IP66 Jetson AGX Orin Industrial computer with 4x PoE+ GbE and 1x 10GbE.

IP66 fanless computer powered by NVIDIA Jetson AGX Orin Industrial with 64GB eMMC, four PoE+ Gigabit Ethernet ports, one 10GBASE-T port, USB 3.2/DisplayPort, isolated CAN and serial I/O, NVMe and SATA expansion, and 8V to 48V DC input with ignition control. Rated from -40°C to 75°C under reduced interface load and -40°C to 60°C with full function; no GMSL2 ports.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP66 Jetson AGX Orin Industrial computer with 8x GMSL2, 4x PoE+ and 10GbE.

IP66 fanless computer powered by NVIDIA Jetson AGX Orin Industrial with 64GB eMMC, eight GMSL2 camera inputs, four PoE+ Gigabit Ethernet ports, one 10GBASE-T port, USB 3.2/DisplayPort, isolated CAN and serial I/O, NVMe and SATA expansion, and 8V to 48V DC input with ignition control. Rated from -40°C to 75°C under reduced interface load and -40°C to 60°C with full function.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 fanless computer with Core i3-N305, dual 2.5GbE and isolated industrial I/O.

Sealed IP67 fanless embedded computer with Intel Core i3-N305 processor, up to 16 GB DDR5-4800, dual 2.5GbE, isolated RS-232 and RS-422/485, CAN 2.0B, one isolated DI and two isolated DO. Includes M.2 NVMe/SATA storage, full-size Mini-PCIe expansion, HDMI 1.4b, two internal USB 3.2 Gen2 ports and 8–35 VDC ignition-controlled input. Operates from -25°C to 70°C.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 fanless edge AI computer with NVIDIA L4 and eight M12 PoE+ ports.

IP67 waterproof and dustproof fanless GPU computer with NVIDIA L4, Intel Xeon E or 9th/8th Gen Core CPU support, eight Gigabit PoE+ ports, M12 connectivity, up to 64 GB DDR4, NVMe and SATA storage, 8–48 VDC input, ignition control and rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 fanless edge AI computer with NVIDIA L4 and four M12 PoE+ ports.

IP67 waterproof and dustproof fanless GPU computer with NVIDIA L4, Intel Xeon E or 9th/8th Gen Core CPU support, four Gigabit PoE+ ports, M12 connectivity, up to 64 GB DDR4, NVMe and SATA storage, 8–48 VDC input, ignition control and rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 fanless edge AI computer with RTX 2000 Ada and eight M12 PoE+ ports.

IP67 waterproof and dustproof fanless GPU computer with NVIDIA RTX 2000 Ada, Intel Xeon E or 9th/8th Gen Core CPU support, eight Gigabit PoE+ ports, M12 connectivity, up to 64 GB DDR4 memory, NVMe and SATA storage, 8–48 VDC input, ignition control and rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 fanless edge AI computer with RTX 2000 Ada and four M12 PoE+ ports.

IP67 waterproof and dustproof fanless GPU computer with NVIDIA RTX 2000 Ada, Intel Xeon E or 9th/8th Gen Core CPU support, four Gigabit PoE+ ports, M12 connectivity, up to 64 GB DDR4 memory, NVMe and SATA storage, 8–48 VDC input, ignition control and rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 NVIDIA L4 computer with eight PoE+ ports and M12 10GbE.

IP67 fanless GPU computer with NVIDIA L4, eight Gigabit PoE+ ports and one 10GbE port. Supports Intel Xeon E or 9th/8th Gen Core processors, up to 64 GB DDR4, NVMe and SATA storage, M12 I/O including audio, 8–48 VDC input, ignition control and 2U rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 NVIDIA L4 computer with four PoE+ ports and M12 10GbE.

IP67 fanless GPU computer with NVIDIA L4, four Gigabit PoE+ ports and one 10GbE port. Supports Intel Xeon E or 9th/8th Gen Core processors, up to 64 GB DDR4, NVMe and SATA storage, M12 I/O including audio, 8–48 VDC input, ignition control and 2U rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 RTX 2000 Ada computer with eight PoE+ ports and M12 10GbE.

