000‑4‑8 (Magnetic Field)
- EN61000‑4‑11 (Dip/Interruption)
Mechanical & Environmental:
- IEC60068‑2‑6 (Vibration)
- IEC60068‑2‑27 (Shock)
- IEC60068‑2‑32 (Free Fall)
- EN61373 (Railway Shock and Vibration)
RF & Regional Compliance:
- FCC and Industry Canada RSS standards
- CE marking for Europe
- RF exposure compliant with uncontrolled environment limits
### 9. Additional Information
Warranty: 5 years limited hardware warranty
Maintenance: Periodic inspection of connectors and antenna tightness recommended; firmware updates available from ORing.
Firmware Upgrade: Via web interface; ensure model‑specific firmware is used.
Support & Contact:
- Manufacturer: ORing Industrial Networking Corp.
- Address: 3F., No. 542‑2, Zhongzheng Rd., Xindian Dist., New Taipei City 23148, Taiwan
- Tel: +886‑2‑2218‑1066 Fax: +886‑2‑2218‑1014
- Website: [www.oring‑networking.com](http://www.oring-networking.com)
- Email: support@oring‑networking.com
Software Management:
- Web GUI (HTTP/HTTPS)
- SNMP v1/v2c support
- ORing Open‑Vision Windows utility
- Syslog and event logging
- Firmware backup and restore functions
Safety Notes:
- Maintain ≥ 20 cm distance from antenna during operation.
- Avoid installation near explosive environments unless certified for such use.
- Ensure adequate airflow and avoid mechanical stress on mounting surfaces.
### Summary
The ORing TGAP‑6620⁺‑M12 is a robust, dual‑radio industrial wireless access point engineered for mission‑critical applications in transportation and heavy industry. With dual Gigabit M12 Ethernet ports, redundant 12–48 V DC power inputs, and EN50155 certification, it delivers high‑reliability wireless connectivity in vibration‑prone and temperature‑extreme environments. Its comprehensive security suite, flexible operation modes, and advanced management interfaces make it suitable for rolling stock networks, industrial automation, and remote monitoring systems requiring stable and secure wireless communication.
### 1. Product Overview
Product Name: TGAP‑6620⁺‑M12
Article Number: TGAP‑6620⁺‑M12
Series: TGAP‑620(+)/6620(+)-M12 Industrial Wireless Access Point Series
Manufacturer: ORing Industrial Networking Corp.
Product Type: Dual‑band industrial wireless access point with dual Gigabit Ethernet M12 connectors and EN50155 compliance
Intended Use: Industrial and transportation environments, particularly rolling stock and railway applications requiring ruggedized wireless connectivity
The TGAP‑6620⁺‑M12 is a dual‑radio IEEE 802.11 a/b/g/n wireless access point designed for harsh industrial and transportation environments. It provides two independent Gigabit Ethernet interfaces with M12 connectors, dual power inputs, and full EN50155 certification for railway applications. The “+” variant supports Power‑over‑Ethernet (PoE PD) on the ETH2 port with 1 kV isolation.
### 2. Key Features
- Dual Wireless Modules: Two independent 802.11 a/b/g/n radios supporting simultaneous 2.4 GHz and 5 GHz operation.
- High‑Speed Connectivity: Wireless throughput up to 300 Mbps per radio using IEEE 802.11n MIMO technology.
- Industrial‑Grade Design: EN50155‑certified for railway and rolling stock use; resistant to vibration, shock, and temperature extremes.
- Rugged Connectors: M12 A‑coded connectors for Ethernet, DI/DO, relay, and console; M23 connector for dual DC power input.
- Flexible Operation Modes: Supports AP, Client, Bridge, and AP‑Client modes; dual AP/dual client operation for redundant or segmented networks.
- Secure Communication: WEP (64/128‑bit), WPA/WPA2 (AES/TKIP), WPA‑PSK (256‑bit), and 802.1X authentication.
- Management Interfaces: Web‑based GUI, HTTPS, SNMP, RADIUS, and ORing’s Open‑Vision Windows utility.
- Event Notification: Syslog, e‑mail alerts, SNMP traps, and relay output for fault indication.
- Redundant Power Inputs: Dual 12–48 V DC inputs via M23 connector for high reliability.
- PoE Support: ETH2 port supports IEEE 802.3af PoE PD with 1 kV isolation (TGAP‑6620⁺‑M12 only).
- Environmental Protection: IP40 metal enclosure, DIN‑rail or wall‑mountable, designed for ‑25 °C to 70 °C operation.
- Comprehensive LED Indicators: Power, Ethernet link/activity, WLAN link/activity, and fault relay status LEDs.
