TPS-3082GT-M12X-BP1 - Oring

Managed Switch 8*100TX 8*PoE M12 2*GbE Bypass EN50155

This network is designed to support rugged devices in EN50155 certified railway applications. It features PoE managed EN50155 technology to ensure reliable and secure data transmission in harsh environments. It is a reliable and efficient solution for mission-critical railway applications..

Description

  • Industrial Managed 2*T1000TX+8*100TX 8*PoE IEEE802.3af switch
  • 15,4W PSE
  • bypass function on last 2*ports
  • 9*M12 X-coded connector
  • Railway system standard EN50155
  • alarm LED e-mail warning system log output
  • DIN-rail mounting
  • ESD 4kV DC Ethernet ports
  • surge 2000VDC power
  • DC power input 50..57VDC M23 connector
  • extended -40°..70°C operating temperature
  • ~1.550gr
  • 212*75*196mm
  • Oring

Details

  • Width: 212 mm
  • Height: 75 mm
  • Depth: 196 mm
  • Net weight: 1.55 kg
  • Weight: 1.9kg
  • Manufacturer: Oring
  • Country of Origin: Taiwan R.O.C.
  • Customs code: 8517 6200 900