IP67 fanless GPU computer with NVIDIA RTX 2000 Ada, eight Gigabit PoE+ ports and one 10GbE port. Supports Intel Xeon E or 9th/8th Gen Core processors, up to 64 GB DDR4, NVMe and SATA storage, rugged M12 connectivity, 8–48 VDC input, ignition control and 2U rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP67 RTX 2000 Ada computer with four PoE+ ports and M12 10GbE.

IP67 fanless GPU computer with NVIDIA RTX 2000 Ada, four Gigabit PoE+ ports and one 10GbE port. Supports Intel Xeon E or 9th/8th Gen Core processors, up to 64 GB DDR4, NVMe and SATA storage, rugged M12 connectivity, 8–48 VDC input, ignition control and 2U rack or wall mounting.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP69K fanless 2U edge AI computer with NVIDIA L4 and eight M12 Ethernet ports.

Extreme-rugged 2U 19-inch rack-mount computer with NVIDIA L4 GPU and Intel 14th/13th/12th Gen Core processor support. Features up to 128 GB ECC/non-ECC DDR5, eight M12 Ethernet ports including 2x 10GbE and 4x 2.5GbE PoE+, isolated CAN and serial interfaces, NVMe and SATA storage, 8–48 VDC input, IP69K protection and fanless operation from -40°C to 70°C with a 35 W CPU.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP69K fanless 2U edge AI computer with NVIDIA L4 and seven M12 Ethernet ports.

Extreme-rugged 2U 19-inch rack-mount computer with NVIDIA L4 GPU and Intel 14th/13th/12th Gen Core processor support. Features up to 128 GB DDR5, seven M12 Ethernet ports including 2x 10GbE and 4x 2.5GbE PoE+, isolated CAN and serial interfaces, NVMe and SATA storage, 8–48 VDC input, IP69K protection and fanless operation from -40°C to 70°C with a 35 W CPU.

Manufacturer: Neousys Technology

Category: Industrial Computer

IP69K fanless mission-critical computer with 14th/13th/12th Gen Intel Core support.

2U 19-inch half-rack rugged computer supporting 35 W Intel 14th, 13th and 12th Gen Core processors, up to 128 GB ECC/non-ECC DDR5-4800, dual SATA with RAID 0/1 and one PCIe Gen4 x4 NVMe socket. Provides 2x 10GbE, 4x 2.5GbE, 1x GbE, 2x isolated CAN 2.0, USB, DisplayPort and four isolated serial ports through rugged M12 connectors. Features IP69K protection, -40°C to 70°C fanless operation and 9–36 VDC input with ignition control.

Manufacturer: Neousys Technology

Category: Industrial Computer

Jetson Orin NX edge AI computer with 16GB memory and four 2.5GbE PoE+ ports.

Compact fanless edge AI computer with NVIDIA Jetson Orin NX, 16GB LPDDR5, 128GB NVMe and a pre-installed system image. It provides four 2.5GbE PoE+ camera ports with a 50W total budget, one GbE port, two USB 2.0 ports, DisplayPort, RS-232 and isolated RS-485. The flattop heatsink supports conduction-cooled installation in sealed cabinets. Dimensions are 116 x 171 x 27 mm; fanless operating temperature is -25°C to 60°C under the specified mounting conditions.

Manufacturer: Neousys Technology

Category: Industrial Computer

Jetson Orin NX edge AI computer with 16GB memory and six USB 3.2 camera ports.

Compact fanless edge AI computer with NVIDIA Jetson Orin NX, 16GB LPDDR5, 128GB NVMe and a pre-installed system image. Camera connectivity comprises two USB 3.2 Gen2 ports and four USB 3.2 Gen1 ports, all with screw locks. It also provides two USB 2.0 ports, one GbE port, DisplayPort, RS-232 and isolated RS-485. The flattop heatsink supports conduction-cooled cabinet installation. Dimensions are 116 x 171 x 27 mm; fanless operating temperature is -25°C to 60°C under the specified mounting conditions.

Manufacturer: Neousys Technology

Category: Industrial Computer

Jetson Orin NX edge AI computer with 8GB memory and four 2.5GbE PoE+ ports.

Compact fanless edge AI computer with NVIDIA Jetson Orin NX, 8GB LPDDR5, 128GB NVMe and a pre-installed system image. It provides four 2.5GbE PoE+ camera ports with a 50W total budget, one GbE port, two USB 2.0 ports, DisplayPort, RS-232 and isolated RS-485. The flattop heatsink supports conduction-cooled installation in sealed cabinets. Dimensions are 116 x 171 x 27 mm; fanless operating temperature is -25°C to 60°C under the specified mounting conditions.