### 3. Technical Specifications
Wireless Standards: IEEE 802.11 a/b/g/n
Radio Type: DSSS, OFDM
Modulation:
- 802.11b: CCK, DQPSK, DBPSK
- 802.11g/a/n: OFDM with BPSK, QPSK, 16QAM, 64QAM
Frequency Bands:
- FCC (US): 2.412–2.462 GHz (11 ch), 5.180–5.240 GHz & 5.745–5.825 GHz (9 ch)
- CE/ETSI (EU): 2.412–2.472 GHz (13 ch), 5.180–5.240 GHz (4 ch)
Data Rates:
- 802.11b: 1/2/5.5/11 Mbps
- 802.11a/g: 6/9/12/18/24/36/48/54 Mbps
- 802.11n: up to 300 Mbps
Transmit Power:
- 802.11a: 12 dBm ± 1.5 dBm
- 802.11b: 18 dBm ± 1.5 dBm
- 802.11g: 15 dBm ± 1.5 dBm
- 802.11n HT20: 13 dBm ± 1.5 dBm @ 150 Mbps
- 802.11n HT40: 12 dBm ± 1.5 dBm @ 300 Mbps
Receiver Sensitivity:
- 802.11a/g: ‑68 dBm ± 2 dB @ 54 Mbps
- 802.11b: ‑82 dBm ± 2 dB @ 11 Mbps
- 802.11n HT20: ‑64 dBm ± 2 dB @ 150 Mbps
- 802.11n HT40: ‑60 dBm ± 2 dB @ 300 Mbps
Encryption & Security:
WEP (64/128‑bit), WPA/WPA2 (AES/TKIP), WPA‑PSK (256‑bit), 802.1X authentication, SSID broadcast enable/disable.
Ethernet Interfaces:
- 2 × 10/100/1000 Base‑T(X) M12 A‑coded connectors (Auto MDI/MDIX)
- Daisy‑chain topology supported
- Cable length up to 100 m (Cat 5/5e UTP)
Digital I/O:
- 4 × DI + 4 × DO via M12 (5‑pin A‑coding)
- Dry contact: ON = short to GND, OFF = open
- Wet contact: ON = 0–3 V DC, OFF = 10–30 V DC
Relay Output: 1 × M12 (5‑pin A‑coding), 1 A @ 24 V DC N.C.
Console Port: RS‑232 (M12 5‑pin A‑coding), 115200 bps, 8‑N‑1
Power Input: Dual 12–48 V DC via M23 5‑pin female connector
Power Consumption: ≈ 11 W (typical)
PoE: IEEE 802.3af PD on ETH2 (1 kV isolation)
Enclosure: Metal, IP40 protection
Dimensions: 125.6 (W) × 65 (D) × 196.1 (H) mm (4.94 × 2.55 × 7.72 in.)
Weight: ≈ 965 g
Environmental Ratings:
- Operating Temp: ‑25 °C to 70 °C (‑13 °F to 158 °F)
- Storage Temp: ‑40 °C to 85 °C (‑40 °F to 185 °F)
- Humidity: 5 % – 95 % non‑condensing
### 4. Functionality
The TGAP‑6620⁺‑M12 functions as a dual‑radio access point capable of operating in multiple modes:
- Access Point (AP): Central wireless hub for client devices.
- Client Mode: Acts as a wireless client bridging wired devices to WLAN.
- Bridge Mode: Connects two LAN segments wirelessly using WDS.
- AP‑Client Mode: Combines AP and client functions for flexible topologies.
- Dual AP/Dual Client: Independent operation of two radios for redundancy or separate networks.
Use Cases:
- Onboard train or bus Wi‑Fi systems
- Vehicle‑to‑ground communication in depots
- Industrial automation and SCADA wireless backbones
- Remote monitoring in harsh environments
Compatibility:
Supports standard Ethernet devices (PCs, routers, switches, PLCs) and interoperates with any IEEE 802.11 a/b/g/n compliant equipment.
### 5. Components & Accessories
Package Contents:
- TGAP‑6620⁺‑M12 unit
- 4 × 2.4 GHz/5 GHz antennas (reverse SMA)
- CD with documentation and utilities
- Quick Installation Guide
Optional Accessories:
- DIN‑rail mounting kit
- M12/M23 power and Ethernet cables
- External antennas or RF extension cables
Connectors:
- 2 × M12 8‑pin A‑coded (Ethernet)
- 1 × M12 5‑pin A‑coded (DI/DO)
- 1 × M12 5‑pin A‑coded (Relay)
- 1 × M12 5‑pin A‑coded (Console RS‑232)
- 1 × M23 5‑pin female (Power)
- 4 × Reverse SMA antenna connectors
### 6. Installation & Setup
Mounting Options:
- Wall Mount: Four keyhole slots for screw mounting; leave ~2 mm clearance for sliding fit.
