PCIe-8158 - Adlink Technology Inc.
PCIe 8-axis servo and stepper motion controller
PC Add-On Cards, DIO Cards, and Motion Control Plug-In Cards are all types of add-on cards which can be used to expand the capabilities of a PC. Motion Control / EtherCAT PCIe is a type of add-on card that can be used to control motion and provide Ethernet communication capabilities. It is a powerful and reliable way to add motion control and Ethernet capabilities to a PC..
1.763,00 €
incl. VAT 2.097,97 €
incl. VAT 2.097,97 €
Description
- PCI Express x1 lane interface
- Advanced 8-axis servo & stepper motion controller
- 2- to 4-axis linear interpolation
- 2-axis circular interpolation
- 16CH TTL digital inputs and 16CH TTL digital outputs
- Up to 6.55 MHz pulse output rate
- 100pin SCSI-II connector - use ACL-102100-1 for cabling
Details
- Connectors: SCSI-II-100f
- Width: 185 mm
- Height: 98.4 mm
- Weight: 0.8kg
- Manufacturer: Adlink Technology Inc.
- Part number: 91-18404-0030
- Country of Origin: Taiwan R.O.C.
- Customs code: 8473 3020 000
Data Sheets
Manuals
Downloads
Accessories
-
DIN-100S-01
100pin SCSI-II termination board DIN rail w/o cable -
DIN-814M0
Panel for J2S-A Mitsubishi servo amplifier -
DIN-814M-J3A0
Panel for J3A Mitsubishi servo amplifier -
DIN-814P-A40
Panel for MNAS A4 Panasonic servo amplifier -
DIN-814PA0
Panel for MNAS A Panasonic servo amplifier -
DIN-814Y0
Panel for Sigma II Yaskawa servo amplifier -
ACL-102100-1
100pin SCSI-II cable 1m