Manufacturer: Neousys Technology

Category: Industrial Computer

Jetson Orin NX edge AI computer with 8GB memory and six USB 3.2 camera ports.

Compact fanless edge AI computer with NVIDIA Jetson Orin NX, 8GB LPDDR5, 128GB NVMe and a pre-installed system image. Camera connectivity comprises two USB 3.2 Gen2 ports and four USB 3.2 Gen1 ports, all with screw locks. It also provides two USB 2.0 ports, one GbE port, DisplayPort, RS-232 and isolated RS-485. The flattop heatsink supports conduction-cooled cabinet installation. Dimensions are 116 x 171 x 27 mm; fanless operating temperature is -25°C to 60°C under the specified mounting conditions.

Manufacturer: Neousys Technology

Category: Industrial Computer

Lightweight Jetson Orin NX 16GB mission computer for UAV and UGV applications.

NVIDIA Jetson Orin NX SOM with Ampere GPU, ARM Cortex CPU and 16GB LPDDR5 at 3200 MHz. Provides 1x GbE, 1x 2.5GbE, USB 3.2 Gen2 and Gen1, 2x GMSL2, DisplayPort, CAN 2.0, UART, I2C and isolated 2 DI/4 DO. Includes an M.2 2230 M-key NVMe Gen4 x4 interface and an M.2 3042/3052 B-key slot with micro SIM for 4G/5G modules. Supports 12–60 VDC and 4S–14S batteries. Unenclosed version: 124 x 123 x 29.8 mm, 297 g. Extended operating temperatures require specified cooling and battery conditions.

Manufacturer: Neousys Technology

Category: Artificial Intelligence Robot

Lightweight Jetson Orin NX 8GB mission computer for UAV and UGV applications.

NVIDIA Jetson Orin NX SOM with Ampere GPU, ARM Cortex CPU and 8GB LPDDR5 at 3200 MHz. Provides 1x GbE, 1x 2.5GbE, USB 3.2 Gen2 and Gen1, 2x GMSL2, DisplayPort, CAN 2.0, UART, I2C and isolated 2 DI/4 DO. Includes an M.2 2230 M-key NVMe Gen4 x4 interface and an M.2 3042/3052 B-key slot with micro SIM for 4G/5G modules. Supports 12–60 VDC and 4S–14S batteries. Unenclosed version: 124 x 123 x 29.8 mm, 297 g. Extended operating temperatures require specified cooling and battery conditions.

Manufacturer: Neousys Technology

Category: Artificial Intelligence Robot

Low-profile fanless embedded PC with Intel Core Ultra 200S and 2.5-inch HDD tray.

Low-profile rugged fanless embedded computer supporting Intel Core Ultra 200S LGA1851 35W/65W CPUs, Intel H810 chipset, up to 128GB DDR5-6400, 1x 2.5GbE plus 1x GbE, up to 2x USB 3.2 Gen2, 2x USB 3.2 Gen1 and 4x USB 2.0, 4 isolated DI and 4 isolated DO, HDMI, 2x DisplayPort, 2x software-programmable RS-232/422/485 and 2x RS-232, hot-swappable 2.5-inch HDD/SSD tray, internal SATA, 2x mini-PCIe, and MezIO interface.

Manufacturer: Neousys Technology

Category: No category

Low-profile fanless embedded PC with Intel Core Ultra 200S, 6 LAN and HDD tray.

Low-profile rugged fanless embedded computer supporting Intel Core Ultra 200S LGA1851 35W/65W CPUs, Intel Q870 chipset, up to 128GB DDR5-6400, 5x 2.5GbE plus 1x GbE, optional 10GBASE-T and optional PoE+ on ports 3 to 6, 8x USB 3.2 Gen2, 4 isolated DI and 4 isolated DO, HDMI, 2x DisplayPort, 2x software-programmable RS-232/422/485 and 2x RS-232, M.2 NVMe Gen5x4, hot-swappable 2.5-inch HDD/SSD tray, 2x mini-PCIe, and MezIO interface.