- DIN‑Rail Mount: Optional bracket for panel or cabinet installation.
Power Connection:
1. Insert the M23 power cable into the connector.
2. Rotate the locking ring until secure.
3. Connect redundant power sources (V1+/V1‑, V2+/V2‑).
Grounding:
Connect the grounding pin on the power connector to a proper earth ground to minimize EMI.
Network Setup:
- Default IP: 192.168.10.1
- Default credentials: admin / admin
- Configuration via web browser (HTTP/HTTPS) or ORing Open‑Vision utility.
Reset Procedure:
Press and hold the reset button until the power LED flashes; release to restore factory defaults.
LED Indicators:
- PWR1/PWR2: Green – Power active
- ETH1/ETH2: Green – Link On; Blinking – Data Tx/Rx
- WLAN1/WLAN2: Green – Active; Blinking – Wireless traffic
- Fault: Red – Power or link failure
### 7. Performance & Capabilities
- Wireless Throughput: Up to 300 Mbps per radio (600 Mbps aggregate)
- Ethernet Speed: 2 × Gigabit ports (10/100/1000 Base‑T(X))
- Latency: Optimized for industrial real‑time communication
- Roaming: Supports X‑Roaming protocol for seamless handover
- Reliability: Dual power inputs and relay fault output for redundancy
- Efficiency: Typical power consumption ≈ 11 W
- Limitations: Indoor use only for 5.15–5.25 GHz band per FCC; requires 20 cm minimum separation from personnel.
### 8. Standards & Compliance
Electrical & Safety:
- EN60950‑1 (Safety of IT Equipment)
- EN50155 (Railway Applications – Electronic Equipment on Rolling Stock)
EMI/EMS Compliance:
- FCC Part 15 Class A
- CISPR 22 (EN55022) Class A
- EN50121‑3‑2, EN55011, EN50121‑4
- EN61000‑4‑2 (ESD)
- EN61000‑4‑3 (RS)
- EN61000‑4‑4 (EFT)
- EN61000‑4‑5 (Surge)
- EN61000‑4‑6 (CS)
- EN61000‑4‑8 (Magnetic Field)
- EN61000‑4‑11 (Dip/Interruption)
Mechanical & Environmental:
- IEC60068‑2‑6 (Vibration)
- IEC60068‑2‑27 (Shock)
- IEC60068‑2‑32 (Free Fall)
- EN61373 (Railway Shock and Vibration)
RF & Regional Compliance:
- FCC and Industry Canada RSS standards
- CE marking for Europe
- RF exposure compliant with uncontrolled environment limits
### 9. Additional Information
Warranty: 5 years limited hardware warranty
Maintenance: Periodic inspection of connectors and antenna tightness recommended; firmware updates available from ORing.
Firmware Upgrade: Via web interface; ensure model‑specific firmware is used.
Support & Contact:
- Manufacturer: ORing Industrial Networking Corp.
- Address: 3F., No. 542‑2, Zhongzheng Rd., Xindian Dist., New Taipei City 23148, Taiwan
- Tel: +886‑2‑2218‑1066 Fax: +886‑2‑2218‑1014
- Website: [www.oring‑networking.com](http://www.oring-networking.com)
- Email: support@oring‑networking.com
Software Management:
- Web GUI (HTTP/HTTPS)
- SNMP v1/v2c support
- ORing Open‑Vision Windows utility
- Syslog and event logging
- Firmware backup and restore functions
Safety Notes:
- Maintain ≥ 20 cm distance from antenna during operation.
- Avoid installation near explosive environments unless certified for such use.
- Ensure adequate airflow and avoid mechanical stress on mounting surfaces.
### Summary
The ORing TGAP‑6620⁺‑M12 is a robust, dual‑radio industrial wireless access point engineered for mission‑critical applications in transportation and heavy industry. With dual Gigabit M12 Ethernet ports, redundant 12–48 V DC power inputs, and EN50155 certification, it delivers high‑reliability wireless connectivity in vibration‑prone and temperature‑extreme environments. Its comprehensive security suite, flexible operation modes, and advanced management interfaces make it suitable for rolling stock networks, industrial automation, and remote monitoring systems requiring stable and secure wireless communication.
-
-M12 Series.webp)
DataSheet_TGAP-6620(+)-M12 Series.pdf
PDF Catalog
-M12_ 6620(+)-M12.webp)
-M12 Series.webp)
No accessories available.