Manufacturer: Neousys Technology

Category: No category

- **Dual 16-Channel Configuration:** Provides 16 isolated digital input channels and 16 isolated digital output channels, allowing simultaneous monitoring and control of multiple digital signals. - **High Isolation Voltage:** Each channel is electrically isolated up to **2500 Vrms**, protecting the host system from voltage surges, ground loops, and electrical noise. - **Wide Logic Level Range:** Supports input logic high levels from **5 to 24 VDC** and logic low levels from **0 to 1.5 VDC**, ensuring compatibility with a wide range of industrial sensors and actuators. - **Flexible Operation Modes:** Supports both **Polling Mode** and **Change-of-State (COS) Mode**, enabling efficient event-driven or continuous signal monitoring depending on application requirements. - **Robust Output Drive Capability:** Each output channel can sink up to **500 mA at 24 VDC (100% duty cycle)**, suitable for driving relays, solenoids, and indicator lamps. - **Industrial-Grade Design:** Built for rugged environments, the MezIO-D230-12 maintains stable performance under industrial temperature ranges and electrical conditions. - **Compact Modular Integration:** Designed as a **MezIO™ module**, it seamlessly integrates with Neousys POC-120 series systems, expanding I/O capabilities without increasing system footprint. - **Standardized Connector Interface:** Utilizes a **68-pin SCSI-II female connector** for consistent, secure, and high-density signal interfacing. - **Interchangeable and Scalable:** Part of the MezIO™ modular ecosystem, allowing users to interchange modules for different I/O, communication, or storage functions as needed.

Manufacturer: Neousys Technology

Category: Nuvo-5000-Series

- **Dual 16-Channel Configuration:** Provides 16 isolated digital input channels and 16 isolated digital output channels, enabling simultaneous monitoring and control of multiple digital signals. - **High Isolation Voltage:** Each channel is protected with **2500 Vrms isolation**, ensuring electrical separation between field signals and system logic, improving safety and noise immunity in industrial environments. - **Flexible Operation Modes:** Supports both **Polling Mode** and **Change of State (COS) Mode**, allowing users to choose between continuous signal monitoring or event-driven input detection. - **Wide Logic Level Compatibility:** Accepts **logic high levels from 5 to 24 VDC** and **logic low levels from 0 to 1.5 VDC**, making it compatible with a wide range of industrial sensors and actuators. - **High Output Drive Capability:** Each output channel can **sink up to 500 mA at 24 VDC (100% duty cycle)**, suitable for driving relays, solenoids, and indicator lamps. - **Standardized Connector Interface:** Utilizes a **68-pin SCSI-II female connector**, ensuring reliable connectivity and compatibility with standard industrial cabling and terminal boards. - **Seamless Integration with Neousys Platforms:** Designed for plug-and-play compatibility with Neousys embedded systems, including **Nuvo-7000**, **Nuvo-5000**, **POC-500**, and **POC-300** series. - **Industrial-Grade Reliability:** Engineered for harsh environments with robust electrical isolation, stable operation, and long-term durability.

Manufacturer: Neousys Technology

Category: Nuvo-5000-Series

- **Dedicated 2.5" SATA Drive Support:** Provides a direct SATA interface for integrating a 2.5-inch HDD or SSD, supporting both mechanical and solid-state storage devices. - **Interchangeable Modular Design:** Built on the **MezIO™ modular platform**, allowing seamless integration with compatible Neousys embedded systems such as the **POC‑500** and **POC‑300** series. - **High-Speed SATA Interface:** Supports SATA III (6 Gbps) data transfer rates, ensuring fast read/write performance for data-intensive applications. - **Compact and Rugged Construction:** Designed for industrial environments, the MezIO‑R11 maintains mechanical robustness and thermal stability suitable for embedded deployments. - **Plug‑and‑Play Integration:** The module can be easily installed or replaced without complex wiring or configuration, minimizing downtime and simplifying system customization. - **Optimized for Embedded Edge Systems:** Ideal for edge computing, data logging, machine vision, and industrial automation systems requiring local data storage. - **Compatibility with Other MezIO Modules:** Can be combined with other MezIO modules (e.g., MezIO‑D230 for digital I/O, MezIO‑C180 for serial communication, or MezIO‑U4 for USB expansion) to create a tailored embedded solution.

Manufacturer: Neousys Technology

Category: Nuvo-5000-Series
